Motorola ASTRO Digital XTL 5000 Detailed Service Manual

Schematics, Component Location Diagrams, and Parts Lists: HUD4022A/HUD4025B (VHF) Main Board 7-47
6881096C74-B May 25, 2005
HUD4022A (VHF) Main Board Parts List
Reference
Designator
Motorola
Part Number
Description
C0001 2311049A78 CAP TANT CHIP 10.0 UF
C0100 2113743N32 CAP CHIP 18.0 PF 5% CO
C0101 2113743N32 CAP CHIP 18.0 PF 5% CO
C0102 2113743M24 CAP CHIP 100000 PF +80
C0103 2113743M24 CAP CHIP 100000 PF +80
C0104 2113743M24 CAP CHIP 100000 PF +80
C0105 2113743M24 CAP CHIP 100000 PF +80
C0106 2113743N50 CAP CHIP 100 PF 5% COG
C0107 2113743L09 CAP CHIP 470 PF 10% X7
C0201 2113743M24 CAP CHIP 100000 PF +80
C0202 2113743M24 CAP CHIP 100000 PF +80
C0203 2113928S04 CAP CER CHIP 0.100UF 1
C0204 2185802B01 CAP 10V 4.7UF
C0205 2113743N54 CAP CHIP 150 PF 5% COG
C0206 2113928E01 CAP CER CHIP 1.0 UF 10
C0001 2311049A78 CAP TANT CHIP 10.0 UF
C0100 2113743N32 CAP CHIP 18.0 PF 5% CO
C0101 2113743N32 CAP CHIP 18.0 PF 5% CO
C0102 2113743M24 CAP CHIP 100000 PF +80
C0103 2113743M24 CAP CHIP 100000 PF +80
C0104 2113743M24 CAP CHIP 100000 PF +80
C0105 2113743M24 CAP CHIP 100000 PF +80
C0106 2113743N50 CAP CHIP 100 PF 5% COG
C0107 2113743L09 CAP CHIP 470 PF 10% X7
C0201 2113743M24 CAP CHIP 100000 PF +80
C0202 2113743M24 CAP CHIP 100000 PF +80
C0203 2113928S04 CAP CER CHIP 0.100UF 1
C0204 2185802B01 CAP 10V 4.7UF
C0205 2113743N54 CAP CHIP 150 PF 5% COG
C0206 2113928E01 CAP CER CHIP 1.0 UF 10
C0207 2113743N38 CAP CHIP 33.0 PF 5% CO
C0208 2113928E01 CAP CER CHIP 1.0 UF 10
C0209 2113743M24 CAP CHIP 100000 PF +80
C0210 2113743M24 CAP CHIP 100000 PF +80
C0211 2113743N50 CAP CHIP 100 PF 5% COG
C0212 2113743M24 CAP CHIP 100000 PF +80
C0213 2113743M24 CAP CHIP 100000 PF +80
C0214 2113741N69 CAP CHIP CL2 X7R 10% 1
C0215 2113928S04 CAP CER CHIP 0.100UF 1
C0216 2113743M24 CAP CHIP 100000 PF +80
C0217 2113743L29 CAP CHIP 3300 PF 10% X
C0220 2311049A57 CAP TANT CHIP A/P 10UF
C0221 2311049C06 CAP TANT CHIP 22 UF 35
C0223 2185802B01 CAP 10V 4.7UF
C0224 2113743M24 CAP CHIP 100000 PF +80
C0225 2113928S04 CAP CER CHIP 0.100UF 1
C0226 2113928S04 CAP CER CHIP 0.100UF 1
C0227 2113743M24 CAP CHIP 100000 PF +80
C0228 2113743N54 CAP CHIP 150 PF 5% COG
C0230 2113743L09 CAP CHIP 470 PF 10% X7
C0231 2113743L01 CAP CHIP 220 PF 10% X7
C0232 2113743L09 CAP CHIP 470 PF 10% X7
C0233 2113743L01 CAP CHIP 220 PF 10% X7
C0234 2113928S04 CAP CER CHIP 0.100UF 1
C0235 2113743L09 CAP CHIP 470 PF 10% X7
C0236 2113743L09 CAP CHIP 470 PF 10% X7
C0237 2113743L01 CAP CHIP 220 PF 10% X7
C0238 2113743L01 CAP CHIP 220 PF 10% X7
C0239 2113743M24 CAP CHIP 100000 PF +80
C0240 2113928S04 CAP CER CHIP 0.100UF 1
C0242 2113928S04 CAP CER CHIP 0.100UF 1
C0243 2113945B01 CAP CER CHP 6800PF
25V
C0244 2113945B01 CAP CER CHP 6800PF
25V
C0301 2113743M24 CAP CHIP 100000 PF +80
C0302 2113743M24 CAP CHIP 100000 PF +80
C0305 2113743M24 CAP CHIP 100000 PF +80
C0306 2113743M24 CAP CHIP 100000 PF +80
C0308 2113743E20 CAP CHIP .10 UF 10%
C0309 2113743E20 CAP CHIP .10 UF 10%
C0310 2113743E20 CAP CHIP .10 UF 10%
C0311 2113743M24 CAP CHIP 100000 PF +80
C0312 2113743M24 CAP CHIP 100000 PF +80
C0313 2113743M24 CAP CHIP 100000 PF +80
C0400 2113743N38 CAP CHIP 33.0 PF 5% CO
C0401 2113743N50 CAP CHIP 100 PF 5% COG
C0402 2113743N38 CAP CHIP 33.0 PF 5% CO
C0403 2113743N38 CAP CHIP 33.0 PF 5% CO
C0404 2113743N38 CAP CHIP 33.0 PF 5% CO
Reference
Designator
Motorola
Part Number
Description
C0405 2113743N38 CAP CHIP 33.0 PF 5% CO
C0406 2113743N38 CAP CHIP 33.0 PF 5% CO
C0407 2113743N50 CAP CHIP 100 PF 5% COG
C0408 2113743N50 CAP CHIP 100 PF 5% COG
C0409 2113743N38 CAP CHIP 33.0 PF 5% CO
C0410 2113743N38 CAP CHIP 33.0 PF 5% CO
C0412 2113743N50 CAP CHIP 100 PF 5% COG
C0413 2113743N50 CAP CHIP 100 PF 5% COG
C0414 2113743L01 CAP CHIP 220 PF 10% X7
C0415 2113743L01 CAP CHIP 220 PF 10% X7
C0416 2113743N50 CAP CHIP 100 PF 5% COG
C0417 2113743L01 CAP CHIP 220 PF 10% X7
C0418 2113743L01 CAP CHIP 220 PF 10% X7
C0419 2113743N50 CAP CHIP 100 PF 5% COG
C0420 2185802B01 CAP 10V 4.7UF
C0421 2113741B13 CAP CHIP CL2 X7R REEL
C0422 2113743N38 CAP CHIP 33.0 PF 5% CO
C0423 2113743N38 CAP CHIP 33.0 PF 5% CO
C0424 2113743N38 CAP CHIP 33.0 PF 5% CO
C0425 2113743N50 CAP CHIP 100 PF 5% COG
C0426 2113741B13 CAP CHIP CL2 X7R REEL
C0427 2113743N50 CAP CHIP 100 PF 5% COG
C0428 2113743N50 CAP CHIP 100 PF 5% COG
C0429 2113743N50 CAP CHIP 100 PF 5% COG
C0430 2113743N50 CAP CHIP 100 PF 5% COG
C0431 2113743N50 CAP CHIP 100 PF 5% COG
C0432 2113743N50 CAP CHIP 100 PF 5% COG
C0433 2113743N50 CAP CHIP 100 PF 5% COG
C0434 2113743N50 CAP CHIP 100 PF 5% COG
C0435 2113743L09 CAP CHIP 470 PF 10% X7
C0436 2113741B13 CAP CHIP CL2 X7R REEL
C0437 2113741B13 CAP CHIP CL2 X7R REEL
C0438 2113743L09 CAP CHIP 470 PF 10% X7
C0439 2113743N50 CAP CHIP 100 PF 5% COG
C0440 2113743N50 CAP CHIP 100 PF 5% COG
C0441 2113743M24 CAP CHIP 100000 PF +80
C0442 2113743N38 CAP CHIP 33.0 PF 5% CO
C0443 2113743N38 CAP CHIP 33.0 PF 5% CO
C0444 2113743N38 CAP CHIP 33.0 PF 5% CO
C0445 2113743N38 CAP CHIP 33.0 PF 5% CO
C0446 2113743N50 CAP CHIP 100 PF 5% COG
Reference
Designator
Motorola
Part Number
Description
C0447 2113743N50 CAP CHIP 100 PF 5% COG
C0448 2113743N50 CAP CHIP 100 PF 5% COG
C0449 2113743N50 CAP CHIP 100 PF 5% COG
C0450 2113743N38 CAP CHIP 33.0 PF 5% CO
C0451 2113743N38 CAP CHIP 33.0 PF 5% CO
C0452 2113743N38 CAP CHIP 33.0 PF 5% CO
C0453 2113743N38 CAP CHIP 33.0 PF 5% CO
C0454 2113743N38 CAP CHIP 33.0 PF 5% CO
C0455 2113743N38 CAP CHIP 33.0 PF 5% CO
C0456 2113743N38 CAP CHIP 33.0 PF 5% CO
C0457 2113743N38 CAP CHIP 33.0 PF 5% CO
C0458 2113743N38 CAP CHIP 33.0 PF 5% CO
C0459 2113743N38 CAP CHIP 33.0 PF 5% CO
C0460 2113743N50 CAP CHIP 100 PF 5% COG
C0461 2113743L01 CAP CHIP 220 PF 10% X7
C0462 2113743L01 CAP CHIP 220 PF 10% X7
C0463 2113743N38 CAP CHIP 33.0 PF 5% CO
C0464 2113743N38 CAP CHIP 33.0 PF 5% CO
C0465 2113741B13 CAP CHIP CL2 X7R REEL
C0466 2113743N50 CAP CHIP 100 PF 5% COG
C0467 2113743N50 CAP CHIP 100 PF 5% COG
C0469 2113743M24 CAP CHIP 100000 PF +80
C0470 2113743N38 CAP CHIP 33.0 PF 5% CO
C0475 2113743N50 CAP CHIP 100 PF 5% COG
C0476 2113743N50 CAP CHIP 100 PF 5% COG
C0477 2113743N50 CAP CHIP 100 PF 5% COG
C0478 2113743N50 CAP CHIP 100 PF 5% COG
C0500 2113743M24 CAP CHIP 100000 PF +80
C0502 2113743N50 CAP CHIP 100 PF 5% COG
C0503 2113743N50 CAP CHIP 100 PF 5% COG
C0504 2113741N69 CAP CHIP CL2 X7R 10% 1
C0505 2113743L41 CAP CHIP 10000 PF 10%
C0506 2113743L41 CAP CHIP 10000 PF 10%
C0507 2113743M24 CAP CHIP 100000 PF +80
C0510 2185802B01 CAP 10V 4.7UF
C0512 2113743M24 CAP CHIP 100000 PF +80
C0513 2311049A43 CAP TANT CHIP 150 10 6
C0514 2311049A43 CAP TANT CHIP 150 10 6
C0515 2113743M24 CAP CHIP 100000 PF +80
C0516 2113743M24 CAP CHIP 100000 PF +80
C0517 2185802B01 CAP 10V 4.7UF
Reference
Designator
Motorola
Part Number
Description
