Schematics, Component Location Diagrams, and Parts Lists: HUE4039A/HUE4043A (UHF Range 1) Main Board 7-115
6881096C74-B May 25, 2005
U0603 5113837A15 IC 3.3V QUAD BUFFER
U0604 5113818A14 IC DL OP AMP RAIL TO RAIL
U0605 5109522E17 IC SNGL NAND TC7S00FU
U0606 5105109Z31 IC QUAD 2:1 MUX/DEMUX
U0607 5109522E74 IC 2-INPUT AND GATE
U0608 5109522E74 IC 2-INPUT AND GATE
U0609 5109522E17 IC SNGL NAND TC7S00FU
U0610 5109522E17 IC SNGL NAND TC7S00FU
U0900 5185368C83 IC 12 BIT DAC
U0901 5185143E43 IC 23 MACROCELL CPLD
U0902 5113805B39 IC MUX/DEMUX, TRIP 2-CH
ANALOG
U0903 5185143E68 IC LM7219 HIGH SPEED
COMPARATOR
U0950 5105625U25 IC 9.3V REG 2941
U0951 5105625U25 IC 9.3V REG 2941
U0952 5185353D35 IC DUAL EPOT 256 TAP
U0953 5185143E16 IC ANALOG TO DIGITAL
CONVERTER
U0954 5109522E17 IC SNGL NAND TC7S00FU
U0955 5113819A14 IC QD OP AMP _33204_
U0956 5185956E24 QUAD OP AMP RAIL TO RAIL
14
U0957 5113819A14 IC QD OP AMP _33204_
U0958 5109522E17 IC SNGL NAND TC7S00FU
U0959 5185143E05 IC DAC OCTAL 8 BIT
U0960 5113819A14 IC QD OP AMP _33204_
U0962 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U0963 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U0965 5185143E68 IC LM7219 HIGH SPEED
COMPARATOR
U5001 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U5002 5185963A85 IC-ABACUS III-LP
U5300 5185130C83 IC 15DB DIGITAL
ATTEUATOR SOT25 PKG
U5301 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U5302 5186258W01 IC GAAS RF GAIN STAGE
U5303 5185130C65 IC VHF/UHF/800 MHZ LDMOS
DRIVER
Reference
Designator
Motorola
Part Number
Description
U5400 5185963A87 IC ATTENUATOR
U5501 5185130C65 IC VHF/UHF/800 MHZ LDMOS
DRIVER
U5502 5185963A15 IC TEMPERTURE SENSOR
1M50C
U5503 5185353D92 IC CURRENT SHUNT
MONITOR
U5570 5183308X01 IC, LM2941, TO DRPOUT
RGTR
U5750 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U5751 5105492X03 IC SNG HI SPD L-MOS NOT
GATE
U5752 5185963A27 IC TESTED AT25016 48 PIN
GFP
U5753 5113805B87 IC MUX/DEMUX DUAL 4
CHAN ANALOG
U5825 4885757E03 RESONATOR 4MMX4MM
COPPER DIELECTRIC
COAXIAL
U5826 4885757E02 RESONATOR 4MM X 4MM
COPPER DIELECTRIC
VR0400 4805656W09 DIODE QUAD 20 VOLT
ZENER
VR0402 4805656W09 DIODE QUAD 20 VOLT
ZENER
VR0404 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0405 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0406 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0407 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0408 4813832C75 DIODE ZENER QU O
VR0410 4813832C75 DIODE ZENER QU O
VR0411 4805656W39 QUAD ESD SUPPRESSOR
ARRAY -41206ESD
VR0412 4805656W09 DIODE QUAD 20 VOLT
ZENER
VR0414 4813832C75 DIODE ZENER QU O
VR0417 4813832C75 DIODE ZENER QU O
VR0418 4813832C75 DIODE ZENER QU O
VR0420 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
Reference
Designator
Motorola
Part Number
Description
VR0421 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
VR0422 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0423 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0424 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0425 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0500 4813830A14 DIODE 5.1V 5% 225MW
MMBZ5231B_
VR0501 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
VR0950 4813832C77 TRANS SUP .24V HIGH PWR
Y0100 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Y5400 4885230C01 109.65MHZ FILTER 3RD
OVERTONE
Y5401 4885230C01 109.65MHZ FILTER 3RD
OVERTONE
Y5750 5185143E07 IC 16.8 MHZ REF OSC .8 PPM
Y5900 4885593E04 RESONATOR 6MMX6MM
COPPER DIELECTRIC
COAXIAL
Y5901 4885593E05 RESONATOR 6MMX6MM
COPPER DIELECTRIC
COAXIAL
Y5902 4885593E06 RESONATOR 6MMX6MM
COPPER DIELECTRIC
COAXIAL
Reference
Designator
Motorola
Part Number
Description
