Motorola ASTRO Digital XTL 5000 Detailed Service Manual

7-120 Schematics, Component Location Diagrams, and Parts Lists: HUE4039A/HUE4043A (UHF Range 1) Main Board
May 25, 2005 6881096C74-B
HUE4043A Main Board Parts List
Reference
Designator
Motorola
Part Number
Description
C0100 2113743N32 CAP CHIP 18.0 PF 5% COG
C0101 2113743N32 CAP CHIP 18.0 PF 5% COG
C0102 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0103 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0104 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0105 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0106 2113743N50 CAP CHIP 100 PF 5% COG
C0107 2113743L09 CAP CHIP 470 PF 10% X7R
C0108 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0109 2113743N32 CAP CHIP 18.0 PF 5% COG
C0200 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0201 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0202 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0203 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C0204 2185802B01 CAP 10V 4.7UF
C0207 2113743N38 CAP CHIP 33.0 PF 5% COG
C0208 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0209 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0210 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0211 2113743N50 CAP CHIP 100 PF 5% COG
C0212 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0213 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0214 2113741N69 CAP CHIP CL2 X7R 10%
100000
C0215 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C0216 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0217 2113743L29 CAP CHIP 3300 PF 10% X7R
C0220 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C0221 2311049C06 CAP TANT CHIP 22 UF 35V
20%
C0223 2185802B01 CAP 10V 4.7UF
C0224 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0226 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C0227 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0230 2113743L09 CAP CHIP 470 PF 10% X7R
C0231 2113743L01 CAP CHIP 220 PF 10% X7R
C0232 2113743L09 CAP CHIP 470 PF 10% X7R
C0233 2113743L01 CAP CHIP 220 PF 10% X7R
C0234 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C0235 2113743L09 CAP CHIP 470 PF 10% X7R
C0236 2113743L09 CAP CHIP 470 PF 10% X7R
C0237 2113743L01 CAP CHIP 220 PF 10% X7R
C0238 2113743L01 CAP CHIP 220 PF 10% X7R
C0239 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0240 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C0242 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C0243 2113945B01 CAP CER CHIP 6800 PF 25V
10%
C0244 2113945B01 CAP CER CHIP 6800 PF 25V
10%
C0301 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0302 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0305 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0306 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0308 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0309 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0310 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
Reference
Designator
Motorola
Part Number
Description
C0311 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0312 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0313 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0314 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0315 2113928E01 CAP CER CHIP 1.0 UF 10 %
10V
C0420 2185802B01 CAP 10V 4.7UF
C0421 2113741B13 CAP CHIP CL2 X7R REEL 470
C0422 2113743N38 CAP CHIP 33.0 PF 5% COG
C0423 2113743N38 CAP CHIP 33.0 PF 5% COG
C0424 2113743N38 CAP CHIP 33.0 PF 5% COG
C0426 2113741B13 CAP CHIP CL2 X7R REEL 470
C0428 2113743N50 CAP CHIP 100 PF 5% COG
C0431 2113743N50 CAP CHIP 100 PF 5% COG
C0432 2113743N50 CAP CHIP 100 PF 5% COG
C0433 2113743N50 CAP CHIP 100 PF 5% COG
C0434 2113743N50 CAP CHIP 100 PF 5% COG
C0435 2113743L09 CAP CHIP 470 PF 10% X7R
C0436 2113741B13 CAP CHIP CL2 X7R REEL 470
C0437 2113741B13 CAP CHIP CL2 X7R REEL 470
C0438 2113743L09 CAP CHIP 470 PF 10% X7R
C0439 2113743N50 CAP CHIP 100 PF 5% COG
C0440 2113743N50 CAP CHIP 100 PF 5% COG
C0441 2311049C47 CAP TANT CHIP 22.0UF 10%
16V
C0442 2113743N38 CAP CHIP 33.0 PF 5% COG
C0443 2113743N38 CAP CHIP 33.0 PF 5% COG
C0444 2113743N38 CAP CHIP 33.0 PF 5% COG
C0445 2113743N38 CAP CHIP 33.0 PF 5% COG
C0446 2113743N50 CAP CHIP 100 PF 5% COG
C0447 2113743N50 CAP CHIP 100 PF 5% COG
C0448 2113743N50 CAP CHIP 100 PF 5% COG
C0449 2113743N50 CAP CHIP 100 PF 5% COG
C0450 2113743N38 CAP CHIP 33.0 PF 5% COG
C0451 2113743N38 CAP CHIP 33.0 PF 5% COG
C0452 2113743N38 CAP CHIP 33.0 PF 5% COG
C0453 2113743N38 CAP CHIP 33.0 PF 5% COG
C0454 2113743N38 CAP CHIP 33.0 PF 5% COG
Reference
Designator
Motorola
Part Number
Description
C0455 2113743N38 CAP CHIP 33.0 PF 5% COG
C0456 2113743N38 CAP CHIP 33.0 PF 5% COG
C0457 2113743N38 CAP CHIP 33.0 PF 5% COG
C0458 2113743N38 CAP CHIP 33.0 PF 5% COG
C0459 2113743N38 CAP CHIP 33.0 PF 5% COG
C0460 2113743N50 CAP CHIP 100 PF 5% COG
C0461 2113743L01 CAP CHIP 220 PF 10% X7R
C0462 2113743L01 CAP CHIP 220 PF 10% X7R
C0463 2113743N38 CAP CHIP 33.0 PF 5% COG
C0464 2113743N38 CAP CHIP 33.0 PF 5% COG
C0467 2113743N50 CAP CHIP 100 PF 5% COG
C0470 2113743N38 CAP CHIP 33.0 PF 5% COG
C0471 2113743N50 CAP CHIP 100 PF 5% COG
C0475 2113743N50 CAP CHIP 100 PF 5% COG
C0476 2113743N50 CAP CHIP 100 PF 5% COG
C0477 2113743N50 CAP CHIP 100 PF 5% COG
C0478 2113743N50 CAP CHIP 100 PF 5% COG
C0479 2113743N50 CAP CHIP 100 PF 5% COG
C0500 2113743N50 CAP CHIP 100 PF 5% COG
C0502 2113743N50 CAP CHIP 100 PF 5% COG
C0503 2113743N50 CAP CHIP 100 PF 5% COG
C0504 2113741N69 CAP CHIP CL2 X7R 10%
100000
C0505 2113743L41 CAP CHIP 10000 PF 10% X7R
C0506 2113743L41 CAP CHIP 10000 PF 10% X7R
C0507 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0510 2185802B01 CAP 10V 4.7UF
C0512 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0513 2311049A43 CAP TANT CHIP 150 10 6
C0514 2311049A43 CAP TANT CHIP 150 10 6
C0515 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0516 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0517 2185802B01 CAP 10V 4.7UF
C0518 2185802B01 CAP 10V 4.7UF
C0519 2113743L41 CAP CHIP 10000 PF 10% X7R
C0520 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C0521 2185802B01 CAP 10V 4.7UF
Reference
Designator
Motorola
Part Number
Description
