Motorola ASTRO Digital XTL 5000 Detailed Service Manual

7-168 Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board
May 25, 2005 6881096C74-B
C5925 2113743N50 CAP CHIP 100 PF 5% COG
C5926 2113743N14 CAP CHIP 3.3 PF +-.25PF
COG
C5927 2113743N19 CAP CHIP 5.1 PF + -.5PF
COG
C5928 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C5929 2113743L01 CAP CHIP 220 PF 10% X7R
C5930 2113743L01 CAP CHIP 220 PF 10% X7R
C5931 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C5932 2113743L01 CAP CHIP 220 PF 10% X7R
C5933 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5935 2113743L01 CAP CHIP 220 PF 10% X7R
C5936 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5937 2113743N50 CAP CHIP 100 PF 5% COG
C5938 2113743Q07 CAP CHIP 1.5 PF +/-.1PF
20*40
C5939 2113743N14 CAP CHIP 3.3 PF +-.25PF
COG
C5940 2113743N19 CAP CHIP 5.1 PF + -.5PF
COG
C5941 2113743N50 CAP CHIP 100 PF 5% COG
C5942 2113743N16 CAP CHIP 3.9 PF +-.25PF
COG
C5943 2113743N20 CAP CHIP 5.6 PF + -.5PF
COG
C5944 2113743N20 CAP CHIP 5.6 PF + -.5PF
COG
C5945 2113743L01 CAP CHIP 220 PF 10% X7R
C5946 2113743L01 CAP CHIP 220 PF 10% X7R
C5947 2113743N20 CAP CHIP 5.6 PF + -.5PF
COG
C5948 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5949 2113743L01 CAP CHIP 220 PF 10% X7R
C5950 2113743N50 CAP CHIP 100 PF 5% COG
C5951 2113743N50 CAP CHIP 100 PF 5% COG
C5956 2113743L01 CAP CHIP 220 PF 10% X7R
C5957 2113743Q03 CAP CHIP 1.0 PF +/-.1PF
20*40
C5958 2113928S04 CAP CER CHIP 0.100UF 10V
0402
Reference
Designator
Motorola
Part Number
Description
C5959 2113743N50 CAP CHIP 100 PF 5% COG
C5960 2113743Q07 CAP CHIP 1.5 PF +/-.1PF
20*40
D0950 4813833C02 DIODE DUAL 70V '5B' COMM
CATH
D0951 4813833C02 DIODE DUAL 70V '5B' COMM
CATH
D0952 4813833C02 DIODE DUAL 70V '5B' COMM
CATH
D5002 4809877C13 DIODE VARACTOR ISV305
SMD
D5003 4805649Q13 DIODE VCTR ISV 228
D5250 4862824C01 DIODE VARACTOR
D5251 4862824C01 DIODE VARACTOR
D5252 4862824C01 DIODE VARACTOR
D5253 4862824C01 DIODE VARACTOR
D5280 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D5281 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D5282 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D5300 4808115L23 DIODE,PIN,SMP1322,,,,100M
A,1V,.25W,
D5301 4808115L23 DIODE,PIN,SMP1322,,,,100M
A,1V,.25W,
D5302 4808115L23 DIODE,PIN,SMP1322,,,,100M
A,1V,.25W,
D5303 4808115L23 DIODE,PIN,SMP1322,,,,100M
A,1V,.25W,
D5380 4882290T04 DIODE SI HOT CARRIER
HSMS 2812
D5381 4882290T04 DIODE SI HOT CARRIER
HSMS 2812
D5400 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D5501 4813833C02 DIODE DUAL 70V '5B' COMM
CATH
D5502 4813833C02 DIODE DUAL 70V '5B' COMM
CATH
D5701 4802482J02 PIN DIODE SMD
D5702 4802482J02 PIN DIODE SMD
D5703 4802482J02 PIN DIODE SMD
D5704 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
Reference
Designator
Motorola
Part Number
Description
D5705 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
D5750 4802233J09 DIODE TRIPLE SOT25-RH
D5751 4802233J09 DIODE TRIPLE SOT25-RH
D5827 4862824C01 DIODE VARACTOR
D5828 4862824C01 DIODE VARACTOR
D5831 4862824C01 DIODE VARACTOR
D5832 4862824C01 DIODE VARACTOR
D5833 4813833C02 DIODE DUAL 70V '5B' COMM
CATH
D5900 4802233J09 DIODE TRIPLE SOT25-RH
D5901 4862824C01 DIODE VARACTOR
D5902 4862824C01 DIODE VARACTOR
D5903 4862824C01 DIODE VARACTOR
D5904 4862824C01 DIODE VARACTOR
D5905 4862824C01 DIODE VARACTOR
D5906 4862824C01 DIODE VARACTOR
D5907 4862824C01 DIODE VARACTOR
D5908 4862824C01 DIODE VARACTOR
D5909 4862824C01 DIODE VARACTOR
D5910 4862824C01 DIODE VARACTOR
D5911 4862824C01 DIODE VARACTOR
D5912 4862824C01 DIODE VARACTOR
E5001 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5002 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5003 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5004 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5005 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5006 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5007 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5008 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5009 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E5400 2484657R01 INDUCTOR BEAD CHIP
E5501 2484657R01 INDUCTOR BEAD CHIP
Reference
Designator
Motorola
Part Number
Description
E5502 2484657R01 INDUCTOR BEAD CHIP
E6750 2480640Z01 SURFACE MOUNT FERRITE
BEAD
F0400 6583049X16 FUSE 5A FAST ACT
FL0900 9185130D01 FLTR SW CAP 3 POLE
BUTTERW
J0401 0985722E01 CONN 50 POS FM SMT
RTANG
J0402 0985631E01 CONNECTOR FEMALE 32
PIN ACCY
J0501 0985473E01 CONN SECURE 20 POS FM
SMT RT ANG
J0950 0905902V07 CONNECTOR DC
J5701 0905901V11 RF
CONNECTOR,RF,,F,,,,,,,CON
N RF
L0400 2485821C07 IND RF 10UH
L5001 2462587L50 CHIP IND 100000 NH 10%
L5002 2462587V36 CHIP IND 150 NH 5% 0805
L5003 2405769X05 COIL INDUCTOR
L5004 2405769X05 COIL INDUCTOR
L5006 2462587V34 CHIP IND 100 NH 5% 0805
L5007 2462587N76 CHIP IND 4700 NH 5%
L5008 2485209F02 IDCTR,COIL,150UH,2%,,,,,,ID
CTR 150N
L5010 2462587Q47 IDCTR,CHIP,1UH,10%,50MA,,
FERR,,,,45
L5012 2462587V34 CHIP IND 100 NH 5% 0805
L5015 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L5053 2413926G19 IND 100 NH 5%
L5237 2462587V26 CHIP IND 22 NH 5% 0805
L5250 2484562T02 COIL SURFACE MOUNT AIR
WOUND
L5251 2484562T03 COIL SURFACE MOUNT AIR
WOUND
L5252 2484562T04 COIL SURFACE MOUNT AIR
WOUND
L5253 2462587X52 IND CHIP LO-PRO 82.0 NH
5%
L5254 2484562T04 COIL SURFACE MOUNT AIR
WOUND
L5255 2484562T03 COIL SURFACE MOUNT AIR
WOUND
Reference
Designator
Motorola
Part Number
Description
