Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board 7-207

6881096C74-B May 25, 2005

HUF4017A Main Board Parts List

Reference

Designator

Motorola

Part Number

Description

B6250 9102603S10 FILTER 860.5 MHZ

B6251 9185503C01 FILTER CERAMIC 770

MHZ

B6252 9102603S10 FILTER 860.5 MHZ

B6253 9185503C01 FILTER CERAMIC 770

MHZ

B6350 9185116C01 FILTER CRYSTAL

B6351 9185116C01 FILTER CRYSTAL

C0001 2380090M24 CAP ALU 10 20 50V SURF

C0100 2113743N32 CAP CHIP 18.0 PF 5%

COG

C0101 2113743N32 CAP CHIP 18.0 PF 5%

COG

C0102 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0103 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0104 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0105 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0106 2113743N50 CAP CHIP 100 PF 5% COG

C0201 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0202 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0203 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0204 2185802B01 CAP 10V 4.7UF

C0205 2113743N54 CAP CHIP 150 PF 5% COG

C0206 2113928E01 CAP CER CHIP 1.0 UF 10

% 10V

C0207 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0208 2113928E01 CAP CER CHIP 1.0 UF 10

% 10V

C0209 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0210 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0211 2113743N50 CAP CHIP 100 PF 5% COG

C0212 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0213 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0214 2113741N69 CAP CHIP CL2 X7R 10%

100000

C0215 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0216 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0217 2113743L29 CAP CHIP 3300 PF 10%

X7R

C0220 2311049A57 CAP TANT CHIP A/P 10UF

10% 16V

C0221 2311049A78 CAP TANT CHIP 10.0 UF

10% 50V

C0223 2185802B01 CAP 10V 4.7UF

C0224 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0225 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0226 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0227 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0228 2113743N54 CAP CHIP 150 PF 5% COG

C0230 2113743L09 CAP CHIP 470 PF 10%

X7R

C0231 2113743L01 CAP CHIP 220 PF 10%

X7R

C0232 2113743L09 CAP CHIP 470 PF 10%

X7R

C0233 2113743L01 CAP CHIP 220 PF 10%

X7R

C0234 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0235 2113743L09 CAP CHIP 470 PF 10%

X7R

C0236 2113743L09 CAP CHIP 470 PF 10%

X7R

C0237 2113743L01 CAP CHIP 220 PF 10%

X7R

C0238 2113743L01 CAP CHIP 220 PF 10%

X7R

C0239 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0240 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0242 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0243 2113945B01 CAP CER CHIP 6800 PF

25V 10%

C0244 2113945B01 CAP CER CHIP 6800 PF

25V 10%

C0301 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0302 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0305 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

Reference

Designator

Motorola

Part Number

Description

C0306 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0307 NOTPLACED 64AM DUMMY PART

NUMBER

C0308 2113743E20 CAP CHIP .10 UF 10%

C0309 2113743E20 CAP CHIP .10 UF 10%

C0310 2113743E20 CAP CHIP .10 UF 10%

C0311 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0312 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0313 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0400 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0401 2113743N50 CAP CHIP 100 PF 5% COG

C0402 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0403 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0404 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0405 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0406 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0407 2113743N50 CAP CHIP 100 PF 5% COG

C0408 2113743N50 CAP CHIP 100 PF 5% COG

C0409 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0410 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0412 2113743N50 CAP CHIP 100 PF 5% COG

C0413 2113743N50 CAP CHIP 100 PF 5% COG

C0414 2113743L01 CAP CHIP 220 PF 10%

X7R

C0415 2113743L01 CAP CHIP 220 PF 10%

X7R

C0416 2113743N50 CAP CHIP 100 PF 5% COG

C0417 2113743L01 CAP CHIP 220 PF 10%

X7R

C0418 2113743L01 CAP CHIP 220 PF 10%

X7R

C0419 2113743N50 CAP CHIP 100 PF 5% COG

C0420 2185802B01 CAP 10V 4.7UF

C0422 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0423 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0424 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0425 2113743N50 CAP CHIP 100 PF 5% COG

Reference

Designator

Motorola

Part Number

Description

C0426 2113741B13 CAP CHIP CL2 X7R REEL

470

C0427 2113743N50 CAP CHIP 100 PF 5% COG

C0428 2113743N50 CAP CHIP 100 PF 5% COG

C0429 2113743N50 CAP CHIP 100 PF 5% COG

C0430 2113743N50 CAP CHIP 100 PF 5% COG

C0431 2113743N50 CAP CHIP 100 PF 5% COG

C0432 2113743N50 CAP CHIP 100 PF 5% COG

C0433 2113743N50 CAP CHIP 100 PF 5% COG

C0434 2113743N50 CAP CHIP 100 PF 5% COG

C0435 2113743L09 CAP CHIP 470 PF 10%

X7R

C0436 2113741B13 CAP CHIP CL2 X7R REEL

470

C0437 2113741B13 CAP CHIP CL2 X7R REEL

470

C0438 2113743L09 CAP CHIP 470 PF 10%

X7R

C0439 2113743N50 CAP CHIP 100 PF 5% COG

C0440 2113743N50 CAP CHIP 100 PF 5% COG

C0441 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0442 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0443 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0444 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0445 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0446 2113743N50 CAP CHIP 100 PF 5% COG

C0447 2113743N50 CAP CHIP 100 PF 5% COG

C0448 2113743N50 CAP CHIP 100 PF 5% COG

C0449 2113743N50 CAP CHIP 100 PF 5% COG

C0450 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0451 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0452 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0453 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0454 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0455 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0456 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0457 2113743N38 CAP CHIP 33.0 PF 5%

COG

C0458 2113743N38 CAP CHIP 33.0 PF 5%

COG

Reference

Designator

Motorola

Part Number

Description
