Motorola ASTRO Digital XTL 5000 Detailed Service Manual

8-4 Interconnect Boards Schematics, Component Location Diagrams, and Parts Lists: Remote Interconnect Boards (Mid Power Only)
May 25, 2005 6881096C74-B
HLN6883A/B Remote Interconnect Board (Standard)
Parts List
Reference
Designator
Motorola
Part Number
Description
PCB 8485919E01 PCB INTERCONNECT
HLN6883B
- 1010041C22 SOLDER PASTE
- 1105033S02 RIBBON LABEL LT. PACK
LABEL
- 1105033S13 RIBBON LBL
- 5405569Y02 LBL BARCODE APC
- 5405569Y03 LABEL BARCODE
HD001 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
HD002 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
HD003 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
HD004 0300139581 SCR MCH 4-40X5/16
PHLPAN STL
JU12 0611077A01 RES CHIP JUMPER
JU512 0611077A01 RES CHIP JUMPER
JU513 0611077A01 RES CHIP JUMPER
JU600 0611077A01 RES CHIP JUMPER
JU601 0611077A01 RES CHIP JUMPER
JU603 0611077A01 RES CHIP JUMPER
JU604 0611077A01 RES CHIP JUMPER
JU606 0611077A01 RES CHIP JUMPER
JU607 0611077A01 RES CHIP JUMPER
JU608 0611077A01 RES CHIP JUMPER
JU609 0611077A01 RES CHIP JUMPER
JU613 0611077A01 RES CHIP JUMPER
JU619 0611077A01 RES CHIP JUMPER
JU620 0611077A01 RES CHIP JUMPER
JU621 0611077A01 RES CHIP JUMPER
JU622 0611077A01 RES CHIP JUMPER
JU623 0611077A01 RES CHIP JUMPER
JU628 0611077A01 RES CHIP JUMPER
JU629 0611077A01 RES CHIP JUMPER
JU631 0611077A01 RES CHIP JUMPER
JU632 0611077A01 RES CHIP JUMPER
JU633 0611077A01 RES CHIP JUMPER
JU634 0611077A01 RES CHIP JUMPER
JU635 0611077A01 RES CHIP JUMPER
JU637 0611077A01 RES CHIP JUMPER
JU638 0611077A01 RES CHIP JUMPER
JU640 0611077A01 RES CHIP JUMPER
JU641 0611077A01 RES CHIP JUMPER
JU642 0611077A01 RES CHIP JUMPER
JU650 0611077A01 RES CHIP JUMPER
JU654 0611077A01 RES CHIP JUMPER
JU656 0611077A01 RES CHIP JUMPER
JU657 0611077A01 RES CHIP JUMPER
JU672 0611077A01 RES CHIP JUMPER
JU673 0611077A01 RES CHIP JUMPER
JU678 0611077A01 RES CHIP JUMPER
JU679 0611077A01 RES CHIP JUMPER
R608 0611077A01 RES CHIP JUMPER
R618 0611077A96 RES CHIP 8200 5 1/8
J5 0980159P02 CONNECTOR 25-PIN
J6 0980159P02 CONNECTOR 25-PIN
C750 2113740B65 CAP CHIP REEL CL1 +/-30
470
C751 2113740B65 CAP CHIP REEL CL1 +/-30
470
C752 2113740B65 CAP CHIP REEL CL1 +/-30
470
C754 2113740B65 CAP CHIP REEL CL1 +/-30
470
C755 2113740B65 CAP CHIP REEL CL1 +/-30
470
C756 2113740B65 CAP CHIP REEL CL1 +/-30
470
C757 2113740B65 CAP CHIP REEL CL1 +/-30
470
C758 2113740B65 CAP CHIP REEL CL1 +/-30
470
C765 2113740B65 CAP CHIP REEL CL1 +/-30
470
C767 2113740B65 CAP CHIP REEL CL1 +/-30
470
C768 2113740B65 CAP CHIP REEL CL1 +/-30
470
C772 2113740B65 CAP CHIP REEL CL1 +/-30
470
C773 2113740B65 CAP CHIP REEL CL1 +/-30
470
Reference
Designator
Motorola
Part Number
Description
C774 2113740B65 CAP CHIP REEL CL1 +/-30
470
C779 2113740B65 CAP CHIP REEL CL1 +/-30
470
C780 2113740B65 CAP CHIP REEL CL1 +/-30
470
C790 2113740B65 CAP CHIP REEL CL1 +/-30
470
P506 2880068M01 HEADER MIC
P502 2885361E01 CONN 38 PIN MALE (RM
CH)
VR675 4805656W03 DIODE DUAL 5.6V ZENER
VR614 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR615 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR616 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR617 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR600 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR601 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR602 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR603 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR604 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR605 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR606 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR607 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR608 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR609 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR610 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR611 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR612 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
Reference
Designator
Motorola
Part Number
Description
VR613 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR618 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR619 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR620 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR621 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR622 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR623 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR673 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
VR674 4813830C31 DIODE 18V 'J3'
MMSZ5248BT1
C732 NOTPLACED
C753 NOTPLACED
C759 NOTPLACED
C760 NOTPLACED
C761 NOTPLACED
C762 NOTPLACED
C763 NOTPLACED
C764 NOTPLACED
C766 NOTPLACED
C769 NOTPLACED
C770 NOTPLACED
C771 NOTPLACED
C776 NOTPLACED
C777 NOTPLACED
C778 NOTPLACED
C781 NOTPLACED
C783 NOTPLACED
C785 NOTPLACED
C786 NOTPLACED
C789 NOTPLACED
C791 NOTPLACED
C792 NOTPLACED
C793 NOTPLACED
C794 NOTPLACED
C795 NOTPLACED
Reference
Designator
Motorola
Part Number
Description
