8-12 Interconnect Boards Schematics, Component Location Diagrams, and Parts Lists: Remote Interconnect Boards (Mid Power Only)
May 25, 2005 6881096C74-B
VR616 4805656W10 DIODE DUAL 15 VOLT
ZENER (GALAXY) I600
VR615 4805656W10 DIODE DUAL 15 VOLT
ZENER (GALAXY) I600
Q602 4813821A09 TSTR P-CH 60V 12A
_2955_
VR600 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR602 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR604 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR606 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR608 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR674 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR673 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR672 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR627 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR625 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR624 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR623 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR622 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR621 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR620 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR619 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR618 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR613 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR612 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR611 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
Reference
Designator
Motorola
Part Number
Description
VR610 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR609 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR607 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR605 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR603 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
VR601 4813830C31 DIODE 18V ‘J3’
MMSZ5248BT1
Q603 4885316E17 XSTR,POWER MOSFET
30V,2.5A,SINGLE
Q606 4885316E17 XSTR,POWER MOSFET
30V,2.5A,SINGLE
Q604 4885316E17 XSTR,POWER MOSFET
30V,2.5A,SINGLE
U601 5113806A05 IC FLIP-FLOP,DUAL D
U603 5113816A19 IC ASJ LO DROPOUT POS
REG .8A
U602 5113818A06 IC LOW PWR SING SPLY
MC33172DR
C776 NOTPLACED 64AM DUMMY PART NUM-
BER
C777 NOTPLACED 64AM DUMMY PART NUM-
BER
C778 NOTPLACED 64AM DUMMY PART NUM-
BER
C786 NOTPLACED 64AM DUMMY PART NUM-
BER
C793 NOTPLACED 64AM DUMMY PART NUM-
BER
C795 NOTPLACED 64AM DUMMY PART NUM-
BER
D600 NOTPLACED 64AM DUMMY PART NUM-
BER
D605 NOTPLACED 64AM DUMMY PART NUM-
BER
F600 NOTPLACED 64AM DUMMY PART NUM-
BER
GS1 NOTPLACED 64AM DUMMY PART NUM-
BER
GS2 NOTPLACED 64AM DUMMY PART NUM-
BER
JU10 NOTPLACED 64AM DUMMY PART NUM-
BER
Reference
Designator
Motorola
Part Number
Description
JU11 NOTPLACED 64AM DUMMY PART NUM-
BER
JU12 NOTPLACED 64AM DUMMY PART NUM-
BER
JU601 NOTPLACED 64AM DUMMY PART NUM-
BER
JU603 NOTPLACED 64AM DUMMY PART NUM-
BER
JU605 NOTPLACED 64AM DUMMY PART NUM-
BER
JU610 NOTPLACED 64AM DUMMY PART NUM-
BER
JU611 NOTPLACED 64AM DUMMY PART NUM-
BER
JU612 NOTPLACED 64AM DUMMY PART NUM-
BER
JU614 NOTPLACED 64AM DUMMY PART NUM-
BER
JU615 NOTPLACED 64AM DUMMY PART NUM-
BER
JU617 NOTPLACED 64AM DUMMY PART NUM-
BER
JU624 NOTPLACED 64AM DUMMY PART NUM-
BER
JU625 NOTPLACED 64AM DUMMY PART NUM-
BER
JU627 NOTPLACED 64AM DUMMY PART NUM-
BER
JU628 NOTPLACED 64AM DUMMY PART NUM-
BER
JU629 NOTPLACED 64AM DUMMY PART NUM-
BER
JU630 NOTPLACED 64AM DUMMY PART NUM-
BER
JU631 NOTPLACED 64AM DUMMY PART NUM-
BER
JU636 NOTPLACED 64AM DUMMY PART NUM-
BER
JU643 NOTPLACED 64AM DUMMY PART NUM-
BER
JU644 NOTPLACED 64AM DUMMY PART NUM-
BER
JU645 NOTPLACED 64AM DUMMY PART NUM-
BER
JU651 NOTPLACED 64AM DUMMY PART NUM-
BER
Reference
Designator
Motorola
Part Number
Description
JU653 NOTPLACED 64AM DUMMY PART NUM-
BER
JU655 NOTPLACED 64AM DUMMY PART NUM-
BER
JU657 NOTPLACED 64AM DUMMY PART NUM-
BER
JU658 NOTPLACED 64AM DUMMY PART NUM-
BER
JU671 NOTPLACED 64AM DUMMY PART NUM-
BER
JU674 NOTPLACED 64AM DUMMY PART NUM-
BER
JU675 NOTPLACED 64AM DUMMY PART NUM-
BER
JU677 NOTPLACED 64AM DUMMY PART NUM-
BER
JU700 NOTPLACED 64AM DUMMY PART NUM-
BER
JU800 NOTPLACED 64AM DUMMY PART NUM-
BER
Q605 NOTPLACED 64AM DUMMY PART NUM-
BER
R600 NOTPLACED 64AM DUMMY PART NUM-
BER
R601 NOTPLACED 64AM DUMMY PART NUM-
BER
R602 NOTPLACED 64AM DUMMY PART NUM-
BER
R603 NOTPLACED 64AM DUMMY PART NUM-
BER
R604 NOTPLACED 64AM DUMMY PART NUM-
BER
R605 NOTPLACED 64AM DUMMY PART NUM-
BER
R606 NOTPLACED 64AM DUMMY PART NUM-
BER
R607 NOTPLACED 64AM DUMMY PART NUM-
BER
R612 NOTPLACED 64AM DUMMY PART NUM-
BER
R613 NOTPLACED 64AM DUMMY PART NUM-
BER
R614 NOTPLACED 64AM DUMMY PART NUM-
BER
R670 NOTPLACED 64AM DUMMY PART NUM-
BER
U600 NOTPLACED 64AM DUMMY PART NO.
Reference
Designator
Motorola
Part Number
Description
