3-32 Theory of Operation: Transmitter
First Stage
The RFPA first stage provides gain that is determined by the control voltage, RFPA_CNTRL. This
control voltage is generated in the power control section and is a function of the final-stage output
power, temperature, and current, as well as the control and A+ voltage levels. See “3.6.2.4. Power
Control (for 40W and 100W Transmitter)” on page 3-35 for a detailed explanation of the power
control section.
The 0.5 mW TX_INJ signal is routed to the U5501 first stage device (Pin 16, RFIN) via C5508 to an
integrated, wide-band input match. U5501 is a two-stage LDMOS device with a bandpass interstage
match consisting of L5503, C5507, and C5509 routed between VD1 (pin 14) and G2 (pin 11). L5502
and L5505 provide the K9.1V drain bias voltage for the first and second stages to VD1 (pin 14) and
RFOUT1/2 (pins 6 and 7), respectively. The RFPA_CNTRL gate bias is provided to both stages
internally via VCNTRL (pin 1). Both U5501 stages are operated Class A and the second-stage output
power is approximately 250 mW.
Driver Stage
C5566, C5516, C5518 and a transmission line form a low-pass, interstage match that transfers
power to the Q5502 LDMOS transistor. R5511-R5515 provide device stability, and R5527, C5556,
C5525 and R5516 supply the VGBIAS3 gate bias. L5508, C5527, R5517, E5501 and C5526 form
the 9.3 V drain bias circuit. The 9.3 V drain voltage is supplied from regulator U5570 via R5574. The
9.3 V supply to the driver is only present during transmit and is disabled during receive via the K9.1V
signal and Q5570. Q5502 is operated Class AB and its output power is approximately 3.5 W.
Final Stage
C5559, C5560, C5535, C5538, and transmission lines form a low pass, splitter match that transfers
power to the LDMOS final-stage transistor Q5503. Q5503 contains two transistors in a single
package, each with it's own gate and drain lead. R5530, R5533, R5534 and R5536 provide stability
for Q5503. R5525, C5557, C5539 and R5520 supply the VGBIAS1 gate bias to Q5503-7. R5526,
C5558, C5540 and R5521 supply the VGBIAS2 gate bias to Q5503-6. L5510, C5549, R5523, E5502
and C5550 form the A+ drain bias circuit to Q5503-2 and Q5503-3. C5542-43, C5545-46, C5547-48,
C5551-53 and transmission lines form a low -pass combiner match that transfers approximately 51
W to the antenna switch. R5535 provides stability for Q5503. Q5503 operates Class AB.
R5522 and U5503 comprise the final-stage, current-sense circuit that generates the VCURRENT
voltage proportional to the final stage current. R5519 sets the circuit gain. U5502 generates the
VTEMP voltage, which is proportional to the final-stage temperature.
