February 14, 2012 6816985H01-F

8.1-14 VHF Troubleshooting Tables: Tables

D12 TCK TCK ONCE/JTAG Yes

C13 TMS TMS ONCE/JTAG Yes

E11 TRST TRST ONCE/JTAG Yes

A14 TDO TDO ONCE/JTAG Yes

E12 TDI TDI ONCE/JTAG Yes

M16 NOT USED No

L14 NOT USED No

P15 NOT USED No

L11 NOT USED No

M14 NOT USED No

N16 NOT USED No

L12 NOT USED No

M12 CKO CKO Disabled Yes

N15 NOT USED No

M15 NOT USED No

R12 ADDRESS 0 J601, pin 7 Yes

T13 ADDRESS 1 No

M10 ADDRESS 2 No

T12 ADDRESS 3 No

P13 ADDRESS 4 No

M9 ADDRESS 5 No

P10 ADDRESS 6 No

P12 ADDRESS 7 No

N9 ADDRESS 8 No

R10 ADDRESS 9 No

P9 ADDRESS 10 No

L10 ADDRESS 11 No

T10 ADDRESS 12 No

R9 ADDRESS 13 No

L9 ADDRESS 14 No

K9 ADDRESS 15 No

Table 8.1-5. Patriot MCU/DSP (U800) Pinout (Continued)

U800 Pin

Number

Description To/From Comment

Accessible on

Main Board?
