6816985H01-F February 14, 2012

VHF Troubleshooting Tables: Tables 8.1-15

J9 ADDRESS 16 No

L8 ADDRESS 17 No

M8 ADDRESS 18 No

N8 ADDRESS 19 No

K8 ADDRESS 20 No

L7 ADDRESS 21 No

T7 ADDRESS 22 No

R7 ADDRESS 23 R814 Yes

R3 DATA 15 No

T3 DATA 14 No

N4 DATA 13 No

P4 DATA 12 No

R4 DATA 11 No

J8 DATA 10 No

T4 DATA 9 No

N5 DATA 8 No

P5 DATA 7 R644 Yes

R5 DATA 6 R643 Yes

T5 DATA 5 R642 Yes

R6 DATA 4 R641 Yes

T6 DATA 3 R640 Yes

M7 DATA 2 R639 Yes

N7 DATA 1 R638 Yes

P7 DATA 0 R637 Yes

N11 R_W No

T11 NOT USED No

R14 NOT USED No

N12 CS3* No

T14 CS2 No

R11 NOT USED No

R15 CS0 TP_CS0 Active Low Yes

Table 8.1-5. Patriot MCU/DSP (U800) Pinout (Continued)

U800 Pin

Number

Description To/From Comment

Accessible on

Main Board?
