UHF1 Troubleshooting Tables: Tables 8.2-17

M11 RTS_FILLSEN_5V RTS 5V Yes

M12 ADC_VREF GND 5V Yes

M13 ATOD_1 VOLUME 5V Yes

N12 RXDIN_5V RS232_DI_USB- 5V Yes

N13 SB96_BUS_BUSY SB9600_BUSY 5V Yes

N6 USB1_DP RS232_D0_USB+ 5V Yes

N9 SB96_BDO_KF_5V LHDATA_KEYFAIL 5V Yes

P13 CTS_CABLE_DET_5V CTS 5V Yes

P7 USB1_DM RS232_DI_USB- 5V Yes

D7 VC_FSYNC CODEC_FSYNC 8KHz Yes

F1 INT_SPKR_P INT_SPKR_POS B+(7.5V) Yes

F2 INT_SPKR_M INT_SPKR_NEG B+(7.5V) Yes

G1 EXT_SPKR_M EXT_SPKR_NEG B+(7.5V) Yes

G2 PA_IN_P VC_OUT_P B+(7.5V) Yes

G3 PA_IN_M VC_OUT_M B+(7.5V) Yes

H1 EXT_SPKR_P EXT_SPKR_POS B+(7.5V) Yes

H2 VC_OUT_M PA_IN_N B+(7.5V) Yes

H3 VC_OUT_P PA_IN_P B+(7.5V) Yes

A3 TEST GND GND No

C4 SCAN_EN GND GND No

E8 VFUSE GND GND No

B11 AD_TRIG ADTRIG NA No

B6 SPI_DI SPI_MOSIB NA No

C6 SPI_DO SPI_MISOB NA No

A11 TX_RX NC NC No

B12 OPTION_INTX NC NC No

B7 VC_TX NC NC No

C10 USB_INTX NC NC No

C11 OPT_GPIO1 NC NC No

D11 OPT_GPIO3 NC NC No

Table 8.2-6. MAKO (U701) Pinout (Continued)

Pin Ref

Number

U701 Pin Name To/From Comment

Accessible

on Main

Board?
