February 14, 2012 6816985H01-F

8.2-18 UHF1 Troubleshooting Tables: Tables

F10 OPT_GPIO0 NC NC No

G10 OPT_GPIO2 NC NC No

J5 TXDO_BDI_UP_3V TXDO_BDI_ENC_3V NC No

K12 ATOD_7 NC NC No

K13 ATOD_8 NC NC No

K6 TXDO_BDI_ENC_3V TXDO_BDI_UP_3V NC No

K7 OPTA_SEL1 NC NC No

K8 OPTB_SEL1 NC NC No

L3 FE_TUNE1 NC NC No

M14 ATOD_3 NC NC No

M2 FE_TUNE2 NC NC No

M3 RTS_FILLSEN_3V NC NC No

M8 ONE_WIRE_2 NC NC No

M9 OPTA_SEL2 NC NC No

N1 PWR_CTRL NC NC No

N10 OPTA_SEL3 NC NC No

N11 OPTB_SEL3 NC NC No

N2 RXDIN_ENC_3V RXDIN_3V NC No

N7 USB2_DP NC NC No

N8 SB96D_BDO_KF_3V UART2_RXD_OD NC No

P10 OPTA_SEL0 NC NC No

P11 OPTB_SEL0 NC NC No

P12 OPTB_SEL2 NC NC No

P2 RXDIN_3V RXDIN_ENC_3V NC No

P8 USB2_DM NC NC No

E1 PA_BPLUS SW_B+ SW_B+(7.5V) Yes

E3 BPLUS BPLUS UNSW_B+(7.5V) No

A7 VC_RX CODEC_RX V1.55(1.6V) Yes

A6 LOGIC_VDD V2.9 V2.9 No

A8 RS232_USB_X RS232_USB_X V2.9 Yes

Table 8.2-6. MAKO (U701) Pinout (Continued)

Pin Ref

Number

U701 Pin Name To/From Comment

Accessible

on Main

Board?
