6816985H01-F February 14, 2012
UHF1 Troubleshooting Tables: Tables 8.2-19
K11 ATOD_6 V2.9 V2.9 Yes
L13 ATOD_5 V2.9 V2.9 Yes
L5 APCO V2.9 V2.9 Yes
M4 VC_TX3V CODEC_TX V2.9 Yes
N14 ATOD_0 V2.9 V2.9 No
L12 ATOD_4 BAT_STATUS VCC5(5V) Yes
A10 UART2_RXD_OD SB96D_BDO_KF_3V/
V2.9/URXD3
VDD(1.65–3.6V) Yes
A9 USB2_OE_RCV_RTS URTS1_XRXD VDD(1.65–3.6V) Yes
B10 CTS_X UCTS_USB_SPEED VDD(1.65–3.6V) Yes
B8 USB1_OE USB_TXENAB VDD(1.65–3.6V) Yes
B9 USB2_DAT_VP USB_VPI VDD(1.65–3.6V) Yes
C12 BUSY_IN BUSY_IN_RTS VDD(1.65–3.6V) Yes
C7 BOOT_NORM_X BOOT_NORM_X VDD(1.65–3.6V) Yes
C8 USB1_DAT_TXD TXD1_USB_VPO VDD(1.65–3.6V) Yes
C9 USB2_SE0_VM_RXD URXD1_USB_VMI VDD(1.65–3.6V) Yes
D10 CABLE_DET_3V KVL_USB_DET VDD(1.65–3.6V) Yes
D6 SPI_CS MAKO_CE VDD(1.65–3.6V) Yes
D8 USB1_SE0 USB_VMO VDD(1.65–3.6V) Yes
E11 BUSY_OUT BUSY_OUT_CTS VDD(1.65–3.6V) Yes
E6 SPI_CLK SCKB VDD(1.65–3.6V) Yes
E9 UART2_TXD UTXD2 VDD(1.65–3.6V) Yes
L7 ONE_WIRE_UP ONE_WIRE_UP/V2.9 VDD(1.65–3.6V) Yes
POWER MANAGE-
MENT BLOCK
B2 BAT_TYPE GND 0–5V Yes
D2 BAT_3V6 GND 0–5V Yes
D3 REG_3V6 GND 0–5V Yes
G4 HV_BG GND 1.2V Yes
M1 TXCO_IN 16_8MHz 16.8MHz (2.5–3.3V) Yes
J13 SW2_VOUT GND 2.3V Yes
Table 8.2-6. MAKO (U701) Pinout (Continued)
Pin Ref
Number
U701 Pin Name To/From Comment
Accessible
on Main
Board?
To Next Page
