6816985H01-F February 14, 2012

UHF1 Troubleshooting Tables: Tables 8.2-21

M7 GND2 GND GND No

P5 GND1 GND GND No

B13 VBUS_SUPPLY NC NC No

B4 IGN_X NC NC No

C13 VBUS2_CMD NC NC No

C14 VBUS1_CMD NC NC No

D12 VBUS2 NC NC No

D13 SW5_VDD NC NC No

E12 VBUS1_SENS NC NC No

E13 SW5_SUMCOMP NC NC No

E14 SW5_VSENSE NC NC No

F11 VBUS2_SENS NC NC No

F12 SW5_VOUT NC NC No

F13 SW5_VDDHV NC NC No

F4 EMERG_PB NC NC No

G11 SW5_PHASE NC NC No

H10 VBUS1 NC NC No

H13 SW1_DH NC NC No

J11 SW1_VSEN_BST NC NC No

NC1 NC1 NC NC No

NC2 NC2 NC NC No

NC3 NC3 NC NC No

NC4 NC4 NC NC No

NC5 NC5 NC NC No

NC6 NC6 NC NC No

G12 SW1_VDDHV SW_B+ SW_B+(7.5V) Yes

H11 SW1_VSEN_BUK SW_B+ SW_B+(7.5V) Yes

K3 V08_I SW_B+ SW_B+(7.5V) Yes

D1 BAT_7V5 UNSW_B+ UNSW_B+(7.5V) Yes

P4 V03_O V1.55 V1.55(1.6V) Yes

Table 8.2-6. MAKO (U701) Pinout (Continued)

Pin Ref

Number

U701 Pin Name To/From Comment

Accessible

on Main

Board?

Motorola ATS 3000 User Manual
