February 14, 2012 6816985H01-F
8.2-22 UHF1 Troubleshooting Tables: Tables
N4 V02_O V1.875 V1.875 Yes
P3 V06_O V2.9 V2.9 Yes
C5 RESETX MAKO RESET VDD(1.65–3.6V) Yes
D5 INT_X MAKO_INT_X VDD(1.65–3.6V) Yes
G13 SW1_VDD Q702 VDD(1.65–3.6V) Yes
G14 SW1_SUMCOMP_DL Q702 VSW1 (3.6V) Yes
H12 SW1_VOUT VSW1 VSW1 (3.6V) No
J10 V10_I VSW1 VSW1 (3.6V) Yes
J12 SW2_VCC VSW1 VSW1 (3.6V) Yes
K14 SW2_VCCS VSW1 VSW1 (3.6V) Yes
Table 8.2-6. MAKO (U701) Pinout (Continued)
Pin Ref
Number
U701 Pin Name To/From Comment
Accessible
on Main
Board?
