Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-29
6816985H01-F February 14, 2012
PMLD4303A/ PMLD4303D/ PMUD2887A/
PMUD2888A/ PMUD2886A/ PMUD2885A/
PMUD3199A/ PMUD3183A/ PMUD3200A/
PMUD3184A Main Circuit Board
Electrical Parts List
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02
CONNECTOR (CONTACT
BATTERY)
C1 2115075H01 CAP CHIP 24PF 5% COG
C100 2113944C04 CAP CER CHP 330.0PF 50V
5%
C101 2113944C04 CAP CER CHP 330.0PF 50V
5%
C102 2113945A03 CAP CER CHP 330PF 50V 10%
C103 2113945B02 CAP CER CHP 10,000PF 25V
10%
C104 2113945A03 CAP CER CHP 330PF 50V 10%
C105 NOT PLACED –
C106 NOT PLACED –
C108 2113945B02 CAP CER CHP 10,000PF 25V
10%
C109 2113945B02 CAP CER CHP 10,000PF 25V
10%
C110 2113945B02 CAP CER CHP 10,000PF 25V
10%
C111 2113944C04 CAP CER CHP 330.0PF 50V
5%
C112 2113944C04 CAP CER CHP 330.0PF 50V
5%
C113 2113944C04 CAP CER CHP 330.0PF 50V
5%
C115 2113944M14 CAP,FXD,6.8PF,.1PF+/-,
50V-DC, 0603,C
C116 2113944M35 CAP,FXD,51PF,+2%,-2%,
50V-DC, 0603,C0
C118 2113944M33 CAP,FXD,43PF,+2%,-2%,
50V-DC, 0603,C0
C119 2113944M14 CAP,FXD,6.8PF,.1PF+/-,
50V-DC, 0603,C
C120 2113944C45 CAP CER CHP 100.0PF 50V
5%
C122 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,
C124 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC, 0805,C0
C125 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC, 0805,C0
C126 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC, 0805,C0
C127 2113944M09 CAP,FXD,4.3PF,.1PF+/-,
50V-DC,0603
C128 2113944F56 CAP,FXD,39PF,+5%,-5%,
50V-DC,0805,C0
C129 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603
C130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C131 2113945B02 CAP CER CHP 10,000PF 25V
10%
C135 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603
C140 2113945A03 CAP CER CHP 330PF 50V 10%
C141 2113944C04 CAP CER CHP 330.0PF 50V
5%
C142 2313960B01 CAP,FXD,1UF,+10%,-10%,
16V-DC, SM,-5
C143 2113945A10 CAP CER CHP 1500PF 50V
10%
C144 2113945A05 CAP CER CHP 470PF 50V 10%
C145 2113945B03 CAP,FXD,.015UF,+10%,-10%,
25V-DC,040
C146 2113946K02 CAP CER CHP 0.10UF 16V
C147 2313960B01 CAP,FXD,1UF,+10%,-10%,
16V-DC, SM,-5
C148 2113944A40 CAP CER CHP 100.0PF 50V
5%
C149 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C15 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,
C16 2115075H01 CAP CHIP 24PF 5% COG
C17 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,
C170 2113944M27 CAP,FXD,24PF,+2%,-2%,
50V-DC, 0603,C
C171 2113944C45 CAP CER CHP 100.0PF 50V
5%
C172 2113944M16 CAP,FXD,8.2PF,.1PF+/-,
50V-DC, 0603,C
C173 2113944M29 CAP,FXD,30PF,+2%,-2%,
50V-DC, 0603,C
C174 2113944M13 CAP,FXD,6.2PF,.1PF+/-,
50V-DC,0603,C
C175 2113944M28 CAP,FXD,27PF,+2%,-2%,
50V-DC, 0603,C0
C176 2113944M20 CAP,FXD,12PF,+2%,-2%,
50V-DC,0603,C0
C177 2113944M24 CAP,FXD,18PF,+2%,-2%,
50V-DC,0603,C0
C178 2113944A28 CAP CER CHP 18.0PF 50V 5%
C179 2113944C04 CAP CER CHP 330.0PF 50V
5%
C18 2113945A03 CAP CER CHP 330PF 50V 10%
C180 NOT PLACED –
C181 NOT PLACED –
C182 2113944C04 CAP CER CHP 330.0PF 50V
5%
C185 2113945B02 CAP CER CHP 10,000PF 25V
10%
C186 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C187 2113944C04 CAP CER CHP 330.0PF 50V
5%
C188 2113945A03 CAP CER CHP 330PF 50V 10%
C189 2113945A03 CAP CER CHP 330PF 50V 10%
C190 2113945A05 CAP CER CHP 470PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C191 NOT PLACED –
C2 2113944A42 CAP CER CHP 150.0PF 50V
5%
C20 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C200 2113945A13 CAP CER CHP 4700PF 50V
10%
C201 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C202 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,060
C203 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,060
C204 2109720D20 CAP CHIP LOW DIST 2000
SOV
C206 2113946K02 CAP CER CHP 0.10UF 16V
C207 2113946K02 CAP CER CHP 0.10UF 16V
C208 2113946K02 CAP CER CHP 0.10UF 16V
C209 2113946K02 CAP CER CHP 0.10UF 16V
C210 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,12
C211 2113946K02 CAP CER CHP 0.10UF 16V
C212 2113945A03 CAP CER CHP 330PF 50V 10%
C213 2113946K02 CAP CER CHP 0.10UF 16V
C214 2113945B02 CAP CER CHP 10,000PF 25V
10%
C215 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113945A03 CAP CER CHP 330PF 50V 10%
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,12
C22 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C220 2113945B02 CAP CER CHP 10,000PF 25V
10%
C221 2113945A03 CAP CER CHP 330PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
