Motorola ATS 3000

9.1-30 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C222 2313960D07 CAP,FXD,10,+10,-10,16,SM,-
55MIN,12
C223 2113945A03 CAP CER CHP 330PF 50V 10%
C226 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC ,0603,
C227 2113945L13 CAP,FXD,330PF,+5%,-5%,50V-
DC, 0603,X
C228 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,
C229 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,
C230 2113946K02 CAP CER CHP 0.10UF 16V
C231 2113945A01 CAP CER CHP 220PF 50V 10%
C232 2113946K02 CAP CER CHP 0.10UF 16V
C233 2113946K02 CAP CER CHP 0.10UF 16V
C234 2113945A03 CAP CER CHP 330PF 50V 10%
C235 2113944A40 CAP CER CHP 100.0PF 50V
5%
C236 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C237 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C238 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C239 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C240 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C243 2113946K02 CAP CER CHP 0.10UF 16V
C245 2113944A40 CAP CER CHP 100.0PF 50V
5%
C246 2113946N03 CAP CER CHP 2.2UF 16V
C247 2113945A09 CAP CER CHP 1000PF 50V
10%
C248 NOT PLACED –
C249 2113945A09 CAP CER CHP 1000PF 50V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C25 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C252 2113944C78 CAP,FXD,13PF,+5%,-5%,
50V-DC,0603,C0
C253 2113944C78 CAP,FXD,13PF,+5%,-5%,
50V-DC,0603,C0
C254 2113944C18 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C255 2113944C63 CAP,FXD,1PF,.1PF+/-,50V-DC,
0603,C0G
C256 2113945L13 CAP,FXD,330PF,+5%,-5%,
50V-DC,0603,X
C257 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C258 2113945A03 CAP CER CHP 330PF 50V 10%
C261 2113945A03 CAP CER CHP 330PF 50V 10%
C262 2113945A03 CAP CER CHP 330PF 50V 10%
C263 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC,0402,C
C266 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C267 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC, 0402,C
C271 2113944C32 CAP CER CHP 15.0PF 50V 5%
C272 2113944C32 CAP CER CHP 15.0PF 50V 5%
C273 2188881Y12 CAP,CERAMIC CHIP,1.8PF,
.1PF +/-,16
C274 2113944V03 CAP,FXD,1PF,.1PF+/-,50V-DC
,0402,C0G
C275 2113945A03 CAP CER CHP 330PF 50V 10%
C276 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC, 0402,C
C277 2113945A03 CAP CER CHP 330PF 50V 10%
C278 2113944A18 CAP CER CHP 5.1PF 50V
+/- 0.5PF
C279 2113945A03 CAP CER CHP 330PF 50V 10%
C286 2113945A03 CAP CER CHP 330PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C292 2113945A03 CAP CER CHP 330PF 50V 10%
C293 2113945A03 CAP CER CHP 330PF 50V 10%
C294 2113945A03 CAP CER CHP 330PF 50V 10%
C295 2113945B02 CAP CER CHP 10,000PF 25V
10%
C296 2113945A09 CAP CER CHP 1000PF 50V
10%
C30 2113944A21 CAP CER CHP 6.8PF 50V +/-
0.5PF
C33 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C35 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C400 2113944A40 CAP CER CHP 100.0PF 50V
5%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C405 2113944A40 CAP CER CHP 100.0PF 50V
5%
C41 2115075H01 CAP CHIP 24PF 5% COG
C411 2113945A11 CAP CER CHP 2200PF 50V
10%
C412 NOT PLACED –
C416 2113946K02 CAP CER CHP 0.10UF 16V
C417 2113944A40 CAP CER CHP 100.0PF 50V
5%
C421 NOT PLACED –
C422 2113945B02 CAP CER CHP 10,000PF 25V
10%
C423 2113944C41 CAP CER CHP 68.0PF 50V 5%
C424 2113944A40 CAP CER CHP 100.0PF 50V
5%
C425 2113945H69 CAP,FXD,.1UF,+5%,-5%,
50V-DC,1206,X
C428 2113944A29 CAP CER CHP 22.0PF 50V 5%
C429 2113946K02 CAP CER CHP 0.10UF 16V
C43 2113944A42 CAP CER CHP 150.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C430 2113946K02 CAP CER CHP 0.10UF 16V
C431 2113946K02 CAP CER CHP 0.10UF 16V
C432 2113946K02 CAP CER CHP 0.10UF 16V
C433 2113944C33 CAP CER CHP 18.0PF 50V 5%
C434 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,060
C435 2113944A36 CAP CER CHP 68.0PF 50V 5%
C436 2113944A40 CAP CER CHP 100.0PF 50V
5%
C437 2113944C85 CAP,FXD,51PF,+5%,-5%
50V-DC,0603,C0
C438 2113944C40 CAP CER CHP 62.0PF 50V 5%
C44 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C440 2113945G96 CAP,FXD,.33UF,+10%,-10%,
50V-DC,0805
C441 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC,SM,-5
C442 2113945B02 CAP CER CHP 10,000PF 25V
10%
C447 NOT PLACED –
C448 2113945C25 CAP,FXD,.033UF,+10%,-10%,
50V-DC,060
C449 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC,0402,C0
C46 2113946Q01 CAP CER CHP 4.7UF 16V
C461 2113946K02 CAP CER CHP 0.10UF 16V
C463 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,060
C464 2113946K02 CAP CER CHP 0.10UF 16V
C465 2113946K02 CAP CER CHP 0.10UF 16V
C47 2115075H01 CAP CHIP 24PF 5% COG
C470 2113946K02 CAP CER CHP 0.10UF 16V
C472 2113946K02 CAP CER CHP 0.10UF 16V
C473 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
