Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-31
6816985H01-F February 14, 2012
C475 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C476 2113944C89 CAP,FXD,200PF,+5%,-5%,
50V-DC,0603,C
C478 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,060
C48 2113944A42 CAP CER CHP 150.0PF 50V
5%
C480 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC,SM,-5
C481 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC,SM,
C482 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC,SM,
C500 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C501 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C502 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C503 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C504 2113945A03 CAP CER CHP 330PF 50V 10%
C505 2113945G98 CAP,FXD,.47UF,+10%,-10%
,50V-DC,0805
C506 2113946E02 CAP CER CHP 1.0UF 16V 10%
C507 2113945B02 CAP CER CHP 10,000PF 25V
10%
C508 2113945B02 CAP CER CHP 10,000PF 25V
10%
C509 2113945B02 CAP CER CHP 10,000PF 25V
10%
C510 2113946K02 CAP CER CHP 0.10UF 16V
C511 2113946K02 CAP CER CHP 0.10UF 16V
C512 2113946K02 CAP CER CHP 0.10UF 16V
C513 2113955E11 CAP,FXD,1UF,+10%,-10%,50V
C514 2113955E11 CAP,FXD,1UF,+10%,-10%,50V
C516 2113946E02 CAP CER CHP 1.0UF 16V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C517 2113946E02 CAP CER CHP 1.0UF 16V 10%
C518 2313960B57 CAP,FXD,10UF,+10%,-10%,
6.3V-DC,SM,-
C519 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C520 2113945A05 CAP CER CHP 470PF 50V 10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2313960H04 CAP,FXD,33UF,+10%,-
10%,16V-DC ,SM,-5
C525 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603
C526 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C527 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C528 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C550 2113945B02 CAP CER CHP 10,000PF 25V
10%
C551 2113945B02 CAP CER CHP 10,000PF 25V
10%
C56 2113946B04 CAP CER CHP 0.10UF 10V
10%
C57 2113944C33 CAP CER CHP 18.0PF 50V 5%
C58 NOT PLACED –
C59 2113944A28 CAP CER CHP 18.0PF 50V 5%
C60 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C607 2113946K02 CAP CER CHP 0.10UF 16V
C61 2113945A03 CAP CER CHP 330PF 50V 10%
C610 2113944A32 CAP CER CHP 39.0PF 50V 5%
C611 2113944A32 CAP CER CHP 39.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C612 2113944A32 CAP CER CHP 39.0PF 50V 5%
C613 2113944A32 CAP CER CHP 39.0PF 50V 5%
C614 2113945A03 CAP CER CHP 330PF 50V 10%
C615 2113944A32 CAP CER CHP 39.0PF 50V 5%
C617 2113944A32 CAP CER CHP 39.0PF 50V 5%
C619 2113944A32 CAP CER CHP 39.0PF 50V 5%
C62 2113944A26 CAP CER CHP 12.0PF 50V 5%
C620 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,
C621 2113946K02 CAP CER CHP 0.10UF 16V
C629 2113945A03 CAP CER CHP 330PF 50V 10%
C63 2113944A26 CAP CER CHP 12.0PF 50V 5%
C630 2113945A03 CAP CER CHP 330PF 50V 10%
C631 2113945A03 CAP CER CHP 330PF 50V 10%
C632 2113945A03 CAP CER CHP 330PF 50V 10%
C633 2113945A03 CAP CER CHP 330PF 50V 10%
C634 2113945A03 CAP CER CHP 330PF 50V 10%
C635 2113945A03 CAP CER CHP 330PF 50V 10%
C636 2113945A03 CAP CER CHP 330PF 50V 10%
C637 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,
C638 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,
C64 2113945A03 CAP CER CHP 330PF 50V 10%
C640 NOT PLACED –
C641 NOT PLACED –
C65 2113945A03 CAP CER CHP 330PF 50V 10%
C652 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C653 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C654 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C655 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C656 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C657 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C658 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C66 2113945A03 CAP CER CHP 330PF 50V 10%
C67 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C671 2113944A31 CAP CER CHP 33.0PF 50V 5%
C672 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C673 2113944A31 CAP CER CHP 33.0PF 50V 5%
C674 2113945A05 CAP CER CHP 470PF 50V 10%
C675 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C68 2113944A09 CAP CER CHP 2.2PF 50V +/-
0.25PF
C680 2113944A31 CAP CER CHP 33.0PF 50V 5%
C70 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402
C700 2113946B04 CAP CER CHP 0.10UF 10V
10%
C701 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C702 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C703 NOT PLACED –
C704 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C705 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C706 2113945A09 CAP CER CHP 1000PF 50V
10%
C708 2113944A31 CAP CER CHP 33.0PF 50V 5%
C709 2113944A31 CAP CER CHP 33.0PF 50V 5%
C71 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
