Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-33
6816985H01-F February 14, 2012
C9 2113944A42 CAP CER CHP 150.0PF 50V
5%
CR800 4813978A25 DIODE, SCHOTTKY 30V
SOD-323 T&R
CR801 4813978A25 DIODE, SCHOTTKY 30V
SOD-323 T&R
D10 4815096H01 VARACTOR DIODE 1SV305
D104 4816487H01 DIODE MMBD7000
D11 4815096H01 VARACTOR DIODE 1SV305
D12 4815096H01 VARACTOR DIODE 1SV305
D13 4815096H01 VARACTOR DIODE 1SV305
D170 4802482J02 PIN DIODE SMD
D171 4802482J02 PIN DIODE SMD
D172 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.
D173 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.
D20 4808115L27 DIODE ARRAY
D201 4815011H01 DIODE TRIPLE
D202 4815011H01 DIODE TRIPLE
D251 4813974A01 VARACTOR 3V DUAL
D252 4813974A01 VARACTOR 3V DUAL
D270 4813974A01 VARACTOR 3V DUAL
D3 4815096H01 VARACTOR DIODE 1SV305
D4 4815096H01 VARACTOR DIODE 1SV305
D401 4805656W87 DIODE,VCTR, @ 15V, 1SV279,
SOD-523/S
D402 4805656W41 DIODE VARACTOR 40PF@1V
15PF@3V
D5 4815096H01 VARACTOR DIODE 1SV305
D500 4815155H01 RECTIFIER
D501 4809118D02 LED BICOLOR
LNJ115W8POMT
D510 4813978M15 DIODE,RECT,RM140,SM,1A,
40V, SHTK,PB-
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D511 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V
D512 4813978M15 DIODE,RECT,RM140,SM,1A,
40V, SHTK,PB-
D513 4813978M15 DIODE,RECT,RM140,SM,1A,
40V, SHTK,PB-
D6 4815096H01 VARACTOR DIODE 1SV305
D600 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V
D603 4813978A25 DIODE, SCHOTTKY 30V
SOD-323 T&R
D662 4813978A25 DIODE, SCHOTTKY 30V
SOD-323 T&R
D700 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V
E102 2480574F01 CHIP INDUCTOR,BEAD,25%,
200MA,FERR,S
E140 2405688Z01 INDUCTOR FERRITE BEAD
E141 2480574F01 CHIP INDUCTOR,BEAD,25%,
200MA,FERR,S
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20
E800 2480574F01 CHIP INDUC-
TOR,BEAD,25%,200MA,FERR,
S
E801 2480574F01 CHIP INDUC-
TOR,BEAD,25%,200MA,FERR,
S
E802 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
F500 6515076H01 FUSE CHIP SMT TR/1608FF
3A
FL200 9116848H01 FLTR SW CAP 3 POLE
BUTTERW
FL51 9185367C01 XTAL FLTR 5X7 SURFACE MT
MONO
J101 2880658Z08 CONNECTOR, SMA
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L101 2414017N10 IND CER CHIP 6.8 NH 5%
L106 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28
L114 2414032B60 IDCTR,WW,390NH,5%,620MA,
1.12OHM,CER
L115 2460591B80 COIL AIR WOUND INDUC
19.61
L117 2414017N18 IND CER CHIP 33.0 NH 5%
L118 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
L119 2479990E01 COIL AIR WOUND/GREEN
CLR 23.75
L12 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,4
L120 NOT PLACED –
L121 NOT PLACED –
L125 2479990A02 AIR WND COIL/GREEN
COLOR7.66NH
L126 2415428H01 IDCTR,1.65NH,10%,SM
L127 2479990E01 COIL AIR WOUND/GREEN
CLR 23.75
L128 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28
L170 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L171 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L172 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L176 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L20 2414032F38 IDCTR,WW,220NH,5%,400MA,
.7OHM,CER,3
L200 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L201 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FER
L202 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FER
L203 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FER
L204 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FER
L205 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,
L206 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FER
L21 2414032F31 IDCTR,WW,56NH,5%,500MA,
.34OHM,CER,4
L251 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28
L252 2414032D30 IDCTR,WW,1UH,5%,320MA
2.8OHM,CER,28
L253 2460591C35 COIL AIR WOUND INDUC
18.08
L254 2460591C03 COIL AIR WOUND INDUC
11.87
L257 0613958T74 CER CHIP RES 0.0 OHM JMP
1206
L258 2414032D17 IDCTR,WW,150NH,5%,750MA
,.31OHM,CER,
L259 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28
L266 2414032D18 IDCTR,WW,180NH,5%,700MA,
.43OHM,CER,
L270 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28
L271 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28
L272 2414032B48 IDCTR,WW,39NH,5%,1A,
.15OHM,CER,5
L273 2414032B46 IDCTR,WW,27NH,5%,1A,
.13OHM,CER,50Q,
L274 2414032D40 IDCTR,WW,33NH,5%,1A,
.11OHM,CER,4
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
