Motorola ATS 3000

9.1-34 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
L28 2414032F26 IDCTR,WW,22NH,5%,500MA,
.22OHM,CER,
L31 2414032F34 IDCTR,WW,100NH,5%,400MA,
.46OHM,CER
L34 2414032F35 IDCTR,WW,120NH,5%,400MA,
.51OHM,CER,
L403 2414032B75 IDCTR,WW,3.9UH,5%,340MA,
3.6OHM,CER,
L404 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER
L407 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20
L411 2466505A01 COIL INDUCTOR
L412 2466505A01 COIL INDUCTOR
L413 2414032B64 IDCTR,WW,680NH,5%,540MA,
1 .47OHM,CER
L414 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FER
L42 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,4
L45 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,
L47 2414032F33 IDCTR,WW,82NH,5%,400MA,
.42OHM,CER,4
L48 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,
L49 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,4
L5 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,4
L500 2414017Q42 IDCTR,FXD,390NH,10%,200M
A, .65OHM,FE
L501 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FER
L502 2489669V01 CHIP IND 100000 NH 10%
L54 2414032F73 IDCTR,WW,820NH,5%,180MA,
2.23OHM,CER
L55 0613958T74 CER CHIP RES 0.0 OHM JMP
1206
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L56 2414032D25 IDCTR,WW,620NH,5%,400MA,
1.6OHM,CER
L6 2414032F27 IDCTR,FXD,27NH,5%,500MA
,.25OHM,CER,
L60 2414017G13 IDCTR,CHIP,33NH,5%,300MA,
.65OHM,CER
L61 2414017N16 IDCTR,CHIP,22NH,5%,600MA,
.54OHM,CER
L62 2414017N16 IDCTR,CHIP,22NH,5%,600MA,
.54OHM,CER
L63 2414017Q40 IDCTR,FXD,270NH,10%,
250MA,.5OHM,FER
L64 NOT PLACED –
L651 2414032F75 IDCTR,CHIP,270NH,2%,350MA
,1OHM,CER,
L652 2414032F75 IDCTR,CHIP,270NH,2%,350MA
,1OHM,CER,
L7 2414032F33 IDCTR,WW,82NH,5%,400MA,
.42OHM,CER,4
L701 2486085A01 IDCTR,22UH,20%,SHLD
L702 2486085A01 IDCTR,22UH,20%,SHLD
L703 2464675H01 IDCTR,WW,560NH,5%,550MA
L704 2464675H01 IDCTR,WW,560NH,5%,550MA
L705 2464675H01 IDCTR,WW,560NH,5%,550MA
L708 2416307H01 IDCTR,WW,680NH,5%,0603
L710 2416307H01 IDCTR,WW,680NH,5%,0603
L8 2414032F27 IDCTR,FXD,27NH,5%,500MA,.
25OHM,CER,
M701 0985888K02 SKT RTC BTTY LEAP
P100 3916333H02 CONTACT ANT GRD
P4 3905643V01 CONTACT ANT GRD
Q101 4816698H02 MITSUBISHI,FET RF
POWER,VHF
Q197 4813973A13 XSTR,BIP GP SS,PNP,T3906,
SM,SOT-23,
Q200 4871674S01 TSTR SOT BCW 60B (RH)
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q29 4805585Q28 TRANSISTOR RF NPN 8GHZ
NOPB
Q301 4816371H01 XSTR DUAL PNP W18
COMPLIANT
Q401 4805585Q28 TRANSISTOR RF NPN 8GHZ
NOPB
Q402 4813973A04 XSTR NPN 30V DARLINGTON
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT
Q700 4813970A62 XSTR,FET GP
PWR,MOSFET,P-CH,ENHN,C
Q701 4813973M07 XSTR,BIP GP SS,NPN,T3904,
SM,SOT-23,
Q702 5185956E76 IC,CONV,SM,SO16,0-30
VINPUT RANGE
Q703 4813970A62 XSTR,FET GP PWR,MOSFET
,P-CH,ENHN,C
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42 XSTR,BIP GP SS,NPN,SM,
SC-59, SMT,50V
Q804 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT
R102 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R103 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R104 0613952J15 CER CHIP RES 39K OHM 5%
0603
R105 NOT PLACED –
R108 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R109 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R115 0613958H57 CER CHIP RES 220 OHM 5%
0805
R125 0613952H47 CER CHIP RES 82.0 OHM 5%
0603
R127 0613952R01 CER CHIP RES 10K OHM 5%
0402
R13 0613952R01 CER CHIP RES 10K OHM 5%
0402
R14 0613952R01 CER CHIP RES 10K OHM 5%
0402
R142 0613952Z55 RES,MF,12KOHM,1%,.0625W,
SM,0402,200
R143 0613952Z65 RES,MF,43KOHM,1%,.0625W,
SM,0402,200
R144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R146 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R149 0613952Q89 CER CHIP RES 4700 OHM 5%
0402
R15 NOT PLACED –
R150 0613952H47 CER CHIP RES 82.0 OHM 5%
0603
R151 0613952H47 CER CHIP RES 82.0 OHM 5%
0603
R153 NOT PLACED –
R154 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R155 0613952Q77 CER CHIP RES 1500 OHM 5%
0402
R156 NOT PLACED –
R157 0613952Q71 CER CHIP RES 820 OHM 5%
0402
R158 0613952Q49 CER CHIP RES 100 OHM 5%
0402
R159 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R160 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
