Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-39
6816985H01-F February 14, 2012
PMLD4264B/ PMUD2887A/ PMUD2888A/
PMUD2886A/ PMUD2885A/ PMUD3199A/
PMUD3183A/ PMUD3200A/ PMUD3184A Main
Circuit Board Electrical Parts List
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02 CONNECTOR (CONTACT
BATTERY)
C1 2115075H01 CAP CHIP 24PF 5% COG
C2 2113944A42 CAP CER CHP 150.0PF 50V
5%
C9 2113944A42 CAP CER CHP 150.0PF 50V
5%
C15 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C16 2115075H01 CAP CHIP 24PF 5% COG
C17 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C18 2113945A03 CAP CER CHP 330PF 50V 10%
C20 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C22 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C25 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C30 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C33 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R
C35 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C41 2115075H01 CAP CHIP 24PF 5% COG
C43 2113944A42 CAP CER CHP 150.0PF 50V
5%
C44 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C46 2113946Q01 CAP CER CHP 4.7UF 16V
C47 2115075H01 CAP CHIP 24PF 5% COG
C48 2113944A42 CAP CER CHP 150.0PF 50V
5%
C56 2113946B04 CAP CER CHP 0.10UF 10V
10%
C57 2113944C33 CAP CER CHP 18.0PF 50V 5%
C58 NOT PLACED –
C59 2113944A28 CAP CER CHP 18.0PF 50V 5%
C60 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C61 2113945A03 CAP CER CHP 330PF 50V 10%
C62 2113944A26 CAP CER CHP 12.0PF 50V 5%
C63 2113944A26 CAP CER CHP 12.0PF 50V 5%
C64 2113945A03 CAP CER CHP 330PF 50V 10%
C65 2113945A03 CAP CER CHP 330PF 50V 10%
C66 2113945A03 CAP CER CHP 330PF 50V 10%
C67 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C68 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C70 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C71 2113945B02 CAP CER CHP 10,000PF 25V
10%
C72 2113945B02 CAP CER CHP 10,000PF 25V
10%
C100 2113944C04 CAP CER CHP 330.0PF 50V
5%
C101 2113944C04 CAP CER CHP 330.0PF 50V
5%
C102 2113945A03 CAP CER CHP 330PF 50V 10%
C103 2113945B02 CAP CER CHP 10,000PF 25V
10%
C104 2113945A03 CAP CER CHP 330PF 50V 10%
C105 NOT PLACED –
C106 NOT PLACED –
C108 2113945B02 CAP CER CHP 10,000PF 25V
10%
C109 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C110 2113945B02 CAP CER CHP 10,000PF 25V
10%
C111 2113944C04 CAP CER CHP 330.0PF 50V
5%
C112 2113944C04 CAP CER CHP 330.0PF 50V
5%
C113 2113944C04 CAP CER CHP 330.0PF 50V
5%
C115 2113944M14 CAP,FXD,6.8PF,.1PF+/-,
50V-DC
C116 2113944M35 CAP,FXD,51PF,+2%,-2%,
50V-DC
C118 2113944M33 CAP,FXD,43PF,+2%,-2%,
50V-DC
C119 2113944M14 CAP,FXD,6.8PF,.1PF+/-,
50V-DC
C120 2113944C45 CAP CER CHP 100.0PF 50V
5%
C122 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C124 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC,0805,C0G
C125 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC,0805,C0G
C126 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC,0805,C0G
C127 2113944M09 CAP,FXD,4.3PF,.1PF+/-,
50V-DC,0603,C0G
C128 2113944F56 CAP,FXD,39PF,+5%,-5%,
50V-DC,0805,C0G
C129 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603,X7R
C130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C131 2113945B02 CAP CER CHP 10,000PF 25V
10%
C135 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603,X7R
C140 2113945A03 CAP CER CHP 330PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C141 2113944C04 CAP CER CHP 330.0PF 50V
5%
C142 2313960B01 CAP,FXD,1UF,+10%,-10%,
16V-DC
C143 2113945A10 CAP CER CHP 1500PF 50V
10%
C144 2113945A05 CAP CER CHP 470PF 50V 10%
C145 2113945B03 CAP,FXD,.015UF,+10%,-10%,
25V-DC,0402,X7R
C146 2113946K02 CAP CER CHP 0.10UF 16V
C147 2313960B01 CAP,FXD,1UF,+10%,-10%,
16V-DC,SM
C148 2113944A40 CAP CER CHP 100.0PF 50V
5%
C149 2113945B02 CAP CER CHP 10,000PF 25V
10%
C170 2113944M27 CAP,FXD,24PF,+2%,-2%,
50V-DC,0603,C0G
C171 2113944C45 CAP CER CHP 100.0PF 50V
5%
C172 2113944M16 CAP,FXD,8.2PF,.1PF+/-,
50V-DC,0603,C0G
C173 2113944M29 CAP,FXD,30PF,+2%,-2%,
50V-DC,0603,C0G
C174 2113944M13 CAP,FXD,6.2PF,.1PF+/-,
50V-DC,0603,C0G
C175 2113944M28 CAP,FXD,27PF,+2%,-2%,
50V-DC,0603,C0G
C176 2113944M20 CAP,FXD,12PF,+2%,-2%,
50V-DC,0603,C0G
C177 2113944M24 CAP,FXD,18PF,+2%,-2%,
50V-DC,0603,C0G
C178 2113944A28 CAP CER CHP 18.0PF 50V 5%
C179 2113944C04 CAP CER CHP 330.0PF 50V
5%
C180 NOT PLACED –
C181 NOT PLACED –
C182 2113944C04 CAP CER CHP 330.0PF 50V
5%
