Motorola ATS 3000

9.1-40 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C185 2113945B02 CAP CER CHP 10,000PF 25V
10%
C186 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C187 2113944C04 CAP CER CHP 330.0PF 50V
5%
C188 2113945A03 CAP CER CHP 330PF 50V 10%
C189 2113945A03 CAP CER CHP 330PF 50V 10%
C190 2113945A05 CAP CER CHP 470PF 50V 10%
C191 NOT PLACED –
C200 2113945A13 CAP CER CHP 4700PF 50V
10%
C201 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C202 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
C203 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
C204 2109720D20 CAP CHIP LOW DIST 2000
SOV
C206 2113946K02 CAP CER CHP 0.10UF 16V
C207 2113946K02 CAP CER CHP 0.10UF 16V
C208 2113946K02 CAP CER CHP 0.10UF 16V
C209 2113946K02 CAP CER CHP 0.10UF 16V
C210 2313960D07 CAP,FXD,10UF,+10%,-
10%,16V-DC
C211 2113946K02 CAP CER CHP 0.10UF 16V
C212 2113945A03 CAP CER CHP 330PF 50V 10%
C213 2113946K02 CAP CER CHP 0.10UF 16V
C214 2113945B02 CAP CER CHP 10,000PF 25V
10%
C215 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113945A03 CAP CER CHP 330PF 50V 10%
C218 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C219 2313960D07 CAP,FXD,10UF,+10%,-10%,
16V-DC
C220 2113945B02 CAP CER CHP 10,000PF 25V
10%
C221 2113945A03 CAP CER CHP 330PF 50V 10%
C222 2313960D07 CAP,FXD,10UF,+10%,-
10%,16V-DC
C223 2113945A03 CAP CER CHP 330PF 50V 10%
C226 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R
C227 2113945L13 CAP,FXD,330PF,+5%,-5%,
50V-DC,0603,X7R
C228 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C229 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C230 2113946K02 CAP CER CHP 0.10UF 16V
C231 2113945A01 CAP CER CHP 220PF 50V 10,
C232 2113946K02 CAP CER CHP 0.10UF 16V
C233 2113946K02 CAP CER CHP 0.10UF 16V
C234 2113945A03 CAP CER CHP 330PF 50V 10%
C235 2113944A40 CAP CER CHP 100.0PF 50V
5%
C236 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C237 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C238 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C239 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C240 2109720D14 CAP CER CHIP LOW DIST
.1 UF
C243 2113946K02 CAP CER CHP 0.10UF 16V
C245 2113944A40 CAP CER CHP 100.0PF 50V
5%
C246 2113946N03 CAP CER CHP 2.2UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C247 2113945A09 CAP CER CHP 1000PF 50V
10%
C248 NOT PLACED –
C249 2113945A09 CAP CER CHP 1000PF 50V
10%
C252 2113944C78 CAP,FXD,13PF,+5%,-5%,
50V-DC,0603,C0G
C253 2113944C78 CAP,FXD,13PF,+5%,-5%,
50V-DC,0603,C0G
C254 2113944C18 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C255 2113944C63 CAP,FXD,1PF,.1PF+/-,50V-DC,
0603,C0G
C256 2113945L13 CAP,FXD,330PF,+5%,-5%,
50V-DC,0603,X7R
C257 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C258 2113945A03 CAP CER CHP 330PF 50V 10%
C261 2113945A03 CAP CER CHP 330PF 50V 10%
C262 2113945A03 CAP CER CHP 330PF 50V 10%
C263 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC,0402,C0G
C266 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C267 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC,0402,C0G
C271 2113944C32 CAP CER CHP 15.0PF 50V 5%
C272 2113944C32 CAP CER CHP 15.0PF 50V 5%
C273 2188881Y12 CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
C274 2113944V03 CAP,FXD,1PF,.1PF+/-,
50V-DC,0402,C0G
C275 2113945A03 CAP CER CHP 330PF 50V 10%
C276 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC,0402,C0G
C277 2113945A03 CAP CER CHP 330PF 50V 10%
C278 2113944A18 CAP CER CHP 5.1PF 50V
+/- 0.5PF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C279 2113945A03 CAP CER CHP 330PF 50V 10%
C286 2113945A03 CAP CER CHP 330PF 50V 10%
C292 2113945A03 CAP CER CHP 330PF 50V 10%
C293 2113945A03 CAP CER CHP 330PF 50V 10%
C294 2113945A03 CAP CER CHP 330PF 50V 10%
C295 2113945A09 CAP CER CHP 1000PF 50V
10%
C296 2113945A09 CAP CER CHP 1000PF 50V
10%
C400 2113944A40 CAP CER CHP 100.0PF 50V
5%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C405 2113944A40 CAP CER CHP 100.0PF 50V
5%
C411 2113945A11 CAP CER CHP 2200PF 50V
10%
C412 NOT PLACED –
C416 2113946K02 CAP CER CHP 0.10UF 16V
C417 2113944A40 CAP CER CHP 100.0PF 50V
5%
C421 NOT PLACED –
C422 2113945B02 CAP CER CHP 10,000PF 25V
10%
C423 2113944C41 CAP CER CHP 68.0PF 50V 5%
C424 2113944A40 CAP CER CHP 100.0PF 50V
5%
C425 2113945H69 CAP,FXD,.1UF,+5%,-5%,
50V-DC,1206,X7R
C428 2113944A29 CAP CER CHP 22.0PF 50V 5%
C429 2113946K02 CAP CER CHP 0.10UF 16V
C430 2113946K02 CAP CER CHP 0.10UF 16V
C431 2113946K02 CAP CER CHP 0.10UF 16V
C432 2113946K02 CAP CER CHP 0.10UF 16V
C433 2113944C33 CAP CER CHP 18.0PF 50V 5%
C434 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
