Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-41
6816985H01-F February 14, 2012
C435 2113944A36 CAP CER CHP 68.0PF 50V 5%
C436 2113944A40 CAP CER CHP 100.0PF 50V
5%
C437 2113944C85 CAP,FXD,51PF,+5%,-5%,50V-
DC,0603,C0G
C438 2113944C40 CAP CER CHP 62.0PF 50V 5%
C440 2113945G96 CAP,FXD,.33UF,+10%,-
10%,50V-DC,0805,X7R
C441 2313960M26 CAP,FXD,1UF,+10%,-
10%,10V-DC
C442 2113945B02 CAP CER CHP 10,000PF 25V
10%
C447 NOT PLACED –
C448 2113945C25 CAP,FXD,.033UF,+10%,-
10%,50V-DC,0603,X7R
C449 2113944A79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C0G
C461 2113946K02 CAP CER CHP 0.10UF 16V
C463 2113945C27 CAP,FXD,.047UF,+10%,-
10%,50V-DC,0603,X7R
C464 2113946K02 CAP CER CHP 0.10UF 16V
C465 2113946K02 CAP CER CHP 0.10UF 16V
C470 2113946K02 CAP CER CHP 0.10UF 16V
C472 2113946K02 CAP CER CHP 0.10UF 16V
C473 2113946K02 CAP CER CHP 0.10UF 16V
C475 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C476 2113944C89 CAP,FXD,200PF,+5%,-5%,50V-
DC,0603,C0G
C478 2113945C27 CAP,FXD,.047UF,+10%,-
10%,50V-DC,0603,X7R
C480 2313960M26 CAP,FXD,1UF,+10%,-
10%,10V-DC,SM
C481 2313960B30 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,SM
C482 2313960B30 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,SM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C500 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C501 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C502 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C503 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C504 2113945A03 CAP CER CHP 330PF 50V 10%
C505 2113945G98 CAP,FXD,.47UF,+10%,-
10%,50V-DC,0805,X7R
C506 2113946E02 CAP CER CHP 1.0UF 16V 10%
C507 2113945B02 CAP CER CHP 10,000PF 25V
10%
C508 2113945B02 CAP CER CHP 10,000PF 25V
10%
C509 2113945B02 CAP CER CHP 10,000PF 25V
10%
C510 2113946K02 CAP CER CHP 0.10UF 16V
C511 2113946K02 CAP CER CHP 0.10UF 16V
C512 2113946K02 CAP CER CHP 0.10UF 16V
C513 2113955E37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X7R
C514 2113955E37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X7R
C516 2113946E02 CAP CER CHP 1.0UF 16V 10%
C517 2113946E02 CAP CER CHP 1.0UF 16V 10%
C518 2313960B57 CAP,FXD,10UF,+10%,-
10%,6.3V-DC,SM
C519 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C520 2113945A05 CAP CER CHP 470PF 50V 10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C524 2313960H04 CAP,FXD,33UF,+10%,-
10%,16V-DC,SM
C525 2113945L25 CAP,FXD,1000PF,+5%,-
5%,50V-DC,0603,X7R
C526 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C527 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C528 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C550 2113945B02 CAP CER CHP 10,000PF 25V
10%
C551 2113945B02 CAP CER CHP 10,000PF 25V
10%
C607 2113946K02 CAP CER CHP 0.10UF 16V
C610 2113944A32 CAP CER CHP 39.0PF 50V 5%
C611 2113944A32 CAP CER CHP 39.0PF 50V 5%
C612 2113944A32 CAP CER CHP 39.0PF 50V 5%
C613 2113944A32 CAP CER CHP 39.0PF 50V 5%
C614 2113945A03 CAP CER CHP 330PF 50V 10%
C615 2113944A32 CAP CER CHP 39.0PF 50V 5%
C617 2113944A32 CAP CER CHP 39.0PF 50V 5%
C619 2113944A32 CAP CER CHP 39.0PF 50V 5%
C620 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R
C621 2113946K02 CAP CER CHP 0.10UF 16V
C629 2113945A03 CAP CER CHP 330PF 50V 10%
C630 2113945A03 CAP CER CHP 330PF 50V 10%
C631 2113945A03 CAP CER CHP 330PF 50V 10%
C632 2113945A03 CAP CER CHP 330PF 50V 10%
C633 2113945A03 CAP CER CHP 330PF 50V 10%
C634 2113945A03 CAP CER CHP 330PF 50V 10%
C635 2113945A03 CAP CER CHP 330PF 50V 10%
C636 2113945A03 CAP CER CHP 330PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C637 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R
C638 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R
C640 NOT PLACED –
C641 NOT PLACED –
C652 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C653 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C654 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C655 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C656 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C657 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C658 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C671 2113944A31 CAP CER CHP 33.0PF 50V 5%
C672 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C673 2113944A31 CAP CER CHP 33.0PF 50V 5%
C674 2113945A05 CAP CER CHP 470PF 50V 10%
C675 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R
C680 2113944A31 CAP CER CHP 33.0PF 50V 5%
C700 2113946B04 CAP CER CHP 0.10UF 10V
10%
C701 2113944A19 CAP CER CHP 5.6PF 50V +/-
0.5PF
C702 2113944A19 CAP CER CHP 5.6PF 50V +/-
0.5PF
C703 NOT PLACED –
C704 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C705 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
