Motorola ATS 3000

9.1-42 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C706 2113945A09 CAP CER CHP 1000PF 50V
10%
C708 2113944A31 CAP CER CHP 33.0PF 50V 5%
C709 2113944A31 CAP CER CHP 33.0PF 50V 5%
C710 2113946J03 CAP CER CHP 10.0UF 16V
10%
C711 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C712 2113946E02 CAP CER CHP 1.0UF 16V 10%
C713 2311049C70 CAP,FXD,68PF,+10%,-
10%,6.3V-DC
C714 2113945A09 CAP CER CHP 1000PF 50V
10%
C715 2311049C70 CAP,FXD,68PF,+10%,-
10%,6.3V-DC
C716 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C717 2113946E02 CAP CER CHP 1.0UF 16V 10%
C718 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C719 2113946E02 CAP CER CHP 1.0UF 16V 10%
C720 2113946G01 CAP CER CHP 2.2UF 16V 10%
C721 2113946E02 CAP CER CHP 1.0UF 16V 10%
C722 2113946E02 CAP CER CHP 1.0UF 16V 10%
C723 2113946E02 CAP CER CHP 1.0UF 16V 10%
C724 2113946E02 CAP CER CHP 1.0UF 16V 10%
C725 2113946K02 CAP CER CHP 0.10UF 16V
C726 2113946E02 CAP CER CHP 1.0UF 16V 10%
C727 2113944A40 CAP CER CHP 100.0PF 50V
5%
C728 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R
C729 2113946J03 CAP CER CHP 10.0UF 16V
10%
C730 2113944A40 CAP CER CHP 100.0PF 50V
5%
C731 2113946G01 CAP CER CHP 2.2UF 16V 10%
C732 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C734 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C735 2113946E02 CAP CER CHP 1.0UF 16V 10%
C736 2113946J03 CAP CER CHP 10.0UF 16V
10%
C737 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C738 2113946K02 CAP CER CHP 0.10UF 16V
C742 2113945A05 CAP CER CHP 470PF 50V 10%
C743 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C750 2113946J03 CAP CER CHP 10.0UF 16V
10%
C751 2113946J03 CAP CER CHP 10.0UF 16V
10%
C752 2113944A40 CAP CER CHP 100.0PF 50V
5%
C753 2113944A40 CAP CER CHP 100.0PF 50V
5%
C754 2113946E02 CAP CER CHP 1.0UF 16V 10%
C755 2113946E02 CAP CER CHP 1.0UF 16V 10%
C756 2113944A40 CAP CER CHP 100.0PF 50V
5%
C757 2113944A40 CAP CER CHP 100.0PF 50V
5%
C758 2113946E02 CAP CER CHP 1.0UF 16V 10%
C759 2113946E02 CAP CER CHP 1.0UF 16V 10%
C760 2113944A40 CAP CER CHP 100.0PF 50V
5%
C761 2113944A40 CAP CER CHP 100.0PF 50V
5%
C762 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R
C763 2113944A40 CAP CER CHP 100.0PF 50V
5%
C764 2113946B03 CAP CER CHP 0.068UF 10V 10
C765 2113946B03 CAP CER CHP 0.068UF 10V 10
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C766 2113944A40 CAP CER CHP 100.0PF 50V
5%
C767 2113944A40 CAP CER CHP 100.0PF 50V
5%
C768 2113944A40 CAP CER CHP 100.0PF 50V
5%
C769 2113944A40 CAP CER CHP 100.0PF 50V
5%
C770 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R
C771 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R
C773 2113946K02 CAP CER CHP 0.10UF 16V
C790 2113946A02 CAP CER CHP 0.022UF 16V
10,
C791 2113946K02 CAP CER CHP 0.10UF 16V
C792 2113946K02 CAP CER CHP 0.10UF 16V
C796 NOT PLACED –
C800 2113955D31 CAP,FXD,1UF,+10%,-
10%,16V-DC,1206,X7R
C801 2113945A05 CAP CER CHP 470PF 50V 10%
C802 2113945C20 CAP,FXD,.016UF,+10%,-
10%,50V-DC,0603,X7R
C803 2113945A05 CAP CER CHP 470PF 50V 10%
C804 2113946E02 CAP CER CHP 1.0UF 16V 10%
C805 2113945C20 CAP,FXD,.016UF,+10%,-
10%,50V-DC,0603,X7R
C806 2113946K02 CAP CER CHP 0.10UF 16V
C807 2113946K02 CAP CER CHP 0.10UF 16V
C808 2113946K02 CAP CER CHP 0.10UF 16V
C809 2113945C20 CAP,FXD,.016UF,+10%,-
10%,50V-DC,0603,X7R
C810 2113946E02 CAP CER CHP 1.0UF 16V 10%
C811 2113946K02 CAP CER CHP 0.10UF 16V
C812 2113946K02 CAP CER CHP 0.10UF 16V
C813 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C814 2113946K02 CAP CER CHP 0.10UF 16V
C815 2113946K02 CAP CER CHP 0.10UF 16V
C816 2113946K02 CAP CER CHP 0.10UF 16V
C817 2113946K02 CAP CER CHP 0.10UF 16V
C818 2113946K02 CAP CER CHP 0.10UF 16V
C830 2113946K02 CAP CER CHP 0.10UF 16V
C840 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C850 2113945A03 CAP CER CHP 330PF 50V 10%
C851 2113944A40 CAP CER CHP 100.0PF 50V
5%
C855 NOT PLACED –
C856 NOT PLACED –
C857 NOT PLACED –
C858 2113945B02 CAP CER CHP 10,000PF 25V
10%
C859 2113945B02 CAP CER CHP 10,000PF 25V
10%
C860 2113945B02 CAP CER CHP 10,000PF 25V
10%
C861 2113945B02 CAP CER CHP 10,000PF 25V
10%
C862 2113945B02 CAP CER CHP 10,000PF 25V
10%
C863 2113945B02 CAP CER CHP 10,000PF 25V
10%
C864 2113945B02 CAP CER CHP 10,000PF 25V
10%
C865 2113945B02 CAP CER CHP 10,000PF 25V
10%
C866 2113945B02 CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED –
C868 NOT PLACED –
CR800 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
