Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-43
6816985H01-F February 14, 2012
CR801 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D3 4815096H01 VARACTOR DIODE 1SV305
D4 4815096H01 VARACTOR DIODE 1SV305
D5 4815096H01 VARACTOR DIODE 1SV305
D6 4815096H01 VARACTOR DIODE 1SV305
D10 4815096H01 VARACTOR DIODE 1SV305
D11 4815096H01 VARACTOR DIODE 1SV305
D12 4815096H01 VARACTOR DIODE 1SV305
D13 4815096H01 VARACTOR DIODE 1SV305
D20 4808115L27 DIODE,PIN,DH50037,SM,
SOT-323,30V
D104 4816487H01 SWITCHING DIODE,
MINIBLOC
D170 4802482J02 PIN DIODE SMD
D171 4802482J02 PIN DIODE SMD
D172 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
D173 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
D201 4815011H01 DIODE TRIPLE
D202 4815011H01 DIODE TRIPLE
D251 4813974A01 DIODE ARRAY,VCTR,SM,
SOT-23,100MA,20V,.225W,2
D252 4813974A01 DIODE ARRAY,VCTR,SM,
SOT-23,100MA,20V,.225W,2
D270 4813974A01 DIODE ARRAY,VCTR,SM,
SOT-23,100MA,20V,.225W,2
D401 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D402 4805656W41 DIODE VARACTOR 40PFV
15PFV
D500 4815155H01 RECTIFIER
D501 4809118D02 LED BICOLOR
LNJ115W8POMT
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D510 4813978M15 DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D511 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
D512 4813978M15 DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D513 4813978M15 DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D600 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
D603 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
E102 2480574F01 IND FERRITE CHIP 60OHM
0603
E140 2405688Z01 INDUCTOR FERRITE BEAD
E141 2480574F01 IND FERRITE CHIP 60OHM
0603
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MHZ
SRF,SM,PB-FREE
E800 2480574F01 IND FERRITE CHIP 60OHM
0603
E801 2480574F01 IND FERRITE CHIP 60OHM
0603
E802 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
F500 6515076H01 FUSE CHIP SMT TR/1608FF
3A
FL51 9185367C01 XTAL FLTR 5X7 SURFACE MT
MONO
FL200 9116848H01 FLTR SW CAP 3 POLE
BUTTERW, W18
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
J101 2880658Z08 CONNECTOR SMA
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L5 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L6 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ
SRF,SM,0805,PB-
L7 2414032F33 IDCTR,WW,82NH,5%,400MA,
.42OHM,CER,40 Q,1.02GHZ
SRF,SM,PB-FR
L8 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ
SRF,SM,0805,PB-
L12 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L20 2414032F38 IDCTR,WW,220NH,5%,400MA,
.7OHM,CER,30 Q,630MHZ
SRF,SM,PB-FRE
L21 2414032F31 IDCTR,WW,56NH,5%,500MA
,.34OHM,CER,40 Q,1.3GHZ
SRF,SM,PB-FRE
L28 2414032F26 IDCTR,WW,22NH,5%,500MA,
.22OHM,CER,45 Q,2.2GHZ
SRF,SM,PB-FRE
L31 2414032F34 IDCTR,WW,100NH,5%,400MA,
.46OHM,CER,40 Q,950MHZ
SRF,SM,PB-FR
L34 2414032F35 IDCTR,WW,120NH,5%,400MA,
.51OHM,CER,35 Q,860MHZ
SRF,SM,PB-FR
L42 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L45 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ SRF,
SM,0805,PB-
L47 2414032F33 IDCTR,WW,82NH,5%,400MA,
.42OHM,CER,40 Q,1.02GHZ
SRF,SM,PB-FR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L48 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ SRF,
SM,0805,PB-
L49 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L54 2414032F73 IDCTR,WW,820NH,5%,180MA,
2.23OHM,CER,23 Q,215MHZ
SRF,SM,PB-F
L55 0613958T74 CER CHIP RES 0.0 OHM JMP
1206
L56 2414032D25 IDCTR,WW,620NH,5%,400MA,
1.6OHM,CER,28 Q,400MHZ
SRF,SM,PB-FR
L60 2414017G13 IDCTR,CHIP,33NH,5%,300MA,
.65OHM,CER,8 Q,SM,0603,PB-
FREE
L61 2414017N16 IDCTR,CHIP,22NH,5%,600MA,
.54OHM,CER,12 Q,1.3GHZ
SRF,SM,0603
L62 2414017N16 IDCTR,CHIP,22NH,5%,600MA,
.54OHM,CER,12 Q,1.3GHZ
SRF,SM,0603
L63 2414017Q40 IDCTR,FXD,270NH,10%,250M
A,.5OHM,FERR,20 Q,150MHZ
SRF,SM,0805
L64 NOT PLACED –
L101 2414017N10 IDCTR,CHIP,6.8NH,5%,600MA,
.22OHM,CER,10 Q,2.7GHZ
SRF,SM,0603
L106 2414032D30 IDCTR,WW,1UH,5%,320MA
,2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L114 2414032B60 IDCTR,WW,390NH,5%,620MA,
1.12OHM,CER,30 Q,465MHZ
SRF,SM,PB-F
L115 2460591B80 COIL AIR WOUND INDUC
19.61
L117 2414017N18 IDCTR,CHIP,33NH,5%,600MA,
.71OHM,CER,12 Q,1.1GHZ
SRF,SM,0603
L118 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
