Motorola ATS 3000

9.1-44 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
L119 2479990E01 COIL AIR WOUND/GREEN
CLR 23.75
L120 NOT PLACED –
L121 NOT PLACED –
L125 2479990A02 AIR WND COIL/GREEN
COLOR7.66NH
L126 2415428H01 AIR WOUND INDUCTOR
L127 2479990E01 COIL AIR WOUND/GREEN
CLR 23.75
L128 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L170 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L171 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L172 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L176 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L200 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
SRF,SM,0805,PB
L201 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L202 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L203 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L204 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L205 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
SRF,SM,0805,PB
L206 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L251 2414032D30 IDCTR,WW,1UH,5%,320MA,2.
8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L252 2414032D30 IDCTR,WW,1UH,5%,320MA,2.
8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L253 2460591C35 COIL AIR WOUND INDUC
18.08
L254 2460591C03 COIL AIR WOUND INDUC
11.87
L257 0613958T74 CER CHIP RES 0.0 OHM JMP
1206
L258 2414032D17 IDCTR,WW,150NH,5%,750MA,
.31OHM,CER,40 Q,850MHZ
SRF,SM,PB-FR
L259 2414032D30 IDCTR,WW,1UH,5%,320MA,2.
8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L266 2414032D18 IDCTR,WW,180NH,5%,700MA,
.43OHM,CER,35 Q,780MHZ
SRF,SM,PB-FR
L270 2414032D30 IDCTR,WW,1UH,5%,320MA,2.
8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L271 2414032D30 IDCTR,WW,1UH,5%,320MA,2.
8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L272 2414032B48 IDCTR,WW,39NH,5%,1A,.15O
HM,CER,50 Q,1.5GHZ
SRF,SM,PB-FREE
L273 2414032B46 IDCTR,WW,27NH,5%,1A,.13O
HM,CER,50 Q,1.5GHZ
SRF,SM,PB-FREE
L274 2414032D40 IDCTR,WW,33NH,5%,1A,.11O
HM,CER,42 Q,1.45GHZ
SRF,SM,PB-FREE
L403 2414032B75 IDCTR,WW,3.9UH,5%,340MA,
3.6OHM,CER,20 Q,70MHZ
SRF,SM,PB-FRE
L404 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30 Q,500MHZ
SRF,SM,PB-F
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L407 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MHZ
SRF,SM,PB-FREE
L411 2466505A01 COIL INDUCTOR
L412 2466505A01 COIL INDUCTOR
L413 2414032B64 IDCTR,WW,680NH,5%,540MA,
1.47OHM,CER,30 Q,340MHZ
SRF,SM,PB-F
L414 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,.
65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L500 2414017Q42 IDCTR,FXD,390NH,10%,200M
A,.65OHM,FERR,25 Q,135MHZ
SRF,SM,080
L501 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,.
65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L502 2489669V01 IDCTR,WW,100UH,5%,40MA,1
0OHM,20 Q,10MHZ
SRF,SM,1210,PB-FREE
L651 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
SRF,SM,0805,PB-
L652 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
SRF,SM,0805,PB-
L701 2486085A01 COIL, POWER INDUCTOR
L702 2486085A01 COIL, POWER INDUCTOR
L703 2464675H01 IDCTR,WW,560NH,5%,550MA
L704 2464675H01 IDCTR,WW,560NH,5%,550MA
L705 2464675H01 IDCTR,WW,560NH,5%,550MA
L708 2416307H01 IDCTR,WW,680NH,5%,0603
L710 2416307H01 IDCTR,WW,680NH,5%,0603
M701 0985888K02 SKT RTC BTTY LEAP
P4 3905643V01 CONTACT ANT GRD
P100 3916333H02 GROUND CONTACT
Q29 4805585Q28 TRANSISTOR RF NPN 8GHZ
NOPB
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q101 4816698H02 TRANSISTOR,FET RF
POWER, N-CHANNEL,
RD12MVP1-T122,SM,60V,
MOD, XSTR,FET RF PWR,VHF
Q197 4813973A13 XSTR,GEN PURPOSE SMALL
SIG,PNP,MMBT3906L,TO-236,
4, PB-FREE
Q200 4871674S01 XSTR,BIP GP SS
Q301 4816371H01 XSTR DUAL PNP W18
COMPLIANT
Q401 4805585Q28 TRANSISTOR RF NPN 8GHZ
NOPB
Q402 4813973A04 XSTR,BIP GP SS,NPN,TA13,
SM,SOT-23,SMT,30V,.225W,
300MA,125MHZ,P
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA,PB-FR
Q700 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-20V,
1.3W,PB-FREE
Q701 4813973M07 XSTR,BIP GP SS,NPN,T3904,
SM,SOT-23,SMT,40V,.225W,
200MA,300MHZ
Q702 5185956E76 IC,CONV,SM,SO16,0-30 VIN-
PUT RANGE,6.5A,3.8V,HI SPD
SWTH DR
Q703 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W,
PB-FREE
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42 XSTR,BIP GP SS,NPN,SM,
SC-59,SMT,50V,.23W,100MA,
PB-FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
