Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-45
6816985H01-F February 14, 2012
Q804 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA,PB-FR
R13 0613952R01 CER CHIP RES 10K OHM 5%
0402
R14 0613952R01 CER CHIP RES 10K OHM 5%
0402
R15 NOT PLACED –
R22 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R23 0613952R31 CER CHIP RES 180K OHM 5%
0402
R24 0613952R31 CER CHIP RES 180K OHM 5%
0402
R26 0613952Q83 CER CHIP RES 2700 OHM 5
0402
R30 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R32 0613952H33 CER CHIP RES 22.0 OHM 5%
0603
R33 0613952R01 CER CHIP RES 10K OHM 5%
0402
R34 0613952R01 CER CHIP RES 10K OHM 5%
0402
R60 0613952Q49 CER CHIP RES 100 OHM 5
0402
R102 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R103 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R104 0613952J15 CER CHIP RES 39K OHM 5%
0603
R105 NOT PLACED –
R108 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R109 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R115 0613958H57 CER CHIP RES 220 OHM 5%
0805
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R125 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R127 0613952R01 CER CHIP RES 10K OHM 5%
0402
R142 0613952Z55 RES,MF,12KOHM,1%,.0625W,
SM,0402,200PPM/CEL,
PB-FREE
R143 0613952Z65 RES,MF,43KOHM,1%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R146 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R149 0613952Q89 CER CHIP RES 4700 OHM 5
0402
R150 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R151 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R153 NOT PLACED –
R154 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R155 0613952Q77 CER CHIP RES 1500 OHM 5
0402
R156 NOT PLACED –
R157 0613952Q71 CER CHIP RES 820 OHM 5
0402
R158 0613952Q49 CER CHIP RES 100 OHM 5
0402
R159 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R160 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R161 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R162 NOT PLACED –
R168 0613952Q49 CER CHIP RES 100 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R169 0613952Q49 CER CHIP RES 100 OHM 5
0402
R199 0613952J01 CER CHIP RES 10K OHM 5%
0603
R201 0613952Q47 CER CHIP RES 82.0 OHM 5%
0402
R202 0613952Q69 CER CHIP RES 680 OHM 5
0402
R203 0613952Q57 CER CHIP RES 220 OHM 5
0402
R204 0613952R19 CER CHIP RES 56K OHM 5%
0402
R205 0613952R15 CER CHIP RES 39K OHM 5%
0402
R206 0613952R01 CER CHIP RES 10K OHM 5%
0402
R207 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R208 0613952R13 CER CHIP RES 33K OHM 5%
0402
R209 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R210 0613952R13 CER CHIP RES 33K OHM 5%
0402
R211 0613952Q80 CER CHIP RES 2000 OHM 5
0402
R212 NOT PLACED –
R213 0613952Q95 CER CHIP RES 8200 OHM 5
0402
R214 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R215 0613952R01 CER CHIP RES 10K OHM 5%
0402
R216 0613952Q49 CER CHIP RES 100 OHM 5
0402
R251 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R252 0613952Q36 CER CHIP RES 30.0 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R253 0613952Q61 CER CHIP RES 330 OHM 5
0402
R254 0613952R35 CER CHIP RES 270K OHM 5%
0402
R255 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R257 0613952R01 CER CHIP RES 10K OHM 5%
0402
R266 0613952Q61 CER CHIP RES 330 OHM 5
0402
R270 0613952Q38 CER CHIP RES 36.0 OHM 5
0402
R271 0613952Q59 CER CHIP RES 270 OHM 5
0402
R272 0613952Q56 CER CHIP RES 200 OHM 5
0402
R273 0613952Q65 CER CHIP RES 470 OHM 5
0402
R274 0613952Q29 CER CHIP RES 15.0 OHM 5
0402
R275 0613952Q65 CER CHIP RES 470 OHM 5
0402
R277 0613952R01 CER CHIP RES 10K OHM 5%
0402
R291 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R293 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R294 0613952Q61 CER CHIP RES 330 OHM 5
0402
R295 0613952R01 CER CHIP RES 10K OHM 5%
0402
R406 0613952R01 CER CHIP RES 10K OHM 5%
0402
R407 0613952R01 CER CHIP RES 10K OHM 5%
0402
R408 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R412 0613952H62 CER CHIP RES 360 OHM 5
0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
