Motorola ATS 3000

9.1-46 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R413 0613952H68 CER CHIP RES 620 OHM 5
0603
R414 0613952R07 CER CHIP RES 18K OHM 5%
0402
R415 0613952R03 CER CHIP RES 12K OHM 5%
0402
R417 0613952Q74 RES,MF,1.1KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952R25 CER CHIP RES 100K OHM 5%
0402
R420 0613952R19 CER CHIP RES 56K OHM 5%
0402
R436 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R499 0613952R01 CER CHIP RES 10K OHM 5%
0402
R503 0613952Q63 CER CHIP RES 390 OHM 5
0402
R504 0613952Q66 CER CHIP RES 510 OHM 5
0402
R505 0613952R01 CER CHIP RES 10K OHM 5%
0402
R507 0613952Q49 CER CHIP RES 100 OHM 5
0402
R508 0613952Q49 CER CHIP RES 100 OHM 5
0402
R509 0613952Q49 CER CHIP RES 100 OHM 5
0402
R510 0613952Q49 CER CHIP RES 100 OHM 5
0402
R511 0613952R01 CER CHIP RES 10K OHM 5%
0402
R512 0613952R17 CER CHIP RES 47K OHM 5%
0402
R513 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R514 0613952R01 CER CHIP RES 10K OHM 5%
0402
R515 0613952R01 CER CHIP RES 10K OHM 5%
0402
R516 0613952R01 CER CHIP RES 10K OHM 5%
0402
R517 0613952R01 CER CHIP RES 10K OHM 5%
0402
R518 0613952R01 CER CHIP RES 10K OHM 5%
0402
R519 0613952R17 CER CHIP RES 47K OHM 5%
0402
R520 0613952R37 CER CHIP RES 330K OHM 5%
0402
R521 NOT PLACED –
R522 0613952R17 CER CHIP RES 47K OHM 5%
0402
R523 0613952R17 CER CHIP RES 47K OHM 5%
0402
R524 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R525 0613952R01 CER CHIP RES 10K OHM 5%
0402
R526 0613952R01 CER CHIP RES 10K OHM 5%
0402
R527 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R528 NOT PLACED –
R608 0613952Q49 CER CHIP RES 100 OHM 5
0402
R610 NOT PLACED –
R611 0613952Q49 CER CHIP RES 100 OHM 5
0402
R613 0613952R08 CER CHIP RES 20K OHM 5
0402
R614 0613952R08 CER CHIP RES 20K OHM 5
0402
R615 0613952R25 CER CHIP RES 100K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R616 0613952Q49 CER CHIP RES 100 OHM 5
0402
R617 NOT PLACED –
R620 0613952Q49 CER CHIP RES 100 OHM 5
0402
R621 0613952Q49 CER CHIP RES 100 OHM 5
0402
R622 0613952Q49 CER CHIP RES 100 OHM 5
0402
R625 0613952Q49 CER CHIP RES 100 OHM 5
0402
R626 0613952Q49 CER CHIP RES 100 OHM 5
0402
R633 NOT PLACED –
R634 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R635 NOT PLACED –
R636 0613952R01 CER CHIP RES 10K OHM 5%
0402
R637 0613952Q49 CER CHIP RES 100 OHM 5
0402
R638 0613952Q49 CER CHIP RES 100 OHM 5
0402
R639 0613952Q49 CER CHIP RES 100 OHM 5
0402
R640 0613952Q49 CER CHIP RES 100 OHM 5
0402
R641 0613952Q49 CER CHIP RES 100 OHM 5
0402
R642 0613952Q49 CER CHIP RES 100 OHM 5
0402
R643 0613952Q49 CER CHIP RES 100 OHM 5
0402
R644 0613952Q49 CER CHIP RES 100 OHM 5
0402
R647 0613952R01 CER CHIP RES 10K OHM 5%
0402
R649 0613952R17 CER CHIP RES 47K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R654 0613952R01 CER CHIP RES 10K OHM 5%
0402
R656 0613952R01 CER CHIP RES 10K OHM 5%
0402
R658 0613952P18 CER CHIP RES 150K OHM 1
0402
R666 0613952Q57 CER CHIP RES 220 OHM 5
0402
R667 0613952Q63 CER CHIP RES 390 OHM 5
0402
R668 0613952Q45 CER CHIP RES 68.0 OHM 5
0402
R669 0613952Q49 CER CHIP RES 100 OHM 5
0402
R670 0613952Q49 CER CHIP RES 100 OHM 5
0402
R671 0613952Q63 CER CHIP RES 390 OHM 5
0402
R672 0613952R01 CER CHIP RES 10K OHM 5%
0402
R673 0613952R01 CER CHIP RES 10K OHM 5%
0402
R674 0613952Q49 CER CHIP RES 100 OHM 5
0402
R675 0613952Q67 CER CHIP RES 560 OHM 5
0402
R677 0613952R01 CER CHIP RES 10K OHM 5%
0402
R678 0613952Q49 CER CHIP RES 100 OHM 5
0402
R697 0613952Q49 CER CHIP RES 100 OHM 5
0402
R700 0613952Q80 CER CHIP RES 2000 OHM 5
0402
R701 0613952R17 CER CHIP RES 47K OHM 5%
0402
R702 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R703 0613952R17 CER CHIP RES 47K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
