Motorola ATS 3000

9.1-48 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R837 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R838 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R839 0613952R01 CER CHIP RES 10K OHM 5%
0402
R840 0613952Q66 CER CHIP RES 510 OHM 5
0402
R841 0613952R01 CER CHIP RES 10K OHM 5%
0402
R842 0613952R01 CER CHIP RES 10K OHM 5%
0402
R843 0613952R41 CER CHIP RES 470K OHM 5%
0402
R844 0613952Q61 CER CHIP RES 330 OHM 5
0402
S500 4085131E03 SWITCH FREQ DUAL FUNC-
TION
S501 1880619Z06 POTENTIOMETER, VOLUME
S502 4016618H01 SWITCH SURFACE MOUNT
S503 4070354A01 LIGHT TOUCH SWITCH-SMD
S504 4070354A01 LIGHT TOUCH SWITCH-SMD
S505 4070354A01 LIGHT TOUCH SWITCH-SMD
S506 4070354A01 LIGHT TOUCH SWITCH-SMD
SH1 2686707Z02 SHIELD, SM SLDRD,CRS,
PLTD
SH51 2686700Z02 SHIELD, SM SLDRD,CRS
,PLTD
SH52 2686699Z02 SHIELD, SM SLDRD,CRS,
PLTD
SH101 2686702Z02 SHIELD, SM SLDRD,CRS
,PLTD
SH102 2686701Z02 SHIELD, SM SLDRD,CRS,
PLTD
SH103 2686708Z02 SHIELD, SM SLDRD,CRS,
PLTD
SH201 2686705Z02 SHIELD, SM SLDRD,CRS,
PLTD
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
SH251 2616554H01 SHLD VCO TOP
SH252 2616559H01 SHLD PCIC
SH401 2686706Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH402 2686698Z02 SHIELD, SM
SLDRD,CRS,PLTD
T51 2515121H01 BALUN, TRANSFORMER W18
COMP
T53 2516320H01 XFMR SMALL SIGNAL
SURFACE MT
U1 5164015H81 IC,MXR,DBL BAL GILBERT,
CELL,SM
U2 5185941F45 ATTEN,VAR,14.4DBMIN,15.6D
BMAX,0-2000 MHZFREQ,
50OHM,PCMT,SOT
U3 5116349H01 DUAL INVERTER IC
U101 5115678H01 VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
U102 5185765B26 IC PWR CTRL IN MOS20
U103 5115022H01 IC TEMPERATURE SENSOR
U201 5185941F40 IC, 12 BIT DAC
U202 5116245H01 CC LVFRACN
U250 5105750U56 IC PKG DIE VCO BUFFER
U401 5185963A85 IC-ABACUS III-LP
U500 5188493T01 IC,VREG/
SWG,LP2989,SM,MINI SO-8 HI
PRCN REG 5V
U501 5185941F35 IC, VREG, NOPB
U502 5185941F35 IC, VREG, NOPB
U601 5185941F22 IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U602 5185941F22 IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U701 5185143E77 IC, MAKO ASIC, CMOS PWR
MGMT
U702 5185941F22 IC,OPAMP,SGL,OPA237,
SOT23,NOPB
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
U705 5114000B39 IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U712 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,SM,
SC70-6,1PER PKG,BUS,PB
FREE
U713 5115453H01 RAIL TO RAIL OUTPUT, 8 PIN
BGA
U714 5115453H01 RAIL TO RAIL OUTPUT, 8 PIN
BGA
U800 5185941F04 IC, PATRIOT BRAVO,
1.2.2,256BGA, PB-FREE
U801 5114000B39 IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U802 5114000B39 IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U803 5185956E69 IC,DRAM,64MB,60NS,IC 1.8V
64
U804 5185941F03 IC,SRAM,8M,512KX16,70NS,
SM,FBGA48,1.95V
U805 5116411H01 IC,OP AMP,
VR500 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR501 4813977M19 DIODE,ZEN,MBZ5240,SM,SOT
-23,10V,10MA,.225W,ZEN,
PB-FREE
VR502 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR503 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR504 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR505 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR506 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR508 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
VR509 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
VR510 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
VR511 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
VR512 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
VR513 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
VR514 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR650 4813979P12 DIODE ARRAY,TRANSIENT
PROTECTION,SM,SOT-457,
12V,.225W,ZEN,4,PB
VR651 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
VR652 4813977A43 PB-FREE, NOTCOMPLETELY-
ENRICHED
VR657 4809788E21 DIODE, ZENER, SOD-323,
SMD,W18 COMPLIANT
VR658 4813977C23 DIODE,ZEN,MMSZ5243,SM,
SOD-123,13V,10MA,.5W,
ZEN,PB-FREE
VR659 4813979P10 DIODE ARRAY,TRNSNT
PROT,SM,SOT-457,5.6V,
.225W,ZEN,4,PB-FREE
VR662 4813979P10 DIODE ARRAY,TRNSNT
PROT,SM,SOT-457,5.6V,
.225W,ZEN,4,PB-FREE
VR663 4813977M18 DIODE,ZEN,MBZ5239,SM,SOT
-23,9.1V,10MA,.225W,ZEN,
PB-FREE
VR678 4866544A01 DIODE ARRAY,ZEN,
SR05.TCT,SM,5V,5,LOW
CAPACITANCE TVS DIO
VR701 4813977M11 DIODE,ZEN,MBZ5232,SM,
SOT-23,5.6V,10MA,.225W,
ZEN,PB-FREE
Y200 4802245J68 OSC, REF 16.8 MHZ 1.5 PPM
Y701 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
