Motorola ATS 3000 User Manual

VHF Schematics, Board Overlays, and Parts Lists 9.1-49
6816985H01-F February 14, 2012
PMLD4264E Main Circuit Board
Electrical Parts List
Y702 4864005H01 RESONATOR, CRYSTAL
24.576 MHZ
8416494H02 BOARD, PCB, VHF MAKO
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02 CONNECTOR (CONTACT
BATTERY)
C1 2115075H01 CAP CHIP 24PF 5% COG
C2 2113944A42 CAP CER CHP 150.0PF 50V
5%
C9 2113944A42 CAP CER CHP 150.0PF 50V
5%
C15 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C16 2115075H01 CAP CHIP 24PF 5% COG
C17 2113945C31 CAP,FXD,.1UF,+10%,-10%,5
0V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C18 2113945A03 CAP CER CHP 330PF 50V 10%
C20 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C22 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C25 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C30 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C33 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C35 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C41 2115075H01 CAP CHIP 24PF 5% COG
C43 2113944A42 CAP CER CHP 150.0PF 50V
5%
C44 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C46 2113946Q01 CAP CER CHP 4.7UF 16V
C47 2115075H01 CAP CHIP 24PF 5% COG
C48 2113944A42 CAP CER CHP 150.0PF 50V
5%
C56 2113946B04 CAP CER CHP 0.10UF 10V
10%
C57 2113944C33 CAP CER CHP 18.0PF 50V 5%
C58 NOT PLACED –
C59 2113944A28 CAP CER CHP 18.0PF 50V 5%
C60 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C61 2113945A03 CAP CER CHP 330PF 50V 10%
C62 2113944A26 CAP CER CHP 12.0PF 50V 5%
C63 2113944A26 CAP CER CHP 12.0PF 50V 5%
C64 2113945A03 CAP CER CHP 330PF 50V 10%
C65 2113945A03 CAP CER CHP 330PF 50V 10%
C66 2113945A03 CAP CER CHP 330PF 50V 10%
C67 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C68 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C70 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C71 2113945B02 CAP CER CHP 10,000PF 25V
10%
C72 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C100 2113944C04 CAP CER CHP 330.0PF 50V
5%
C101 2113944C04 CAP CER CHP 330.0PF 50V
5%
C102 2113945A03 CAP CER CHP 330PF 50V 10%
C103 2113945B02 CAP CER CHP 10,000PF 25V
10%
C104 2113945A03 CAP CER CHP 330PF 50V 10%
C105 NOT PLACED –
C106 NOT PLACED –
C108 2113945B02 CAP CER CHP 10,000PF 25V
10%
C109 2113945B02 CAP CER CHP 10,000PF 25V
10%
C110 2113945B02 CAP CER CHP 10,000PF 25V
10%
C111 2113944C04 CAP CER CHP 330.0PF 50V
5%
C112 2113944C04 CAP CER CHP 330.0PF 50V
5%
C113 2113944C04 CAP CER CHP 330.0PF 50V
5%
C115 2113944M14 CAP,FXD,6.8PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C116 2113944M35 CAP,FXD,51PF,+2%,-2%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C118 2113944M33 CAP,FXD,43PF,+2%,-2%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C119 2113944M14 CAP,FXD,6.8PF,.1PF+/-,5
0V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C120 2113944C45 CAP CER CHP 100.0PF 50V
5%
C122 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C124 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX,PB
C125 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX,PB
C126 2113944F58 CAP,FXD,47PF,+5%,-5%,
50V-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX,PB
C127 2113944M09 CAP,FXD,4.3PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C128 2113944F56 CAP,FXD,39PF,+5%,-5%,
50V-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX,PB
C129 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C131 2113945B02 CAP CER CHP 10,000PF 25V
10%
C135 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C140 2113945A03 CAP CER CHP 330PF 50V 10%
C141 2113944C04 CAP CER CHP 330.0PF 50V
5%
C142 2313960B01 CAP,FXD,1UF,+10%,-10%,
16V-DC,SM,-55DEG CMIN,
125DEG CMAX,87MA,E
C143 2113945A10 CAP CER CHP 1500PF 50V
10%
C144 2113945A05 CAP CER CHP 470PF 50V 10%
C145 2113945B03 CAP,FXD,.015UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C146 2113946K02 CAP CER CHP 0.10UF 16V
C147 2313960B01 CAP,FXD,1UF,+10%,-10%,
16V-DC,SM,-55DEG CMIN,
125DEG CMAX,87MA,E
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
