Motorola ATS 3000

9.1-50 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C148 2113944A40 CAP CER CHP 100.0PF 50V
5%
C149 2113945B02 CAP CER CHP 10,000PF 25V
10%
C170 2113944M27 CAP,FXD,24PF,+2%,-2%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C171 2113944C45 CAP CER CHP 100.0PF 50V
5%
C172 2113944M16 CAP,FXD,8.2PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C173 2113944M29 CAP,FXD,30PF,+2%,-2%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C174 2113944M13 CAP,FXD,6.2PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C175 2113944M28 CAP,FXD,27PF,+2%,-2%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C176 2113944M20 CAP,FXD,12PF,+2%,-2%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C177 2113944M24 CAP,FXD,18PF,+2%,-2%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C178 2113944A28 CAP CER CHP 18.0PF 50V 5%
C179 2113944C04 CAP CER CHP 330.0PF 50V
5%
C180 NOT PLACED –
C181 NOT PLACED –
C182 2113944C04 CAP CER CHP 330.0PF 50V
5%
C185 2113945B02 CAP CER CHP 10,000PF 25V
10%
C186 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C187 2113944C04 CAP CER CHP 330.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C188 2113945A03 CAP CER CHP 330PF 50V 10%
C189 2113945A03 CAP CER CHP 330PF 50V 10%
C190 2113945A05 CAP CER CHP 470PF 50V 10%
C191 NOT PLACED –
C200 2113945A13 CAP CER CHP 4700PF 50V
10%
C201 2189705V01 CAP,CER,.1UF,+5%,-5%,
50V-DC,-55DEG CMIN,85DEG
CMAX,PB-FREE
C202 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C203 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C204 2171115L01 CHIP MONOLITHIC CERAMIC
CAPACITOR
C206 2113946K02 CAP CER CHP 0.10UF 16V
C207 2113946K02 CAP CER CHP 0.10UF 16V
C208 2113946K02 CAP CER CHP 0.10UF 16V
C209 2113946K02 CAP CER CHP 0.10UF 16V
C210 2313960D07 CAP,FXD,10UF,+10%,-10%,
16V-DC,SM,-55DEG CMIN,
125DEG CMAX,174MA
C211 2113946K02 CAP CER CHP 0.10UF 16V
C212 2113945A03 CAP CER CHP 330PF 50V 10%
C213 2113946K02 CAP CER CHP 0.10UF 16V
C214 2113945B02 CAP CER CHP 10,000PF 25V
10%
C215 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113945A03 CAP CER CHP 330PF 50V 10%
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2313960D07 CAP,FXD,10UF,+10%,-10%,
16V-DC,SM,-55DEG CMIN,
125DEG CMAX,174MA
C220 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C221 2113945A03 CAP CER CHP 330PF 50V 10%
C222 2313960D07 CAP,FXD,10UF,+10%,-10%,
16V-DC,SM,-55DEG CMIN,
125DEG CMAX,174MA
C223 2113945A03 CAP CER CHP 330PF 50V 10%
C226 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C227 2113945L13 CAP,FXD,330PF,+5%,-5%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C228 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C229 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C230 2113946K02 CAP CER CHP 0.10UF 16V
C231 2113945A01 CAP CER CHP 220PF 50V 10,
C232 2113946K02 CAP CER CHP 0.10UF 16V
C233 2113946K02 CAP CER CHP 0.10UF 16V
C234 2113945A03 CAP CER CHP 330PF 50V 10%
C235 2113944A40 CAP CER CHP 100.0PF 50V
5%
C236 2189705V01 CAP,CER,.1UF,+5%,-5%,
50V-DC,-55DEG CMIN,85DEG
CMAX,PB-FREE
C237 2189705V01 CAP,CER,.1UF,+5%,-5%,
50V-DC,-55DEG CMIN,85DEG
CMAX,PB-FREE
C238 2189705V01 CAP,CER,.1UF,+5%,-5%,
50V-DC,-55DEG CMIN,85DEG
CMAX,PB-FREE
C239 2189705V01 CAP,CER,.1UF,+5%,-5%,
50V-DC,-55DEG CMIN,85DEG
CMAX,PB-FREE
C240 2189705V01 CAP,CER,.1UF,+5%,-5%,
50V-DC,-55DEG CMIN,85DEG
CMAX,PB-FREE
C243 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C245 2113944A40 CAP CER CHP 100.0PF 50V
5%
C246 2113946N03 CAP CER CHP 2.2UF 16V
C247 2113945A09 CAP CER CHP 1000PF 50V
10%
C248 NOT PLACED –
C249 2113945A09 CAP CER CHP 1000PF 50V
10%
C252 2113944C78 CAP,FXD,13PF,+5%,-5%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C253 2113944C78 CAP,FXD,13PF,+5%,-5%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C254 2113944C18 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C255 2113944C63 CAP,FXD,1PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C256 2113945L13 CAP,FXD,330PF,+5%,-5%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C257 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMAX
C258 2113945A03 CAP CER CHP 330PF 50V 10%
C261 2113945A03 CAP CER CHP 330PF 50V 10%
C262 2113945A03 CAP CER CHP 330PF 50V 10%
C263 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C266 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C267 2113944A61 CAP,FXD,.5PF,.25PF+/-,
50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C271 2113944C32 CAP CER CHP 15.0PF 50V 5%
C272 2113944C32 CAP CER CHP 15.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
