Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-51
6816985H01-F February 14, 2012
C273 2188881Y12 CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z12)
C274 2113944V03 CAP,FXD,1PF,.1PF+/-,50V-DC,
0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C275 2113945A03 CAP CER CHP 330PF 50V 10%
C276 2113944A61 CAP,FXD,.5PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C277 2113945A03 CAP CER CHP 330PF 50V 10%
C278 2113944A18 CAP CER CHP 5.1PF 50V +/-
0.5PF
C279 2113945A03 CAP CER CHP 330PF 50V 10%
C286 2113945A03 CAP CER CHP 330PF 50V 10%
C292 2113945A03 CAP CER CHP 330PF 50V 10%
C293 2113945A03 CAP CER CHP 330PF 50V 10%
C294 2113945A03 CAP CER CHP 330PF 50V 10%
C295 2113945A09 CAP CER CHP 1000PF 50V
10%
C296 2113945A09 CAP CER CHP 1000PF 50V
10%
C400 2113944A40 CAP CER CHP 100.0PF 50V
5%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C405 2113944A40 CAP CER CHP 100.0PF 50V
5%
C411 2113945A11 CAP CER CHP 2200PF 50V
10%
C412 NOT PLACED –
C416 2113946K02 CAP CER CHP 0.10UF 16V
C417 2113944A40 CAP CER CHP 100.0PF 50V
5%
C421 NOT PLACED –
C422 2113945B02 CAP CER CHP 10,000PF 25V
10%
C423 2113944C41 CAP CER CHP 68.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C424 2113944A40 CAP CER CHP 100.0PF 50V
5%
C425 2113945H69 CAP,FXD,.1UF,+5%,-5%,
50V-DC,1206,X7R,-55DEG
CMIN,125DEG CMAX,PB
C428 2113944A29 CAP CER CHP 22.0PF 50V 5%
C429 2113946K02 CAP CER CHP 0.10UF 16V
C430 2113946K02 CAP CER CHP 0.10UF 16V
C431 2113946K02 CAP CER CHP 0.10UF 16V
C432 2113946K02 CAP CER CHP 0.10UF 16V
C433 2113944C33 CAP CER CHP 18.0PF 50V 5%
C434 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C435 2113944A36 CAP CER CHP 68.0PF 50V 5%
C436 2113944A40 CAP CER CHP 100.0PF 50V
5%
C437 2113944C85 CAP,FXD,51PF,+5%,-5%,
50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C438 2113944C40 CAP CER CHP 62.0PF 50V 5%
C440 2113945G96 CAP,FXD,.33UF,+10%,-10%,
50V-DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
C441 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN,
125DEG CMAX,47MA,E
C442 2113945B02 CAP CER CHP 10,000PF 25V
10%
C447 NOT PLACED –
C448 2113945C25 CAP,FXD,.033UF,+10%,-10%,5
0V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C449 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C461 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C463 2113945C27 CAP,FXD,.047UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C464 2113946K02 CAP CER CHP 0.10UF 16V
C465 2113946K02 CAP CER CHP 0.10UF 16V
C470 2113946K02 CAP CER CHP 0.10UF 16V
C472 2113946K02 CAP CER CHP 0.10UF 16V
C473 2113946K02 CAP CER CHP 0.10UF 16V
C475 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMAX
C476 2113944C89 CAP,FXD,200PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,P
C478 2113945C27 CAP,FXD,.047UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C480 2313960M26 CAP,FXD,1UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,47MA,E
C481 2313960B30 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,122MA
C482 2313960B30 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,122MA
C500 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMAX
C501 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMAX
C502 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMAX
C503 2113945A58 CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMAX
C504 2113945A03 CAP CER CHP 330PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C505 2113945G98 CAP,FXD,.47UF,+10%,-10%,
50V-DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
C506 2113946E02 CAP CER CHP 1.0UF 16V 10%
C507 2113945B02 CAP CER CHP 10,000PF 25V
10%
C508 2113945B02 CAP CER CHP 10,000PF 25V
10%
C509 2113945B02 CAP CER CHP 10,000PF 25V
10%
C510 2113946K02 CAP CER CHP 0.10UF 16V
C511 2113946K02 CAP CER CHP 0.10UF 16V
C512 2113946K02 CAP CER CHP 0.10UF 16V
C513 2113955E11 CAP,FXD,1UF,+10%,-10%,
50V-DC,X7R,-55DEG CMIN,
125DEG CMAX,PB-FR
C514 2113955E11 CAP,FXD,1UF,+10%,-10%,
50V-DC,X7R,-55DEG CMIN,
125DEG CMAX,PB-FR
C516 2113946E02 CAP CER CHP 1.0UF 16V 10%
C517 2113946E02 CAP CER CHP 1.0UF 16V 10%
C518 2313960B57 CAP,FXD,10UF,+10%,-
10%,6.3V-DC,SM,-55DEG
CMIN,125DEG CMAX,137MA
C519 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C520 2113945A05 CAP CER CHP 470PF 50V 10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2313960H04 CAP,FXD,33UF,+10%,-10%,
16V-DC,SM,-55DEG
CMIN,125DEG CMAX,433MA
C525 2113945L25 CAP,FXD,1000PF,+5%,-5%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
