Motorola ATS 3000

9.1-52 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C526 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C527 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C528 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C550 2113945B02 CAP CER CHP 10,000PF 25V
10%
C551 2113945B02 CAP CER CHP 10,000PF 25V
10%
C607 2113946K02 CAP CER CHP 0.10UF 16V
C610 2113944A32 CAP CER CHP 39.0PF 50V 5%
C611 2113944A32 CAP CER CHP 39.0PF 50V 5%
C612 2113944A32 CAP CER CHP 39.0PF 50V 5%
C613 2113944A32 CAP CER CHP 39.0PF 50V 5%
C614 2113945A03 CAP CER CHP 330PF 50V 10%
C615 2113944A32 CAP CER CHP 39.0PF 50V 5%
C617 2113944A32 CAP CER CHP 39.0PF 50V 5%
C619 2113944A32 CAP CER CHP 39.0PF 50V 5%
C620 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C621 2113946K02 CAP CER CHP 0.10UF 16V
C629 2113945A03 CAP CER CHP 330PF 50V 10%
C630 2113945A03 CAP CER CHP 330PF 50V 10%
C631 2113945A03 CAP CER CHP 330PF 50V 10%
C632 2113945A03 CAP CER CHP 330PF 50V 10%
C633 2113945A03 CAP CER CHP 330PF 50V 10%
C634 2113945A03 CAP CER CHP 330PF 50V 10%
C635 2113945A03 CAP CER CHP 330PF 50V 10%
C636 2113945A03 CAP CER CHP 330PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C637 2113945L49 CAP,FXD,.01UF,+5%,-5%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C638 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C640 NOT PLACED –
C641 NOT PLACED –
C652 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C653 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C654 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C655 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C656 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C657 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C658 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C671 2113944A31 CAP CER CHP 33.0PF 50V 5%
C672 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C673 2113944A31 CAP CER CHP 33.0PF 50V 5%
C674 2113945A05 CAP CER CHP 470PF 50V 10%
C675 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C680 2113944A31 CAP CER CHP 33.0PF 50V 5%
C700 2113946B04 CAP CER CHP 0.10UF 10V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C701 2113944A19 CAP CER CHP 5.6PF 50V +/-
0.5PF
C702 2113944A19 CAP CER CHP 5.6PF 50V +/-
0.5PF
C703 NOT PLACED –
C704 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C705 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C706 2113945A09 CAP CER CHP 1000PF 50V
10%
C708 2113944A31 CAP CER CHP 33.0PF 50V 5%
C709 2113944A31 CAP CER CHP 33.0PF 50V 5%
C710 2113946J03 CAP CER CHP 10.0UF 16V
10%
C711 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C712 2113946E02 CAP CER CHP 1.0UF 16V 10%
C713 2314030F56 CAP,FXD,68UF,+10%,-10%,
6.3V-DC,SM,-55DEG CMIN,
125DEG CMAX,742MA
C714 2113945A09 CAP CER CHP 1000PF 50V
10%
C715 2313960F30 CAP,FXD,47UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN,
125DEG CMAX,303MA
C716 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C717 2113946E02 CAP CER CHP 1.0UF 16V 10%
C718 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C719 2113946E02 CAP CER CHP 1.0UF 16V 10%
C720 2113946G01 CAP CER CHP 2.2UF 16V 10%
C721 2113946E02 CAP CER CHP 1.0UF 16V 10%
C722 2113946E02 CAP CER CHP 1.0UF 16V 10%
C723 2113946E02 CAP CER CHP 1.0UF 16V 10%
C724 2113946E02 CAP CER CHP 1.0UF 16V 10%
C725 2113946K02 CAP CER CHP 0.10UF 16V
C726 2113944F07 CAP,CHIP,1000PF,+5%,-5%,
50V-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C727 2113944A40 CAP CER CHP 100.0PF 50V
5%
C728 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CMAX
C729 2113946J03 CAP CER CHP 10.0UF 16V
10%
C730 2113944A40 CAP CER CHP 100.0PF 50V
5%
C731 2113946G01 CAP CER CHP 2.2UF 16V 10%
C732 2113944A40 CAP CER CHP 100.0PF 50V
5%
C734 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C735 2113946E02 CAP CER CHP 1.0UF 16V 10%
C736 2113946J03 CAP CER CHP 10.0UF 16V
10%
C737 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C738 2113946K02 CAP CER CHP 0.10UF 16V
C742 2113945A05 CAP CER CHP 470PF 50V 10%
C743 2113944A25 CAP CER CHP 10.0PF 50V +/-
0.5PF
C750 2113946J03 CAP CER CHP 10.0UF 16V
10%
C751 2113946J03 CAP CER CHP 10.0UF 16V
10%
C752 2113944A40 CAP CER CHP 100.0PF 50V
5%
C753 2113944A40 CAP CER CHP 100.0PF 50V
5%
C754 2113946E02 CAP CER CHP 1.0UF 16V 10%
C755 2113946E02 CAP CER CHP 1.0UF 16V 10%
C756 2113944A40 CAP CER CHP 100.0PF 50V
5%
C757 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
