Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-53
6816985H01-F February 14, 2012
C758 2113946E02 CAP CER CHP 1.0UF 16V 10%
C759 2113946E02 CAP CER CHP 1.0UF 16V 10%
C760 2113944A40 CAP CER CHP 100.0PF 50V
5%
C761 2113944A40 CAP CER CHP 100.0PF 50V
5%
C762 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C763 2113944A40 CAP CER CHP 100.0PF 50V
5%
C764 2113946B03 CAP CER CHP 0.068UF 10V 10
C765 2113946B03 CAP CER CHP 0.068UF 10V 10
C766 2113944A40 CAP CER CHP 100.0PF 50V
5%
C767 2113944A40 CAP CER CHP 100.0PF 50V
5%
C768 2113944A40 CAP CER CHP 100.0PF 50V
5%
C769 2113944A40 CAP CER CHP 100.0PF 50V
5%
C770 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C771 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C773 2113946K02 CAP CER CHP 0.10UF 16V
C790 2113946A02 CAP CER CHP 0.022UF 16V
10,
C791 2113946K02 CAP CER CHP 0.10UF 16V
C792 2113946K02 CAP CER CHP 0.10UF 16V
C796 NOT PLACED –
C800 2113955D31 CAP,FXD,1UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
CMIN,125DEG CMAX,P
C801 2113945A05 CAP CER CHP 470PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C802 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C803 2113945A05 CAP CER CHP 470PF 50V 10%
C804 2113946E02 CAP CER CHP 1.0UF 16V 10%
C805 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C806 2113946K02 CAP CER CHP 0.10UF 16V
C807 2113946K02 CAP CER CHP 0.10UF 16V
C808 2113946K02 CAP CER CHP 0.10UF 16V
C809 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C810 2113946E02 CAP CER CHP 1.0UF 16V 10%
C811 2113946K02 CAP CER CHP 0.10UF 16V
C812 2113946K02 CAP CER CHP 0.10UF 16V
C813 2113946K02 CAP CER CHP 0.10UF 16V
C814 2113946K02 CAP CER CHP 0.10UF 16V
C815 2113946K02 CAP CER CHP 0.10UF 16V
C816 2113946K02 CAP CER CHP 0.10UF 16V
C817 2113946K02 CAP CER CHP 0.10UF 16V
C818 2113946K02 CAP CER CHP 0.10UF 16V
C830 2113946K02 CAP CER CHP 0.10UF 16V
C840 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C850 2113945A03 CAP CER CHP 330PF 50V 10%
C851 2113944A40 CAP CER CHP 100.0PF 50V
5%
C855 NOT PLACED –
C856 NOT PLACED –
C857 NOT PLACED –
C858 2113945B02 CAP CER CHP 10,000PF 25V
10%
C859 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C860 2113945B02 CAP CER CHP 10,000PF 25V
10%
C861 2113945B02 CAP CER CHP 10,000PF 25V
10%
C862 2113945B02 CAP CER CHP 10,000PF 25V
10%
C863 2113945B02 CAP CER CHP 10,000PF 25V
10%
C864 2113945B02 CAP CER CHP 10,000PF 25V
10%
C865 2113945B02 CAP CER CHP 10,000PF 25V
10%
C866 2113945B02 CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED –
C868 NOT PLACED –
CR800 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
CR801 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D3 4815096H01 VARACTOR DIODE 1SV305
D4 4815096H01 VARACTOR DIODE 1SV305
D5 4815096H01 VARACTOR DIODE 1SV305
D6 4815096H01 VARACTOR DIODE 1SV305
D10 4815096H01 VARACTOR DIODE 1SV305
D11 4815096H01 VARACTOR DIODE 1SV305
D12 4815096H01 VARACTOR DIODE 1SV305
D13 4815096H01 VARACTOR DIODE 1SV305
D20 4808115L27 DIODE,PIN,DH50037,SM,
SOT-323,30V
D104 4816487H01 SWITCHING DIODE, MINI-
BLOC
D170 4802482J02 PIN DIODE SMD
D171 4802482J02 PIN DIODE SMD
D172 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2,PB-FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D173 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2,PB-FREE
D201 4815011H01 DIODE TRIPLE
D202 4815011H01 DIODE TRIPLE
D251 4885094Y01 DIODE VARACTOR ISV228
W18
D252 4885094Y01 DIODE VARACTOR ISV228
W18
D270 4885094Y01 DIODE VARACTOR ISV228
W18
D401 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D402 4805656W41 DIODE VARACTOR 40PFV
15PFV
D500 4815155H01 RECTIFIER
D501 4809118D02 LED BICOLOR
LNJ115W8POMT
D510 4813978M15 DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D511 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V,.2W,
SHTK,PB-FREE
D512 4813978M15 DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D513 4813978M15 DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D600 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
D603 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
E102 2480574F01 IND FERRITE CHIP 60OHM
0603
E140 2405688Z01 INDUCTOR FERRITE BEAD
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
