Motorola ATS 3000

9.1-54 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
E141 2480574F01 IND FERRITE CHIP 60OHM
0603
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MHZ
SRF,SM,PB-FREE
E800 2480574F01 IND FERRITE CHIP 60OHM
0603
E801 2480574F01 IND FERRITE CHIP 60OHM
0603
E802 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
F500 6515076H01 FUSE CHIP SMT TR/1608FF
3A
FL51 9185367C01 XTAL FLTR 5X7 SURFACE MT
MONO
FL200 9116848H01 FLTR SW CAP 3 POLE
BUTTERW, W18
J101 2880658Z08 CONNECTOR SMA
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L5 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L6 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ
SRF,SM,0805,PB-
L7 2414032F33 IDCTR,WW,82NH,5%,400MA,
.42OHM,CER,40 Q,1.02GHZ
SRF,SM,PB-FR
L8 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ
SRF,SM,0805,PB-
L12 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L20 2414032F38 IDCTR,WW,220NH,5%,400MA,
.7OHM,CER,30 Q,630MHZ
SRF,SM,PB-FRE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L21 2414032F31 IDCTR,WW,56NH,5%,500MA,
.34OHM,CER,40 Q,1.3GHZ
SRF,SM,PB-FRE
L28 2414032F26 IDCTR,WW,22NH,5%,500MA,
.22OHM,CER,45 Q,2.2GHZ
SRF,SM,PB-FRE
L31 2414032F34 IDCTR,WW,100NH,5%,400MA,
.46OHM,CER,40 Q,950MHZ
SRF,SM,PB-FR
L34 2414032F35 IDCTR,WW,120NH,5%,400MA,
.51OHM,CER,35 Q,860MHZ
SRF,SM,PB-FR
L42 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L45 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ
SRF,SM,0805,PB-
L47 2414032F33 IDCTR,WW,82NH,5%,400MA,
.42OHM,CER,40 Q,1.02GHZ
SRF,SM,PB-FR
L48 2414032F27 IDCTR,FXD,27NH,5%,500MA,
.25OHM,CER,45 Q,2GHZ
SRF,SM,0805,PB-
L49 2414032F24 IDCTR,WW,15NH,5%,600MA,
.17OHM,CER,45 Q,2.5GHZ
SRF,SM,PB-FRE
L54 2414032F73 IDCTR,WW,820NH,5%,180MA,
2.23OHM,CER,23 Q,215MHZ
SRF,SM,PB-F
L55 0613958T74 CER CHIP RES 0.0 OHM JMP
1206
L56 2414032D25 IDCTR,WW,620NH,5%,400MA,
1.6OHM,CER,28 Q,400MHZ
SRF,SM,PB-FR
L60 2414017G13 IDCTR,CHIP,33NH,5%,300MA,
.65OHM,CER,8 Q,SM,0603,
PB-FREE
L61 2414017N16 IDCTR,CHIP,22NH,5%,600MA,
.54OHM,CER,12 Q,1.3GHZ
SRF,SM,0603
L62 2414017N16 IDCTR,CHIP,22NH,5%,600MA,
.54OHM,CER,12 Q,1.3GHZ
SRF,SM,0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L63 2414017Q40 IDCTR,FXD,270NH,10%,250M
A,.5OHM,FERR,20 Q,150MHZ
SRF,SM,0805
L64 NOT PLACED –
L101 2414017N10 IDCTR,CHIP,6.8NH,5%,600MA,
.22OHM,CER,10 Q,2.7GHZ
SRF,SM,0603
L106 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L114 2414032B60 IDCTR,WW,390NH,5%,620MA,
1.12OHM,CER,30 Q,465MHZ
SRF,SM,PB-F
L115 2460591B80 COIL AIR WOUND INDUC
19.61
L117 2414017N18 IDCTR,CHIP,33NH,5%,600MA,
.71OHM,CER,12 Q,1.1GHZ
SRF,SM,0603
L118 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
L119 2479990E01 COIL AIR WOUND/GREEN
CLR 23.75
L120 NOT PLACED –
L121 NOT PLACED –
L125 2479990A02 AIR WND COIL/GREEN
COLOR7.66NH
L126 2415428H01 AIR WOUND INDUCTOR
L127 2479990E01 COIL AIR WOUND/GREEN
CLR 23.75
L128 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L170 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L171 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L172 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
L176 2479990N01 AIR WND COIL/GREEN
COLOR 43.67
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L200 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
SRF,SM,0805,PB
L201 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L202 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L203 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L204 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L205 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
SRF,SM,0805,PB
L206 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L251 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L252 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L253 2460591C35 COIL AIR WOUND INDUC
18.08
L254 2460591C03 COIL AIR WOUND INDUC
11.87
L257 0613958T74 CER CHIP RES 0.0 OHM JMP
1206
L258 2414032D17 IDCTR,WW,150NH,5%,750MA,
.31OHM,CER,40 Q,850MHZ
SRF,SM,PB-FR
L259 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L266 2414032D18 IDCTR,WW,180NH,5%,700MA,
.43OHM,CER,35 Q,780MHZ
SRF,SM,PB-FR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
