Motorola ATS 3000

VHF Schematics, Board Overlays, and Parts Lists 9.1-55
6816985H01-F February 14, 2012
L270 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L271 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
SRF,SM,LEAD-FR
L272 2414032B48 IDCTR,WW,39NH,5%,1A,
.15OHM,CER,50 Q,1.5GHZ
SRF,SM,PB-FREE
L273 2414032B46 IDCTR,WW,27NH,5%,1A,
.13OHM,CER,50 Q,1.5GHZ
SRF,SM,PB-FREE
L274 2414032D40 IDCTR,WW,33NH,5%,1A,.11O
HM,CER,42 Q,1.45GHZ
SRF,SM,PB-FREE
L403 2414032B75 IDCTR,WW,3.9UH,5%,340MA,
3.6OHM,CER,20 Q,70MHZ
SRF,SM,PB-FRE
L404 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30 Q,500MHZ
SRF,SM,PB-F
L407 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MHZ
SRF,SM,PB-FREE
L411 2466505A01 COIL INDUCTOR
L412 2466505A01 COIL INDUCTOR
L413 2414032B64 IDCTR,WW,680NH,5%,540MA,
1.47OHM,CER,30 Q,340MHZ
SRF,SM,PB-F
L414 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L500 2414017Q42 IDCTR,FXD,390NH,10%,200M
A,.65OHM,FERR,25 Q,135MHZ
SRF,SM,080
L501 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L502 2489669V01 IDCTR,WW,100UH,5%,40MA,
10OHM,20 Q,10MHZ SRF,SM,
1210,PB-FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L651 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
SRF,SM,0805,PB-
L652 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
SRF,SM,0805,PB-
L701 2486085A01 COIL, POWER INDUCTOR
L702 2486085A01 COIL, POWER INDUCTOR
L703 2464675H01 IDCTR,WW,560NH,5%,550MA
L704 2464675H01 IDCTR,WW,560NH,5%,550MA
L705 2464675H01 IDCTR,WW,560NH,5%,550MA
L708 2416307H01 IDCTR,WW,680NH,5%,0603
L710 2416307H01 IDCTR,WW,680NH,5%,0603
M701 0985888K02 SKT RTC BTTY LEAP
P4 3905643V01 CONTACT ANT GRD
P100 3916333H02 GROUND CONTACT
Q29 4805585Q27 TRANSISTOR RF NPN,
BFQ67W NOPB
Q101 4816698H02 TRANSISTOR,FET RF
POWER,N-CHANNEL,
RD12MVP1-T122,SM,60V,
MOD,XSTR,FET RF PWR,VHF
Q197 4813973A13 XSTR,GEN PURPOSE SMALL
SIG,PNP,MMBT3906L,
TO-236,4, PB-FREE
Q200 4871674S01 XSTR,BIP GP SS
Q301 4816371H01 XSTR DUAL PNP W18
COMPLIANT
Q401 4805585Q27 TRANSISTOR RF NPN,
BFQ67W NOPB
Q402 4813973A04 XSTR,BIP GP SS,NPN,TA13,
SM,SOT-23,SMT,30V,.225W,
300MA,125MHZ,P
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA,PB-FR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q700 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W,
PB-FREE
Q701 4813973M07 XSTR,BIP GP SS,NPN,T3904,
SM,SOT-23,SMT,40V,.225W,
200MA,300MHZ
Q702 5185956E76 IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V,HI
SPD SWTH DR
Q703 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W,
PB-FREE
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42 XSTR,BIP GP SS,NPN,SM,
SC-59,SMT,50V,.23W,100MA,
PB-FREE
Q804 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA,PB-FR
R13 0613952R01 CER CHIP RES 10K OHM 5%
0402
R14 0613952R01 CER CHIP RES 10K OHM 5%
0402
R15 NOT PLACED –
R22 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R23 0613952R31 CER CHIP RES 180K OHM 5%
0402
R24 0613952R31 CER CHIP RES 180K OHM 5%
0402
R26 0613952Q83 CER CHIP RES 2700 OHM 5
0402
R30 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R32 0613952H33 CER CHIP RES 22.0 OHM 5%
0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R33 0613952R01 CER CHIP RES 10K OHM 5%
0402
R34 0613952R01 CER CHIP RES 10K OHM 5%
0402
R60 0613952Q49 CER CHIP RES 100 OHM 5
0402
R102 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R103 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R104 0613952J15 CER CHIP RES 39K OHM 5%
0603
R105 NOT PLACED –
R108 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R109 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R115 0613958H57 CER CHIP RES 220 OHM 5%
0805
R125 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R127 0613952R01 CER CHIP RES 10K OHM 5%
0402
R142 0613952Z55 RES,MF,12KOHM,1%,.0625W,
SM,0402,200PPM/CEL,
PB-FREE
R143 0613952Z65 RES,MF,43KOHM,1%,.0625W,
SM,0402,200PPM/CEL,
PB-FREE
R144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R146 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R149 0613952Q89 CER CHIP RES 4700 OHM 5
0402
R150 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R151 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R153 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
