Motorola ATS 3000

9.1-56 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R154 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R155 0613952Q77 CER CHIP RES 1500 OHM 5
0402
R156 NOT PLACED –
R157 0613952Q71 CER CHIP RES 820 OHM 5
0402
R158 0613952Q49 CER CHIP RES 100 OHM 5
0402
R159 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R160 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R161 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R162 NOT PLACED –
R168 0613952Q49 CER CHIP RES 100 OHM 5
0402
R169 0613952Q49 CER CHIP RES 100 OHM 5
0402
R199 0613952J01 CER CHIP RES 10K OHM 5%
0603
R201 0613952Q47 CER CHIP RES 82.0 OHM 5%
0402
R202 0613952Q69 CER CHIP RES 680 OHM 5
0402
R203 0613952Q57 CER CHIP RES 220 OHM 5
0402
R204 0613952R19 CER CHIP RES 56K OHM 5%
0402
R205 0613952R15 CER CHIP RES 39K OHM 5%
0402
R206 0613952R01 CER CHIP RES 10K OHM 5%
0402
R207 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R208 0613952R13 CER CHIP RES 33K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R209 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R210 0613952R13 CER CHIP RES 33K OHM 5%
0402
R211 0613952Q80 CER CHIP RES 2000 OHM 5
0402
R212 NOT PLACED –
R213 0613952Q95 CER CHIP RES 8200 OHM 5
0402
R214 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R215 0613952R01 CER CHIP RES 10K OHM 5%
0402
R216 0613952K93 CER CHIP RES 90.9 OHM 1
0402
R251 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R252 0613952Q36 CER CHIP RES 30.0 OHM 5
0402
R253 0613952Q61 CER CHIP RES 330 OHM 5
0402
R254 0613952R35 CER CHIP RES 270K OHM 5%
0402
R255 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R257 0613952R01 CER CHIP RES 10K OHM 5%
0402
R266 0613952Q61 CER CHIP RES 330 OHM 5
0402
R270 0613952Q38 CER CHIP RES 36.0 OHM 5
0402
R271 0613952Q59 CER CHIP RES 270 OHM 5
0402
R272 0613952Q56 CER CHIP RES 200 OHM 5
0402
R273 0613952Q65 CER CHIP RES 470 OHM 5
0402
R274 0613952Q29 CER CHIP RES 15.0 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R275 0613952Q65 CER CHIP RES 470 OHM 5
0402
R277 0613952R01 CER CHIP RES 10K OHM 5%
0402
R291 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R293 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R294 0613952Q61 CER CHIP RES 330 OHM 5
0402
R295 0613952R01 CER CHIP RES 10K OHM 5%
0402
R406 0613952R01 CER CHIP RES 10K OHM 5%
0402
R407 0613952R01 CER CHIP RES 10K OHM 5%
0402
R408 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R412 0613952H62 CER CHIP RES 360 OHM 5
0603
R413 0613952H68 CER CHIP RES 620 OHM 5
0603
R414 0613952R07 CER CHIP RES 18K OHM 5%
0402
R415 0613952R03 CER CHIP RES 12K OHM 5%
0402
R417 0613952Q74 RES,MF,1.1KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952R25 CER CHIP RES 100K OHM 5%
0402
R420 0613952R19 CER CHIP RES 56K OHM 5%
0402
R436 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R499 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R503 0613952Q63 CER CHIP RES 390 OHM 5
0402
R504 0613952Q66 CER CHIP RES 510 OHM 5
0402
R505 0613952Q93 CER CHIP RES 6800 OHM 5
0402
R507 0613952Q49 CER CHIP RES 100 OHM 5
0402
R508 0613952Q49 CER CHIP RES 100 OHM 5
0402
R509 0613952Q49 CER CHIP RES 100 OHM 5
0402
R510 0613952Q49 CER CHIP RES 100 OHM 5
0402
R511 0613952R01 CER CHIP RES 10K OHM 5%
0402
R512 0613952R17 CER CHIP RES 47K OHM 5%
0402
R513 0613952R01 CER CHIP RES 10K OHM 5%
0402
R514 0613952R01 CER CHIP RES 10K OHM 5%
0402
R515 0613952R01 CER CHIP RES 10K OHM 5%
0402
R516 0613952R01 CER CHIP RES 10K OHM 5%
0402
R517 0613952R01 CER CHIP RES 10K OHM 5%
0402
R518 0613952R01 CER CHIP RES 10K OHM 5%
0402
R519 0613952R17 CER CHIP RES 47K OHM 5%
0402
R520 0613952R37 CER CHIP RES 330K OHM 5%
0402
R521 NOT PLACED –
R522 0613952R17 CER CHIP RES 47K OHM 5%
0402
R523 0613952R17 CER CHIP RES 47K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
