Motorola ATS 3000 User Manual

9.2-38 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
PMLE2537A/ PMLE2537D/ PMUE4003A/
PMUE4004A/PMUE4005A/PMUE4006A/
PMUE3661A/PMUE3660A/PMUE3663A/
PMUE3664A Main Circuit Board
Electrical Parts List
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02 CONNECTOR (CONTACT
BATTERY)
C2 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C3 NOT PLACED –
C4 NOT PLACED –
C9 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C20 2113944A40 CAP CER CHP 100.0PF 50V
5%
C33 2113944A40 CAP CER CHP 100.0PF 50V
5%
C35 2113944A34 CAP CER CHP 56.0PF 50V 5%
C41 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C43 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC,0402,C0G, -55DEG C
C44 2113946K02 CAP CER CHP 0.10UF 16V
C46 2113944A40 CAP CER CHP 100.0PF 50V
5%
C48 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C51 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C54 2113944M01 CAP,FXD,2PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CM
C55 2113945B02 CAP CER CHP 10,000PF 25V
10%
C57 2113944M12 CAP,FXD,5.6PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
C58 2113944M07 CAP,FXD,3.6PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C59 NOT PLACED –
C60 NOT PLACED –
C61 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C62 2113944A29 CAP CER CHP 22.0PF 50V 5%
C63 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C64 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC ,0402,C0G,-55DEG C
C65 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C66 2113946K02 CAP CER CHP 0.10UF 16V
C67 2113946B04 CAP CER CHP 0.10UF 10V
10%
C68 NOT PLACED –
C69 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C70 2113944A40 CAP CER CHP 100.0PF 50V
5%
C71 2113944A80 CAP,FXD,20PF,+5%,-5%,50V-
DC, 0402,C0G,-55DEG C
C72 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C73 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C74 2113944A29 CAP CER CHP 22.0PF 50V 5%
C75 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C76 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC ,0402,C0G,-55DEG C
C77 2113945B02 CAP CER CHP 10,000PF 25V
10%
C78 2113944A40 CAP CER CHP 100.0PF 50V
5%
C79 2113944A40 CAP CER CHP 100.0PF 50V
5%
C80 2113945B02 CAP CER CHP 10,000PF 25V
10%
C82 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C83 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C84 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C85 2113944A07 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C86 2113944A07 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C87 2113944A40 CAP CER CHP 100.0PF 50V
5%
C88 2113945B02 CAP CER CHP 10,000PF 25V
10%
C89 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C90 2113944A40 CAP CER CHP 100.0PF 50V
5%
C100 2113944C45 CAP CER CHP 100.0PF 50V
5%
C102 2113944A40 CAP CER CHP 100.0PF 50V
5%
C103 2113945B02 CAP CER CHP 10,000PF 25V
10%
C104 2113944A40 CAP CER CHP 100.0PF 50V
5%
C108 2113945B02 CAP CER CHP 10,000PF 25V
10%
C109 2113945B02 CAP CER CHP 10,000PF 25V
10%
C110 2113945B02 CAP CER CHP 10,000PF 25V
10%
C111 NOT PLACED –
C112 2113944A40 CAP CER CHP 100.0PF 50V
5%
C122 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
C130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C131 2113945B02 CAP CER CHP 10,000PF 25V
10%
C133 2113944C39 CAP CER CHP 56.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C135 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C139 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC, SM,-55DEG CMIN,
C140 2113944A40 CAP CER CHP 100.0PF 50V
5%
C141 2113944C45 CAP CER CHP 100.0PF 50V
5%
C142 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC,SM,-55DEG CMIN,
C143 2113945A10 CAP CER CHP 1500PF 50V
10%
C144 2113945A05 CAP CER CHP 470PF 50V 10%
C145 2113945B03 CAP,FXD,.015UF,+10%,-10%,
25V-DC,0402,X7R,-55
C146 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC, 0603,X7R,-
55DEG
C147 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC, SM,-55DEG CMIN,
C148 2113944A40 CAP CER CHP 100.0PF 50V
5%
C149 2113945B02 CAP CER CHP 10,000PF 25V
10%
C150 2113944A40 CAP CER CHP 100.0PF 50V
5%
C151 NOT PLACED –
C153 2113944C45 CAP CER CHP 100.0PF 50V
5%
C154 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
C156 2113944F60 CAP,FXD,56PF,+5%,-5%,
50V-DC, 0805,C0G,-55DEG C
C157 2116069H05 CHIP CAPACITOR-EPP PART
C158 2113951A36 CAP NPO 12.0PF +/-5% 250V
HI FREQ
C159 NOT PLACED –
C160 2103689A47 SL240J HIGH - Q CAPACITOR,
UCNO
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
