Motorola ATS 3000 User Manual

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-39
6816985H01-F February 14, 2012
C161 NOT PLACED –
C169 NOT PLACED –
C170 2113944C45 CAP CER CHP 100.0PF 50V
5%
C171 2113944C45 CAP CER CHP 100.0PF 50V
5%
C172 2113951C12 CAP,FXD,1.2PF,.05PF+/-,
250V-DC, 0603,C0G,-55DE
C173 2113944C13 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C174 2113944C15 CAP CER CHP 2.4PF 50V
+/- 0.25PF
C175 2113944C70 CAP,FXD,5.1PF,.25PF+/-,
50V-DC, 0603,C0G,-55DEG
C176 2113944C29 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C177 2113944C22 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C178 2113944A18 CAP CER CHP 5.1PF 50V
+/- 0.5PF
C179 2113944A40 CAP CER CHP 100.0PF 50V
5%
C182 2113944A40 CAP CER CHP 100.0PF 50V
5%
C185 2113945B02 CAP CER CHP 10,000PF 25V
10%
C186 NOT PLACED –
C187 2113944A40 CAP CER CHP 100.0PF 50V
5%
C188 2113944A40 CAP CER CHP 100.0PF 50V
5%
C189 2113944A40 CAP CER CHP 100.0PF 50V
5%
C191 NOT PLACED –
C192 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C193 NOT PLACED –
C200 2113945A13 CAP CER CHP 4700PF 50V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C201 2185419D06 CAP CER SUPER L/D 0.1UF
C202 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C203 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C204 2109720D20 CAP CHIP LOW DIST 2000
SOV
C206 2113946K02 CAP CER CHP 0.10UF 16V
C207 2113946K02 CAP CER CHP 0.10UF 16V
C208 2113946K02 CAP CER CHP 0.10UF 16V
C209 2113946K02 CAP CER CHP 0.10UF 16V
C210 2313960D07 CAP,FXD,10,+10,-10,16,
SM,-55MIN,125MAX,174,
C213 2113946K02 CAP CER CHP 0.10UF 16V
C214 2113945B02 CAP CER CHP 10,000PF 25V
10%
C215 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113944A40 CAP CER CHP 100.0PF 50V
5%
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,125MAX,174,
C220 2113945B02 CAP CER CHP 10,000PF 25V
10%
C221 2113944A40 CAP CER CHP 100.0PF 50V
5%
C222 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,125MAX,174,
C226 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C227 2113944C45 CAP CER CHP 100.0PF 50V
5%
C228 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C229 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C230 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C231 2113945A01 CAP CER CHP 220PF 50V 10,
C232 2113946K02 CAP CER CHP 0.10UF 16V
C233 2113946K02 CAP CER CHP 0.10UF 16V
C234 2113944A40 CAP CER CHP 100.0PF 50V
5%
C235 2113944A40 CAP CER CHP 100.0PF 50V
5%
C236 2185419D06 CAP CER SUPER L/D 0.1UF
C237 2185419D06 CAP CER SUPER L/D 0.1UF
C238 2185419D06 CAP CER SUPER L/D 0.1UF
C239 2185419D06 CAP CER SUPER L/D 0.1UF
C240 2185419D06 CAP CER SUPER L/D 0.1UF
C241 2113944A40 CAP CER CHP 100.0PF 50V
5%
C242 2113944A40 CAP CER CHP 100.0PF 50V
5%
C243 2113946K02 CAP CER CHP 0.10UF 16V
C244 2113946B04 CAP CER CHP 0.10UF 10V
10%
C245 2113944A40 CAP CER CHP 100.0PF 50V
5%
C246 2113946N03 CAP CER CHP 2.2UF 16V
C247 2113945A09 CAP CER CHP 1000PF 50V
10%
C248 NOT PLACED –
C249 2113945A09 CAP CER CHP 1000PF 50V
10%
C251 2113944M16 CAP,FXD,8.2PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C252 2113944M17 CAP,FXD,9.1PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C253 2113944A12 CAP CER CHP 3.0PF 50V
+/- 0.25PF
C254 2113946B04 CAP CER CHP 0.10UF 10V
10%
C255 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C256 2113944M18 CAP,FXD,10PF,+2.5%,-2.5%,
50V-DC,0603,C0G,-55D
C257 2113944M20 CAP,FXD,12PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C258 2113944M17 CAP,FXD,9.1PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C259 2113944M35 CAP,FXD,51PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C260 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C261 2113944A40 CAP CER CHP 100.0PF 50V
5%
C262 2113946B04 CAP CER CHP 0.10UF 10V
10%
C263 2113944A40 CAP CER CHP 100.0PF 50V
5%
C264 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C265 2113944A40 CAP CER CHP 100.0PF 50V
5%
C266 2113944A40 CAP CER CHP 100.0PF 50V
5%
C267 2113944A81 CAP,FXD,24PF,+5%,-5%,
50V-DC,0402,C0G,-55DEG C
C268 2113944A27 CAP CER CHP 15.0PF 50V 5%
C269 2113946B04 CAP CER CHP 0.10UF 10V
10%
C271 2113944M15 CAP,FXD,7.5PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C272 2113944M15 CAP,FXD,7.5PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C273 2113944A14 CAP CER CHP 3.6PF 50V
+/- 0.25PF
C274 2113944M14 CAP,FXD,6.8PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C275 2113944M20 CAP,FXD,12PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C276 2113944M16 CAP,FXD,8.2PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
