Motorola ATS 3000 User Manual

9.2-40 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C277 2113944M35 CAP,FXD,51PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C278 2113944A40 CAP CER CHP 100.0PF 50V
5%
C279 2113946B04 CAP CER CHP 0.10UF 10V
10%
C280 2113944A40 CAP CER CHP 100.0PF 50V
5%
C281 2113944A40 CAP CER CHP 100.0PF 50V
5%
C282 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C283 2113946B04 CAP CER CHP 0.10UF 10V
10%
C284 2113944A40 CAP CER CHP 100.0PF 50V
5%
C285 2113944A05 CAP CER CHP 1.5PF 50V
+/- 0.25PF
C286 2113944A40 CAP CER CHP 100.0PF 50V
5%
C287 2113944A40 CAP CER CHP 100.0PF 50V
5%
C288 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C289 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C290 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C291 2113944A40 CAP CER CHP 100.0PF 50V
5%
C292 2113946B04 CAP CER CHP 0.10UF 10V
10%
C293 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C294 2113944A28 CAP CER CHP 18.0PF 50V 5%
C295 2113944A40 CAP CER CHP 100.0PF 50V
5%
C400 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C401 2113946K02 CAP CER CHP 0.10UF 16V
C405 2113944A40 CAP CER CHP 100.0PF 50V
5%
C411 2113945A11 CAP CER CHP 2200PF 50V
10%
C412 NOT PLACED –
C416 2113946K02 CAP CER CHP 0.10UF 16V
C417 2113944A40 CAP CER CHP 100.0PF 50V
5%
C421 NOT PLACED –
C422 2113945B02 CAP CER CHP 10,000PF 25V
10%
C423 2113944C41 CAP CER CHP 68.0PF 50V 5%
C424 2113944A40 CAP CER CHP 100.0PF 50V
5%
C425 2113945H69 CAP,FXD,.1UF,+5%,-5%,
50V-DC, 1206,X7R,-55DEG C
C428 2113945B02 CAP CER CHP 10,000PF 25V
10%
C429 2113946K02 CAP CER CHP 0.10UF 16V
C430 2113946K02 CAP CER CHP 0.10UF 16V
C431 2113946K02 CAP CER CHP 0.10UF 16V
C432 2113946K02 CAP CER CHP 0.10UF 16V
C433 2113944C33 CAP CER CHP 18.0PF 50V 5%
C434 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C435 2113944A34 CAP CER CHP 56.0PF 50V 5%
C436 2113944A34 CAP CER CHP 56.0PF 50V 5%
C437 2113944C72 CAP,FXD,6.2PF,.25PF+/-,
50V-DC, 0603,C0G,-55DEG
C438 2113944C79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0603,C0G,-55DEG C
C440 2113945G96 CAP,FXD,.33UF,+10%,-10%,
50V-DC,0805,X7R,-55DE
C441 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC, SM,-55DEG CMIN,
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C442 2113945B02 CAP CER CHP 10,000PF 25V
10%
C447 NOT PLACED –
C448 2113945C25 CAP,FXD,.033UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C449 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C461 2113946K02 CAP CER CHP 0.10UF 16V
C463 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C464 2113946K02 CAP CER CHP 0.10UF 16V
C465 2113946K02 CAP CER CHP 0.10UF 16V
C470 2113946K02 CAP CER CHP 0.10UF 16V
C472 2113946K02 CAP CER CHP 0.10UF 16V
C473 2113946K02 CAP CER CHP 0.10UF 16V
C475 NOT PLACED –
C476 2113944C89 CAP,FXD,200PF,+5%,-5%,
50V-DC ,0603,C0G,-55DEG
C478 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C480 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN,
C481 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN
C482 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN
C500 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C501 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C502 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C503 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C504 2113944A40 CAP CER CHP 100.0PF 50V
5%
C505 2113945G98 CAP,FXD,.47UF,+10%,-10%
,50V-DC,0805,X7R,-55DE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C506 2113946E02 CAP CER CHP 1.0UF 16V 10%
C507 2113945B02 CAP CER CHP 10,000PF 25V
10%
C508 2113945B02 CAP CER CHP 10,000PF 25V
10%
C509 2113945B02 CAP CER CHP 10,000PF 25V
10%
C510 2113946K02 CAP CER CHP 0.10UF 16V
C511 2113946K02 CAP CER CHP 0.10UF 16V
C512 2113946K02 CAP CER CHP 0.10UF 16V
C513 2113955E37 CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R,-55DEG
C514 2113955E37 CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R,-55DEG
C516 2113946E02 CAP CER CHP 1.0UF 16V 10%
C517 2113946E02 CAP CER CHP 1.0UF 16V 10%
C518 2313960B57 CAP,FXD,10UF,+10%,-10%,
6.3V-DC,SM,-55DEG CMIN
C520 2113944A40 CAP CER CHP 100.0PF 50V
5%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2313960G32 CAP,FXD,10UF,+10%,-10%,
35V-DC,SM,-55DEG CMIN
C525 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C526 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C527 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
