Motorola ATS 3000

9.2-42 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C791 2113946K02 CAP CER CHP 0.10UF 16V
C792 2113946K02 CAP CER CHP 0.10UF 16V
C796 2113944A40 CAP CER CHP 100.0PF 50V
5%
C800 2113955D31 CAP,FXD,1UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
CR800 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
C801 2113944A40 CAP CER CHP 100.0PF 50V
5%
CR801 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
C802 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55
C803 2113944A40 CAP CER CHP 100.0PF 50V
5%
C804 2113946E02 CAP CER CHP 1.0UF 16V 10%
C805 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55
C806 2113946K02 CAP CER CHP 0.10UF 16V
C807 2113946K02 CAP CER CHP 0.10UF 16V
C808 2113946K02 CAP CER CHP 0.10UF 16V
C809 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55
C810 2113946E02 CAP CER CHP 1.0UF 16V 10%
C811 2113946K02 CAP CER CHP 0.10UF 16V
C812 2113946K02 CAP CER CHP 0.10UF 16V
C813 2113946K02 CAP CER CHP 0.10UF 16V
C814 2113946K02 CAP CER CHP 0.10UF 16V
C815 2113946K02 CAP CER CHP 0.10UF 16V
C816 2113946K02 CAP CER CHP 0.10UF 16V
C817 2113946K02 CAP CER CHP 0.10UF 16V
C818 2113946K02 CAP CER CHP 0.10UF 16V
C830 2113946K02 CAP CER CHP 0.10UF 16V
C840 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C850 2113945A03 CAP CER CHP 330PF 50V 10%
C851 2113944A40 CAP CER CHP 100.0PF 50V
5%
C855 NOT PLACED –
C856 NOT PLACED –
C857 NOT PLACED –
C858 2113945B02 CAP CER CHP 10,000PF 25V
10%
C859 2113945B02 CAP CER CHP 10,000PF 25V
10%
C860 2113945B02 CAP CER CHP 10,000PF 25V
10%
C861 2113945B02 CAP CER CHP 10,000PF 25V
10%
C862 2113945B02 CAP CER CHP 10,000PF 25V
10%
C863 2113945B02 CAP CER CHP 10,000PF 25V
10%
C864 2113945B02 CAP CER CHP 10,000PF 25V
10%
C865 2113945B02 CAP CER CHP 10,000PF 25V
10%
C866 2113945B02 CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED –
C868 NOT PLACED –
D3 4815096H01 VARACTOR DIODE 1SV305
D5 4815096H01 VARACTOR DIODE 1SV305
D10 4815096H01 VARACTOR DIODE 1SV305
D12 4815096H01 VARACTOR DIODE 1SV305
D20 4813974A19 DIODE ARRAY,MXR,SM,
SOT-323, 7V,.2W,SHTK,2,PB-F
D170 4802482J02 PIN DIODE SMD
D171 4802482J02 PIN DIODE SMD
D172 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D173 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
D201 4815011H01 DIODE TRIPLE
D202 4815011H01 DIODE TRIPLE
D251 4815002H01 VARACTOR DIODE
D252 4815002H01 VARACTOR DIODE
D253 4815002H01 VARACTOR DIODE
D254 4815002H01 VARACTOR DIODE
D271 4815002H01 VARACTOR DIODE
D272 4815002H01 VARACTOR DIODE
D273 4815002H01 VARACTOR DIODE
D274 4815002H01 VARACTOR DIODE
D401 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D402 4815096H01 VARACTOR DIODE 1SV305
D403 4815096H01 VARACTOR DIODE 1SV305
D500 4815155H01 RECTIFIER
D501 4809118D02 LED BICOLOR
LNJ115W8POMT
D510 4813978M15 DIODE,RECT,1A,40V,
PB-FREE,NOTCOMPLETELY
D511 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,SHTK,
D512 4813978M15 DIODE,RECT,1A,40V,
PB-FREE, NOTCOMPLETELY
D513 4813978M15 DIODE,RECT,1A,40V,
PB-FREE, NOTCOMPLETELY
D600 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V,.2W,
SHTK,
D603 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,SHTK,
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
E102 2480574F01 IND FERRITE CHIP 60OHM
0603
E140 2405688Z01 INDUCTOR FERRITE BEAD
E141 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MH
E800 2480574F01 IND FERRITE CHIP 60OHM
0603
E801 2480574F01 IND FERRITE CHIP 60OHM
0603
E802 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
FL51 9185924B01 FILTER, 73.35 MHZ 3-POLE
CRYST
FL200 9116848H01 FLTR SW CAP 3 POLE
BUTTERW, W18
F500 6515076H01 FUSE CHIP SMT TR/1608FF
3A
J101 2880658Z08 CONNECTOR SMA
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L5 2460591C16 COIL AIR WOUND INDUC
16.28
L12 2460591C16 COIL AIR WOUND INDUC
16.28
L31 2414017P13 IDCTR,CHIP,10NH,5%,300MA,
.46OHM,CER,9 Q,2.5GH
L33 2415429H36 CHIP INDUCTOR
L34 2415429H36 CHIP INDUCTOR
L42 2460591C16 COIL AIR WOUND INDUC
16.28
L49 2460591C16 COIL AIR WOUND INDUC
16.28
L53 2415429H43 CHIP INDUCTOR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
