Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-43
6816985H01-F February 14, 2012
L54 2414017K32 IDCTR,CHIP,560NH,5%,50MA,
5OHM,CER,11Q,150MHZS
L55 2414032D25 IDCTR,WW,620NH,5%,400MA,
1.6OHM,CER,28Q,400MHZ
L57 2414017P12 IDCTR,CHIP,8.2NH,5%,300MA,
.39OHM,CER,9 Q,2.8G
L61 2415429H39 CHIP INDUCTOR
L63 2414017P17 IDCTR,CHIP,22NH,5%,300MA,
.88OHM,CER,9 Q,1.8GH
L69 2415429H38 CHIP INDUCTOR
L71 2414017P16 IDCTR,CHIP,18NH,5%,300MA,
.76OHM,CER,9 Q,1.9GH
L72 2415429H38 CHIP INDUCTOR
L73 2415429H47 CHIP INDUCTOR
L74 2414017P17 IDCTR,CHIP,22NH,5%,300MA,
.88OHM,CER,9 Q,1.8GH
L106 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
L114 2414032B56 IDCTR,WW,180NH,5%,750MA,
.77OHM,CER,25 Q,700MH
L119 2460591C35 COIL AIR WOUND INDUC
18.08
L120 2414017G09 IDCTR,CHIP,15NH,5%,300MA,
.45OHM,CER,8Q,SM
L121 NOT PLACED –
L128 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
L130 2414017G09 IDCTR,CHIP,15NH,5%,300MA,
.45OHM,CER,8Q,SM
L131 2414017G01 IDCTR,CHIP,3.3NH,300MA,
.22OHM,CER,8Q,SM,
L132 NOT PLACED –
L134 2414017G03 IDCTR,CHIP,4.7NH,300MA,
.28OHM,CER,8 Q,SM,0603
L139 2460591A29 COIL AIR WOUND INDUC 6.61
L171 2460591B80 COIL AIR WOUND INDUC
19.61
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L172 2460591B80 COIL AIR WOUND INDUC
19.61
L173 2460591B80 COIL AIR WOUND INDUC
19.61
L176 2460591D24 COIL AIR WOUND INDUC
19.71
L200 2414017Q47 IDCTR,FXD,1UH,10%,50MA
,.45OHM,FERR,45 Q,75MHZ
L201 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L202 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L203 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA
,.65OHM,FERR,45Q,50MH
L204 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L205 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
L206 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L251 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L252 2415427H37 CHIP INDUCTOR
L253 2415010H04 AIRWOUND COIL
L254 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L255 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L256 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L257 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L258 2415427H26 CHIP INDUCTOR
L270 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L271 2415427H37 CHIP INDUCTOR
L272 2415010H03 AIRWOUND COIL
L273 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L274 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L275 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L276 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L277 2414017H17 IDCTR,CHIP,27NH,5%,300MA,
.45OHM,CER,12Q,1.1GH
L278 2414017P18 IDCTR,CHIP,27NH,5%,300MA,
1.04OHM,CER,9 Q,1.5G
L279 2414017P18 IDCTR,CHIP,27NH,5%,300MA,
1.04OHM,CER,9 Q,1.5G
L280 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
L403 2414032B75 IDCTR,WW,3.9UH,5%,340MA,
3.6OHM,CER,20Q,70MHZS
L404 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MH
L407 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MH
L411 2466505A01 COIL INDUCTOR
L412 2466505A01 COIL INDUCTOR
L413 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MH
L414 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50M
L500 2414017Q42 IDCTR,FXD,390NH,10%,
200MA, .65OHM,FERR,25Q,
135
L501 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50M
L502 2489669V01 IDCTR,WW,100UH,5%,40MA,
10OHM,20 Q,10MHZ SRF,S
L651 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
L652 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
L701 2486085A01 COIL, POWER INDUCTOR
L702 2486085A01 COIL, POWER INDUCTOR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L703 2464675H01 IDCTR,WW,560NH,5%,550MA
L704 2464675H01 IDCTR,WW,560NH,5%,550MA
L705 2464675H01 IDCTR,WW,560NH,5%,550MA
L708 2416307H01 IDCTR,WW,680NH,5%,0603
L710 2416307H01 IDCTR,WW,680NH,5%,0603
M501 NOT PLACED –
M701 0985888K02 SKT RTC BTTY LEAP
P4 3905643V01 CONTACT ANT GRD
P5 3916333H02 GROUND CONTACT
Q29 4805585Q19 TRANSISTOR
Q101 4816698H03 MITSUBISHI RD09MUP2-T112
UHF RFPA
Q197 4813973A13 XSTR,BIP GP SS,PNP,TO-236,
SOT-23,SMT,40V,.
Q200 4871674S01 XSTR,BIP GP SS
Q251 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q252 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q253 4815055H01 TSTR DUAL NPN/PNP UMH 5
Q271 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q272 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q273 4815055H01 TSTR DUAL NPN/PNP UMH 5
Q401 4805585Q28 TRANSISTOR RF NPN 8GHZ
NOPB
Q402 4813973A04 XSTR,BIP GP SS,NPN,TA13,
SM,SOT-23,SMT,30V,.22
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.2
Q700 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W
Q701 4813973M07 XSTR,BIP GP SS,NPN,TO-236,
SMT,40V,.225W,2
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
