Motorola ATS 3000

9.2-44 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
Q702 5185956E76 IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V
Q703 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42 XSTR,BIP GP SS,NPN,SM,
SC-59, SMT,50V,.23W,
Q804 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.2
R13 0613952R01 CER CHIP RES 10K OHM 5%
0402
R14 0613952R01 CER CHIP RES 10K OHM 5%
0402
R24 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R32 0613952Q70 CER CHIP RES 750 OHM
5 0402
R33 0613952R01 CER CHIP RES 10K OHM 5%
0402
R34 0613952R01 CER CHIP RES 10K OHM 5%
0402
R35 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R36 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R37 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R38 0613958J74 CER CHIP RES 0.0 OHM JMP
0805
R51 0613952Q46 CER CHIP RES 75.0 OHM
5 0402
R60 0613952R25 CER CHIP RES 100K OHM 5%
0402
R61 0613952Q81 CER CHIP RES 2200 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R62 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R63 0613952Q69 CER CHIP RES 680 OHM
5 0402
R102 0613952R05 CER CHIP RES 15K OHM 5%
0402
R103 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R104 0613952R06 CER CHIP RES 16K OHM
5 0402
R108 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R125 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R127 0613952R01 CER CHIP RES 10K OHM 5%
0402
R130 0613952H53 CER CHIP RES 150 OHM 5%
0603
R142 0613952R14 CER CHIP RES 36K OHM
5 0402
R143 0613952Z64 RES,MF,39KOHM,1%,.0625W,
SM, 0402,200PPM/CEL,FO
R144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R146 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R149 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R150 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R151 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R153 NOT PLACED –
R154 0613952Q61 CER CHIP RES 330 OHM
5 0402
R155 0613952Q76 CER CHIP RES 1300 OHM
5 0402
R156 NOT PLACED –
R157 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R158 NOT PLACED –
R159 0613952Q25 CER CHIP RES 10.0 OHM
5 0402
R160 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R162 NOT PLACED –
R168 0613952Q56 CER CHIP RES 200 OHM
5 0402
R169 0613952Q52 CER CHIP RES 130 OHM
5 0402
R170 0613952Q56 CER CHIP RES 200 OHM
5 0402
R171 0613952Q52 CER CHIP RES 130 OHM
5 0402
R199 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R201 0613952Q51 CER CHIP RES 120 OHM
5 0402
R202 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R203 0613952Q63 CER CHIP RES 390 OHM
5 0402
R204 0613952R19 CER CHIP RES 56K OHM 5%
0402
R205 0613952R15 CER CHIP RES 39K OHM 5%
0402
R206 0613952R01 CER CHIP RES 10K OHM 5%
0402
R207 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R208 0613952R13 CER CHIP RES 33K OHM 5%
0402
R209 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R210 0613952R13 CER CHIP RES 33K OHM 5%
0402
R211 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R212 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R213 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R214 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R215 0613952R01 CER CHIP RES 10K OHM 5%
0402
R216 0613952Q46
(PMLE2537A)
0613952K93
(PMLE2537D)
CER CHIP RES 75.0 OHM
5 0402
CER CHIP RES 91 OHM 5 0402
R217 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R218 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R248 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R249 NOT PLACED –
R252 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R253 0613952Q96 CER CHIP RES 9100 OHM
5 0402
R256 0613952Q51 CER CHIP RES 120 OHM
5 0402
R257 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R260 0613952Q94 CER CHIP RES 7500 OHM
5 0402
R261 NOT PLACED –
R262 0613952Q91 CER CHIP RES 5600 OHM
5 0402
R263 0613952Q58 CER CHIP RES 240 OHM
5 0402
R265 0613952Q41 CER CHIP RES 47.0 OHM
5 0402
R266 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R269 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
