UHF1 Schematics, Board Overlays, and Parts Lists 9.2-45
6816985H01-F February 14, 2012
R270 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R271 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R272 0613952Q53 CER CHIP RES 150 OHM
5 0402
R277 NOT PLACED –
R278 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R279 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R280 0613952Q49 CER CHIP RES 100 OHM
5 0402
R284 0613952Q49 CER CHIP RES 100 OHM
5 0402
R285 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R286 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R287 NOT PLACED –
R288 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R289 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R290 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R406 0613952R01 CER CHIP RES 10K OHM 5%
0402
R407 0613952R01 CER CHIP RES 10K OHM 5%
0402
R408 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R412 0613952H55 CER CHIP RES 180 OHM 5%
0603
R413 0613952H61 CER CHIP RES 330 OHM
5 0603
R414 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R415 0613952R01 CER CHIP RES 10K OHM 5%
0402
R417 0613952Q74 RES,MF,1.1KOHM,5%,.0625W,
SM,0402,200PPM/CEL,P
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952R25 CER CHIP RES 100K OHM 5%
0402
R420 0613952R19 CER CHIP RES 56K OHM 5%
0402
R436 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R499 0613952R01 CER CHIP RES 10K OHM 5%
0402
R503 0613952Q63 CER CHIP RES 390 OHM
5 0402
R504 0613952Q66 CER CHIP RES 510 OHM
5 0402
R505 0613952R01
(PMLE2537A)
0613952Q93
(PMLE2537D)
CER CHIP RES 10K OHM 5%
0402
CER CHIP RES 6.8K OHM 5%
0402
R507 0613952Q49 CER CHIP RES 100 OHM
5 0402
R508 0613952Q49 CER CHIP RES 100 OHM
5 0402
R509 0613952Q49 CER CHIP RES 100 OHM
5 0402
R510 0613952Q49 CER CHIP RES 100 OHM
5 0402
R511 0613952R01 CER CHIP RES 10K OHM 5%
0402
R512 0613952R17 CER CHIP RES 47K OHM 5%
0402
R513 0613952R01 CER CHIP RES 10K OHM 5%
0402
R514 0613952R01 CER CHIP RES 10K OHM 5%
0402
R515 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R516 0613952R01 CER CHIP RES 10K OHM 5%
0402
R517 0613952R01 CER CHIP RES 10K OHM 5%
0402
R518 0613952R01 CER CHIP RES 10K OHM 5%
0402
R519 0613952R17 CER CHIP RES 47K OHM 5%
0402
R520 0613952R37 CER CHIP RES 330K OHM 5%
0402
R521 NOT PLACED –
R522 0613952R17 CER CHIP RES 47K OHM 5%
0402
R523 0613952R17 CER CHIP RES 47K OHM 5%
0402
R524 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R525 0613952R01 CER CHIP RES 10K OHM 5%
0402
R526 0613952R01 CER CHIP RES 10K OHM 5%
0402
R527 NOT PLACED –
R528 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R608 0613952Q49 CER CHIP RES 100 OHM
5 0402
R610 NOT PLACED –
R611 0613952Q49 CER CHIP RES 100 OHM 5
0402
R613 0613952R08 CER CHIP RES 20K OHM 5
0402
R614 0613952R08 CER CHIP RES 20K OHM 5
0402
R615 0613952R25 CER CHIP RES 100K OHM 5%
0402
R616 0613952Q49 CER CHIP RES 100 OHM
5 0402
R617 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R620 0613952Q49 CER CHIP RES 100 OHM
5 0402
R621 0613952Q49 CER CHIP RES 100 OHM
5 0402
R622 0613952Q49 CER CHIP RES 100 OHM
5 0402
R625 0613952Q49 CER CHIP RES 100 OHM
5 0402
R626 0613952Q49 CER CHIP RES 100 OHM
5 0402
R633 NOT PLACED –
R634 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R635 NOT PLACED –
R636 0613952R01 CER CHIP RES 10K OHM 5%
0402
R637 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R638 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R639 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R640 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R641 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R642 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R643 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R644 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R647 0613952R01 CER CHIP RES 10K OHM 5%
0402
R649 0613952R17 CER CHIP RES 47K OHM 5%
0402
R654 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
