Motorola ATS 3000 User Manual

9.2-48 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
Notes:
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
n=10
-9
µ=10
-6
m=10
-3
k=10
3
M=10
6
4. ITEM refers to the component reference designator. SIDE refers to the
location of the component on the board; S1=Side 1, S2=Side 2.
5. The PMLE2537A RF Board uses a 6-layer printed circuit board.
PMLE2537F Main Circuit Board
Electrical Parts List
VR650 4813979P12 DIODE ARRAY,TRANSIENT
PROTECTION,SM,SOT-457,1
VR651 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR652 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR657 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR658 4813977C23 DIODE,ZEN,MMSZ5243,SM,
SOD-123,13V,10MA,.5W,ZE
VR659 4813979P10 DIODE ARRAY,TRANSIENT
PROTECTION,SM,SOT-457,5
VR662 4813979P10 DIODE ARRAY,TRANSIENT
PROTECTION,SM,SOT-457,5
VR663 4813977M18 DIODE,ZEN,MBZ5239,SM,
SOT-23, 9.1V,10MA,.225W,Z
VR678 4866544A01 DIODE ARRAY,ZEN,SR05.
TCT,SM,5V,5,LOW CAPA
VR701 4813977M11 DIODE,ZEN,MBZ5232,SM,
SOT-23, 5.6V,10MA,.225W,Z
Y200 4802245J68 OSC, REF 16.8 MHZ 1.5 PPM
Y701 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Y702 4864005H01 RESONATOR, CRYSTAL
24.576 MHZ
6003710K08 BATT COIN 3.3V LIION
1085674C03 PASTE/NC-SMQ230
PMLN4624A PEELABLE LABEL KIT
4285633D01 RETAINING CLIP
PCB 8416617H02 BOARD, PC, UHF BAND 1
(MAKO)
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02 CONNECTOR (CONTACT
BATTERY)
C2 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C3 NOT PLACED –
C4 NOT PLACED –
C9 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C20 2113944A40 CAP CER CHP 100.0PF 50V
5%
C33 2113944A40 CAP CER CHP 100.0PF 50V
5%
C35 2113944A34 CAP CER CHP 56.0PF 50V 5%
C41 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C43 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC,0402,C0G, -55DEG C
C44 2113946K02 CAP CER CHP 0.10UF 16V
C46 2113944A40 CAP CER CHP 100.0PF 50V
5%
C48 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C51 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C54 2113944M01 CAP,FXD,2PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CM
INNER LAYERS
C55 2113945B02 CAP CER CHP 10,000PF 25V
10%
C57 2113944M12 CAP,FXD,5.6PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
C58 2113944M07 CAP,FXD,3.6PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C59 NOT PLACED –
C60 NOT PLACED –
C61 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C62 2113944A29 CAP CER CHP 22.0PF 50V 5%
C63 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C64 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC ,0402,C0G,-55DEG C
C65 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C66 2113946K02 CAP CER CHP 0.10UF 16V
C67 2113946B04 CAP CER CHP 0.10UF 10V
10%
C68 NOT PLACED –
C69 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C70 2113944A40 CAP CER CHP 100.0PF 50V
5%
C71 2113944A80 CAP,FXD,20PF,+5%,-5%,50V-
DC, 0402,C0G,-55DEG C
C72 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C73 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C74 2113944A29 CAP CER CHP 22.0PF 50V 5%
C75 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C76 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC ,0402,C0G,-55DEG C
C77 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C78 2113944A40 CAP CER CHP 100.0PF 50V
5%
C79 2113944A40 CAP CER CHP 100.0PF 50V
5%
C80 2113945B02 CAP CER CHP 10,000PF 25V
10%
C82 2113944A40 CAP CER CHP 100.0PF 50V
5%
C83 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C84 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C85 2113944A07 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C86 2113944A07 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C87 2113944A40 CAP CER CHP 100.0PF 50V
5%
C88 2113945B02 CAP CER CHP 10,000PF 25V
10%
C89 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C90 2113944A40 CAP CER CHP 100.0PF 50V
5%
C100 2113944C45 CAP CER CHP 100.0PF 50V
5%
C102 2113944A40 CAP CER CHP 100.0PF 50V
5%
C103 2113945B02 CAP CER CHP 10,000PF 25V
10%
C104 2113944A40 CAP CER CHP 100.0PF 50V
5%
C108 2113945B02 CAP CER CHP 10,000PF 25V
10%
C109 2113945B02 CAP CER CHP 10,000PF 25V
10%
C110 2113945B02 CAP CER CHP 10,000PF 25V
10%
C111 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
