Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-49
6816985H01-F February 14, 2012
C112 2113944A40 CAP CER CHP 100.0PF 50V
5%
C122 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
C130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C131 2113945B02 CAP CER CHP 10,000PF 25V
10%
C133 2113944C39 CAP CER CHP 56.0PF 50V 5%
C135 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C139 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC, SM,-55DEG CMIN,
C140 2113944A40 CAP CER CHP 100.0PF 50V
5%
C141 2113944C45 CAP CER CHP 100.0PF 50V
5%
C142 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC,SM,-55DEG CMIN,
C143 2113945A10 CAP CER CHP 1500PF 50V
10%
C144 2113945A05 CAP CER CHP 470PF 50V 10%
C145 2113945B03 CAP,FXD,.015UF,+10%,-10%,
25V-DC,0402,X7R,-55
C146 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC, 0603,X7R,-
55DEG
C147 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC, SM,-55DEG CMIN,
C148 2113944A40 CAP CER CHP 100.0PF 50V
5%
C149 2113945B02 CAP CER CHP 10,000PF 25V
10%
C150 2113944A40 CAP CER CHP 100.0PF 50V
5%
C151 NOT PLACED –
C153 2113944C45 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C154 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
C156 2113944F60 CAP,FXD,56PF,+5%,-5%,
50V-DC, 0805,C0G,-55DEG C
C157 2113951A44 CAP NPO 33.0PF +/-5% 250V
C158 2113951A36 CAP NPO 12.0PF +/-5% 250V
HI FREQ
C159 NOT PLACED –
C160 2113951A41 CAP NPO 24.0PF +/-5% 250V
HI FREQ
C161 NOT PLACED –
C169 NOT PLACED –
C170 2113944C45 CAP CER CHP 100.0PF 50V
5%
C171 2113944C45 CAP CER CHP 100.0PF 50V
5%
C172 2113951C12 CAP,FXD,1.2PF,.05PF+/-,
250V-DC, 0603,C0G,-55DE
C173 2113944C13 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C174 2113944C15 CAP CER CHP 2.4PF 50V
+/- 0.25PF
C175 2113944C70 CAP,FXD,5.1PF,.25PF+/-,
50V-DC, 0603,C0G,-55DEG
C176 2113944C29 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C177 2113944C22 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C178 2113944A18 CAP CER CHP 5.1PF 50V
+/- 0.5PF
C179 2113944A40 CAP CER CHP 100.0PF 50V
5%
C182 2113944A40 CAP CER CHP 100.0PF 50V
5%
C185 2113945B02 CAP CER CHP 10,000PF 25V
10%
C186 NOT PLACED –
C187 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C188 2113944A40 CAP CER CHP 100.0PF 50V
5%
C189 2113944A40 CAP CER CHP 100.0PF 50V
5%
C191 NOT PLACED –
C192 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C193 NOT PLACED –
C200 2113945A13 CAP CER CHP 4700PF 50V
10%
C201 2185419D06 CAP CER SUPER L/D 0.1UF
C202 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C203 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C204 2109720D20 CAP CHIP LOW DIST 2000
SOV
C206 2113946K02 CAP CER CHP 0.10UF 16V
C207 2113946K02 CAP CER CHP 0.10UF 16V
C208 2113946K02 CAP CER CHP 0.10UF 16V
C209 2113946K02 CAP CER CHP 0.10UF 16V
C210 2313960D07 CAP,FXD,10,+10,-10,16,
SM,-55MIN,125MAX,174,
C213 2113946K02 CAP CER CHP 0.10UF 16V
C214 2113945B02 CAP CER CHP 10,000PF 25V
10%
C215 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113944A40 CAP CER CHP 100.0PF 50V
5%
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,125MAX,174,
C220 2113945B02 CAP CER CHP 10,000PF 25V
10%
C221 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C222 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,125MAX,174,
C226 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C227 2113944C45 CAP CER CHP 100.0PF 50V
5%
C228 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C229 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C230 2113946K02 CAP CER CHP 0.10UF 16V
C231 2113945A01 CAP CER CHP 220PF 50V 10,
C232 2113946K02 CAP CER CHP 0.10UF 16V
C233 2113946K02 CAP CER CHP 0.10UF 16V
C234 2113944A40 CAP CER CHP 100.0PF 50V
5%
C235 2113944A40 CAP CER CHP 100.0PF 50V
5%
C236 2185419D06 CAP CER SUPER L/D 0.1UF
C237 2185419D06 CAP CER SUPER L/D 0.1UF
C238 2185419D06 CAP CER SUPER L/D 0.1UF
C239 2185419D06 CAP CER SUPER L/D 0.1UF
C240 2185419D06 CAP CER SUPER L/D 0.1UF
C241 2113944A40 CAP CER CHP 100.0PF 50V
5%
C242 2113944A40 CAP CER CHP 100.0PF 50V
5%
C243 2113946K02 CAP CER CHP 0.10UF 16V
C244 2113946B04 CAP CER CHP 0.10UF 10V
10%
C245 2113944A40 CAP CER CHP 100.0PF 50V
5%
C246 2113946N03 CAP CER CHP 2.2UF 16V
C247 2113945A09 CAP CER CHP 1000PF 50V
10%
C248 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
