Motorola ATS 3000

9.2-52 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C734 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
C735 2113946E02 CAP CER CHP 1.0UF 16V 10%
C736 2113946J03 CAP CER CHP 10.0UF 16V
10%
C737 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
C738 2113946K02 CAP CER CHP 0.10UF 16V
C742 2113945A05 CAP CER CHP 470PF 50V 10%
C743 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C750 2113946J03 CAP CER CHP 10.0UF 16V
10%
C751 2113946J03 CAP CER CHP 10.0UF 16V
10%
C752 2113944A40 CAP CER CHP 100.0PF 50V
5%
C753 2113944A40 CAP CER CHP 100.0PF 50V
5%
C754 2113946E02 CAP CER CHP 1.0UF 16V 10%
C755 2113946E02 CAP CER CHP 1.0UF 16V 10%
C756 2113944A40 CAP CER CHP 100.0PF 50V
5%
C757 2113944A40 CAP CER CHP 100.0PF 50V
5%
C758 2113946E02 CAP CER CHP 1.0UF 16V 10%
C759 2113946E02 CAP CER CHP 1.0UF 16V 10%
C760 2113944A40 CAP CER CHP 100.0PF 50V
5%
C761 2113944A40 CAP CER CHP 100.0PF 50V
5%
C762 2113945C31 CAP,FXD,.1UF,+10%,-10%,5
0V-DC,0603,X7R,-55DEG
C763 2113944A40 CAP CER CHP 100.0PF 50V
5%
C764 2113946B03 CAP CER CHP 0.068UF 10V 10
C765 2113946B03 CAP CER CHP 0.068UF 10V 10
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C766 2113945A03 CAP CER CHP 330PF 50V 10%
C767 2113945A03 CAP CER CHP 330PF 50V 10%
C768 2113945A03 CAP CER CHP 330PF 50V 10%
C769 2113945A03 CAP CER CHP 330PF 50V 10%
C770 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C771 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C773 2113946K02 CAP CER CHP 0.10UF 16V
C790 2113946A02 CAP CER CHP 0.022UF 16V
10,
C791 2113946K02 CAP CER CHP 0.10UF 16V
C792 2113946K02 CAP CER CHP 0.10UF 16V
C796 2113944A40 CAP CER CHP 100.0PF 50V
5%
C800 2113955D31 CAP,FXD,1UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
C801 2113944A40 CAP CER CHP 100.0PF 50V
5%
C802 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55
C803 2113944A40 CAP CER CHP 100.0PF 50V
5%
C804 2113946E02 CAP CER CHP 1.0UF 16V 10%
C805 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55
C806 2113946K02 CAP CER CHP 0.10UF 16V
C807 2113946K02 CAP CER CHP 0.10UF 16V
C808 2113946K02 CAP CER CHP 0.10UF 16V
C809 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55
C810 2113946E02 CAP CER CHP 1.0UF 16V 10%
C811 2113946K02 CAP CER CHP 0.10UF 16V
C812 2113946K02 CAP CER CHP 0.10UF 16V
C813 2113946K02 CAP CER CHP 0.10UF 16V
C814 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C815 2113946K02 CAP CER CHP 0.10UF 16V
C816 2113946K02 CAP CER CHP 0.10UF 16V
C817 2113946K02 CAP CER CHP 0.10UF 16V
C818 2113946K02 CAP CER CHP 0.10UF 16V
C830 2113946K02 CAP CER CHP 0.10UF 16V
C840 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C850 2113945A03 CAP CER CHP 330PF 50V 10%
C851 2113944A40 CAP CER CHP 100.0PF 50V
5%
C855 NOT PLACED –
C856 NOT PLACED –
C857 NOT PLACED –
C858 2113945B02 CAP CER CHP 10,000PF 25V
10%
C859 2113945B02 CAP CER CHP 10,000PF 25V
10%
C860 2113945B02 CAP CER CHP 10,000PF 25V
10%
C861 2113945B02 CAP CER CHP 10,000PF 25V
10%
C862 2113945B02 CAP CER CHP 10,000PF 25V
10%
C863 2113945B02 CAP CER CHP 10,000PF 25V
10%
C864 2113945B02 CAP CER CHP 10,000PF 25V
10%
C865 2113945B02 CAP CER CHP 10,000PF 25V
10%
C866 2113945B02 CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED –
C868 NOT PLACED –
CR800 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
CR801 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D3 4815096H01 VARACTOR DIODE 1SV305
D5 4815096H01 VARACTOR DIODE 1SV305
D10 4815096H01 VARACTOR DIODE 1SV305
D12 4815096H01 VARACTOR DIODE 1SV305
D20 4813974A19 DIODE ARRAY,MXR,SM,
SOT-323, 7V,.2W,SHTK,2,PB-F
D170 4802482J02 PIN DIODE SMD
D171 4802482J02 PIN DIODE SMD
D172 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
D173 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
D201 4815011H01 DIODE TRIPLE
D202 4815011H01 DIODE TRIPLE
D251 4815002H01 VARACTOR DIODE
D252 4815002H01 VARACTOR DIODE
D253 4815002H01 VARACTOR DIODE
D254 4815002H01 VARACTOR DIODE
D271 4815002H01 VARACTOR DIODE
D272 4815002H01 VARACTOR DIODE
D273 4815002H01 VARACTOR DIODE
D274 4815002H01 VARACTOR DIODE
D401 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D402 4815096H01 VARACTOR DIODE 1SV305
D403 4815096H01 VARACTOR DIODE 1SV305
D500 4815155H01 RECTIFIER
D501 4809118D02 LED BICOLOR
LNJ115W8POMT
D510 4813978M15 DIODE,RECT,1A,40V,
PB-FREE,NOTCOMPLETELY
D511 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,SHTK,
D512 4813978M15 DIODE,RECT,1A,40V,
PB-FREE, NOTCOMPLETELY
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
