D513 4813978M15 DIODE,RECT,1A,40V,
PB-FREE, NOTCOMPLETELY
D600 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V,.2W,
SHTK,
D603 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,SHTK,
E102 2480574F01 IND FERRITE CHIP 60OHM
0603
E140 2405688Z01 INDUCTOR FERRITE BEAD
E141 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MH
E800 2480574F01 IND FERRITE CHIP 60OHM
0603
E801 2480574F01 IND FERRITE CHIP 60OHM
0603
E802 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
FL51 9185924B01 FILTER, 73.35 MHZ 3-POLE
CRYST
FL200 9116848H01 FLTR SW CAP 3 POLE
BUTTERW, W18
F500 6515076H01 FUSE CHIP SMT TR/1608FF
3A
J101 2880658Z08 CONNECTOR SMA
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L5 2460591C16 COIL AIR WOUND INDUC
16.28
L12 2460591C16 COIL AIR WOUND INDUC
16.28
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L31 2414017P13 IDCTR,CHIP,10NH,5%,300MA,
.46OHM,CER,9 Q,2.5GH
L33 2415429H36 CHIP INDUCTOR
L34 2415429H36 CHIP INDUCTOR
L42 2460591C16 COIL AIR WOUND INDUC
16.28
L49 2460591C16 COIL AIR WOUND INDUC
16.28
L53 2415429H43 CHIP INDUCTOR
L54 2414017K32 IDCTR,CHIP,560NH,5%,50MA,
5OHM,CER,11Q,150MHZS
L55 2414032D25 IDCTR,WW,620NH,5%,400MA,
1.6OHM,CER,28Q,400MHZ
L57 2414017P12 IDCTR,CHIP,8.2NH,5%,300MA,
.39OHM,CER,9 Q,2.8G
L61 2415429H39 CHIP INDUCTOR
L63 2414017P17 IDCTR,CHIP,22NH,5%,300MA,
.88OHM,CER,9 Q,1.8GH
L69 2415429H38 CHIP INDUCTOR
L71 2414017P16 IDCTR,CHIP,18NH,5%,300MA,
.76OHM,CER,9 Q,1.9GH
L72 2415429H38 CHIP INDUCTOR
L73 2415429H47 CHIP INDUCTOR
L74 2414017P17 IDCTR,CHIP,22NH,5%,300MA,
.88OHM,CER,9 Q,1.8GH
L106 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
L114 2414032B56 IDCTR,WW,180NH,5%,750MA,
.77OHM,CER,25 Q,700MH
L119 2460591C35 COIL AIR WOUND INDUC
18.08
L120 2414017G09 IDCTR,CHIP,15NH,5%,300MA,
.45OHM,CER,8Q,SM
L121 NOT PLACED –
L128 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
L130 2414017G09 IDCTR,CHIP,15NH,5%,300MA,
.45OHM,CER,8Q,SM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L131 2414017G01 IDCTR,CHIP,3.3NH,300MA,
.22OHM,CER,8Q,SM,
L132 NOT PLACED –
L134 2414017G03 IDCTR,CHIP,4.7NH,300MA,
.28OHM,CER,8 Q,SM,0603
L139 2460591A29 COIL AIR WOUND INDUC 6.61
L171 2460591B80 COIL AIR WOUND INDUC
19.61
L172 2460591B80 COIL AIR WOUND INDUC
19.61
L173 2460591B80 COIL AIR WOUND INDUC
19.61
L176 2460591D24 COIL AIR WOUND INDUC
19.71
L200 2414017Q47 IDCTR,FXD,1UH,10%,50MA
,.45OHM,FERR,45 Q,75MHZ
L201 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L202 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L203 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA
,.65OHM,FERR,45Q,50MH
L204 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L205 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
L206 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L251 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L252 2415427H37 CHIP INDUCTOR
L253 2415010H04 AIRWOUND COIL
L254 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L255 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L256 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L257 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L258 2415427H26 CHIP INDUCTOR
L270 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L271 2415427H37 CHIP INDUCTOR
L272 2415010H03 AIRWOUND COIL
L273 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L274 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L275 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L276 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L277 2414017H17 IDCTR,CHIP,27NH,5%,300MA,
.45OHM,CER,12Q,1.1GH
L278 2414017P18 IDCTR,CHIP,27NH,5%,300MA,
1.04OHM,CER,9 Q,1.5G
L279 2414017P18 IDCTR,CHIP,27NH,5%,300MA,
1.04OHM,CER,9 Q,1.5G
L280 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
L403 2414032B75 IDCTR,WW,3.9UH,5%,340MA,
3.6OHM,CER,20Q,70MHZS
L404 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MH
L407 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MH
L411 2466505A01 COIL INDUCTOR
L412 2466505A01 COIL INDUCTOR
L413 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MH
L414 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50M
L500 2414017Q42 IDCTR,FXD,390NH,10%,
200MA, .65OHM,FERR,25Q,
135
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
