Motorola ATS 3000

9.2-54 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
L501 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50M
L502 2489669V01 IDCTR,WW,100UH,5%,40MA,
10OHM,20 Q,10MHZ SRF,S
L651 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
L652 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
L701 2486085A01 COIL, POWER INDUCTOR
L702 2486085A01 COIL, POWER INDUCTOR
L703 2464675H01 IDCTR,WW,560NH,5%,550MA
L704 2464675H01 IDCTR,WW,560NH,5%,550MA
L705 2464675H01 IDCTR,WW,560NH,5%,550MA
L708 2416307H01 IDCTR,WW,680NH,5%,0603
L710 2416307H01 IDCTR,WW,680NH,5%,0603
M501 NOT PLACED –
M701 0985888K02 SKT RTC BTTY LEAP
P4 3905643V01 CONTACT ANT GRD
P5 3916333H02 GROUND CONTACT
Q29 4805585Q19 TRANSISTOR
Q101 4816698H03 MITSUBISHI RD09MUP2-T112
UHF RFPA
Q197 4813973A13 XSTR,BIP GP SS,PNP,TO-236,
SOT-23,SMT,40V,.
Q200 4871674S01 XSTR,BIP GP SS
Q251 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q252 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q253 4815055H01 TSTR DUAL NPN/PNP UMH 5
Q271 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q272 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q273 4815055H01 TSTR DUAL NPN/PNP UMH 5
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q401 4805585Q28 TRANSISTOR RF NPN 8GHZ
NOPB
Q402 4813973A04 XSTR,BIP GP SS,NPN,TA13,
SM,SOT-23,SMT,30V,.22
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.2
Q700 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W
Q701 4813973M07 XSTR,BIP GP SS,NPN,TO-236,
SMT,40V,.225W,2
Q702 5185956E76 IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V
Q703 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42 XSTR,BIP GP SS,NPN,SM,
SC-59, SMT,50V,.23W,
Q804 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.2
R13 0613952R01 CER CHIP RES 10K OHM 5%
0402
R14 0613952R01 CER CHIP RES 10K OHM 5%
0402
R24 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R32 0613952Q70 CER CHIP RES 750 OHM
5 0402
R33 0613952R01 CER CHIP RES 10K OHM 5%
0402
R34 0613952R01 CER CHIP RES 10K OHM 5%
0402
R35 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R36 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R37 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R38 0613958J74 CER CHIP RES 0.0 OHM JMP
0805
R51 0613952Q46 CER CHIP RES 75.0 OHM
5 0402
R60 0613952R25 CER CHIP RES 100K OHM 5%
0402
R61 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R62 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R63 0613952Q69 CER CHIP RES 680 OHM
5 0402
R102 0613952R05 CER CHIP RES 15K OHM 5%
0402
R103 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R104 0613952R06 CER CHIP RES 16K OHM
5 0402
R108 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R125 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R127 0613952R01 CER CHIP RES 10K OHM 5%
0402
R130 0613952H53 CER CHIP RES 150 OHM 5%
0603
R142 0613952R14 CER CHIP RES 36K OHM
5 0402
R143 0613952Z64 RES,MF,39KOHM,1%,.0625W,
SM, 0402,200PPM/CEL,FO
R144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R146 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R149 0613952Q89 CER CHIP RES 4700 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R150 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R151 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R153 NOT PLACED –
R154 0613952Q61 CER CHIP RES 330 OHM
5 0402
R155 0613952Q76 CER CHIP RES 1300 OHM
5 0402
R156 NOT PLACED –
R157 NOT PLACED –
R158 NOT PLACED –
R159 0613952Q25 CER CHIP RES 10.0 OHM
5 0402
R160 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R162 NOT PLACED –
R168 0613952Q56 CER CHIP RES 200 OHM
5 0402
R169 0613952Q52 CER CHIP RES 130 OHM
5 0402
R170 0613952Q56 CER CHIP RES 200 OHM
5 0402
R171 0613952Q52 CER CHIP RES 130 OHM
5 0402
R199 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R201 0613952Q51 CER CHIP RES 120 OHM
5 0402
R202 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R203 0613952Q63 CER CHIP RES 390 OHM
5 0402
R204 0613952R19 CER CHIP RES 56K OHM 5%
0402
R205 0613952R15 CER CHIP RES 39K OHM 5%
0402
R206 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
