Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-55
6816985H01-F February 14, 2012
R207 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R208 0613952R13 CER CHIP RES 33K OHM 5%
0402
R209 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R210 0613952R13 CER CHIP RES 33K OHM 5%
0402
R211 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R212 NOT PLACED –
R213 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R214 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R215 0613952R01 CER CHIP RES 10K OHM 5%
0402
R216 0613952Q46
(PMLE2537A)
0613952K93
(PMLE2537D)
CER CHIP RES 75.0 OHM
5 0402
CER CHIP RES 91 OHM 5 0402
R217 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R218 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R248 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R249 NOT PLACED –
R252 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R253 0613952Q96 CER CHIP RES 9100 OHM
5 0402
R256 0613952Q51 CER CHIP RES 120 OHM
5 0402
R257 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R260 0613952Q94 CER CHIP RES 7500 OHM
5 0402
R261 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R262 0613952Q91 CER CHIP RES 5600 OHM
5 0402
R263 0613952Q58 CER CHIP RES 240 OHM
5 0402
R265 0613952Q41 CER CHIP RES 47.0 OHM
5 0402
R266 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R269 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R270 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R271 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R272 0613952Q53 CER CHIP RES 150 OHM
5 0402
R277 NOT PLACED –
R278 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R279 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R280 0613952Q49 CER CHIP RES 100 OHM
5 0402
R284 0613952Q49 CER CHIP RES 100 OHM
5 0402
R285 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R286 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R287 NOT PLACED –
R288 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R289 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R290 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R406 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R407 0613952R01 CER CHIP RES 10K OHM 5%
0402
R408 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R412 0613952H55 CER CHIP RES 180 OHM 5%
0603
R413 0613952H61 CER CHIP RES 330 OHM
5 0603
R414 0613952R01 CER CHIP RES 10K OHM 5%
0402
R415 0613952R01 CER CHIP RES 10K OHM 5%
0402
R417 0613952Q74 RES,MF,1.1KOHM,5%,.0625W,
SM,0402,200PPM/CEL,P
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952R25 CER CHIP RES 100K OHM 5%
0402
R420 0613952R19 CER CHIP RES 56K OHM 5%
0402
R436 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R499 0613952R01 CER CHIP RES 10K OHM 5%
0402
R503 0613952Q63 CER CHIP RES 390 OHM
5 0402
R504 0613952Q66 CER CHIP RES 510 OHM
5 0402
R505 0613952R01
(PMLE2537A)
0613952Q93
(PMLE2537D)
CER CHIP RES 10K OHM 5%
0402
CER CHIP RES 6.8K OHM 5%
0402
R507 0613952Q49 CER CHIP RES 100 OHM
5 0402
R508 0613952Q49 CER CHIP RES 100 OHM
5 0402
R509 0613952Q49 CER CHIP RES 100 OHM
5 0402
R510 0613952Q49 CER CHIP RES 100 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R511 0613952R01 CER CHIP RES 10K OHM 5%
0402
R512 0613952R17 CER CHIP RES 47K OHM 5%
0402
R513 0613952R01 CER CHIP RES 10K OHM 5%
0402
R514 0613952R01 CER CHIP RES 10K OHM 5%
0402
R515 0613952R01 CER CHIP RES 10K OHM 5%
0402
R516 0613952R01 CER CHIP RES 10K OHM 5%
0402
R517 0613952R01 CER CHIP RES 10K OHM 5%
0402
R518 0613952R01 CER CHIP RES 10K OHM 5%
0402
R519 0613952R17 CER CHIP RES 47K OHM 5%
0402
R520 0613952R37 CER CHIP RES 330K OHM 5%
0402
R521 NOT PLACED –
R522 0613952R17 CER CHIP RES 47K OHM 5%
0402
R523 0613952R17 CER CHIP RES 47K OHM 5%
0402
R524 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R525 0613952R01 CER CHIP RES 10K OHM 5%
0402
R526 0613952R01 CER CHIP RES 10K OHM 5%
0402
R527 NOT PLACED –
R528 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R608 0613952Q49 CER CHIP RES 100 OHM
5 0402
R610 NOT PLACED –
R611 0613952Q49 CER CHIP RES 100 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
